NIDI01

/ 4.9
1001 reviews | Need a Specific Revision?
ABB NIDI01 is an INFI 90 OPEN digital I/O termination module that connects permanent field wiring to supported input and output modules. It occupies one standard termination-mounting-unit slot.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for NIDI01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for NIDI01

  • Manufacturer:
    ABB
  • Part Number:
    NIDI01
  • Product Family:
    ABB Bailey
  • Product Type:
    Digital I/O Termination Module
  • Stock:
    1
  • System:
    INFI 90 OPEN
  • Mounting:
    One slot in a standard INFI 90 termination mounting unit
  • Input supply:
    +24 V DC from the termination mounting unit bus bar for applicable I/O modules
  • Ambient temperature:
    0 to 70 deg C
  • Relative humidity:
    0 to 95% to 55 deg C; 0 to 45% to 70 deg C, noncondensing
  • Environment:
    Noncorrosive atmosphere
  • Certification:
    CSA certified for ordinary locations
  • Installation guidance:
    ABB Bailey instruction I-E96-410A
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    3.4x17.4x17.7cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Interoperability Integration Temperature & Humidity Range

Features:

  • Terminates supported INFI 90 digital and analog I/O signal wiring.
  • Occupies one position in the standard termination mounting unit.
  • Uses the documented +24 V DC bus supply with applicable I/O modules.
The NIDI01 order identifies the standard one-slot field-termination assembly for supported INFI 90 I/O modules.

It keeps plant conductors on the termination unit while removable electronics connect through the documented cable path.

Select it only after matching the I/O module type, +24 V bus requirement, terminal allocation and cabinet environment.

Legacy termination hardware is sourced after companion-module and field-wiring compatibility are confirmed.
Verified resources for ABB NIDI01:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Terminate digital and selected analog field circuits in an INFI 90 cabinet.
  • Preserve permanent plant wiring while a supported plug-in I/O module is serviced.
  • Provide the documented +24 V field path for applicable connected modules.
  • The official compatibility table defines which INFI 90 I/O modules may use this termination.
  • Channel voltage and signal behavior are governed by the connected I/O module.
  • The cable and mounting-unit arrangement must follow instruction I-E96-410A.
  • The assembly occupies one position in a standard termination mounting unit.
  • Field conductors remain on the terminal block while the associated module is serviced.
  • Grounding and cable routing must follow the Bailey cabinet practice.
  • Ambient operation is specified from 0 to 70 °C.
  • Relative humidity may reach 95% at temperatures up to 55 °C.
  • At 70 °C the permitted humidity is reduced to 45%, noncondensing.
Description
NIDI01 provides the field-wiring termination point for the supported INFI 90 input and output modules listed in instruction I-E96-410A. It separates permanent field wiring from the plug-in I/O module connection so a module can be serviced without rebuilding the complete field termination.

Field conductors land on the termination-module terminals and are routed through the module and cable connection to the associated I/O module. For applicable modules, the +24 V DC termination-mounting-unit bus bar supplies the field-side circuits; the NIDI01 itself does not execute control logic.

The documented compatibility table covers analog-output, digital-input, digital-output and selected frequency-counter signal types. The actual channel behavior, voltage range and output duty are determined by the connected I/O module, so the selected module and wiring diagram must be checked together.
Alternative Names
NIDI01 NIDI 01 ABB NIDI01 Bailey NIDI01 INFI 90 NIDI01 ABB Digital I/O Termination Module Bailey Digital IO Termination NIDI01
Technical notes
NIDI01 wiring compatibility is determined by the connected INFI 90 I/O module; verify the I-E96-410A application table and terminal plan before moving conductors.
