NKTU01-20

/ 4.9
1001 reviews | Need a Specific Revision?
ABB NKTU01-20 is an INFI 90 termination loop cable for documented Bailey I/O connections, confirmed by matching package and cable labels.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for NKTU01-20
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for NKTU01-20

  • Manufacturer:
    ABB
  • Part Number:
    NKTU01-20
  • Product Family:
    ABB Bailey
  • Product Type:
    Termination Loop Cable
  • Stock:
    1
  • Model:
    NKTU01-20
  • Platform marking:
    ABB INFI 90
  • Cable rating:
    300 V, 80°C, #22 AWG
  • Area marking:
    Class I, Division 2, Groups A-D
  • Label caution:
    Not for interrupting current
  • Weight:
    1.4 kg
  • Estimated shipping dimensions:
    42x35x5cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Receiving Match Area Use Cable Installation Product Applications

Features:

  • Exact dual-label evidence: package and cable both read NKTU01-20.
  • Termination-loop role: the cable is identified for an ABB INFI 90 connection path.
  • Mechanical support: the labeled assembly includes a mounting plate and strain-managed cable route.
NKTU01-20 is an ABB INFI 90 termination loop cable confirmed by two supplied labels.

Its printed electrical and hazardous-area markings belong to the complete labeled assembly.

Safe replacement isolates current elsewhere and verifies the termination path channel by channel.

Apter Power supports exact-label and installation review for ABB NKTU01-20.
ABB NKTU01-20 Termination Loop Cable Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Package identity: the outer label must show the complete NKTU01-20 model.
  • Cable identity: the assembly label must agree with the package before issue.
  • Rated construction: compare the 300 V, 80°C and #22 AWG markings with the installation record.
  • Assembly condition: inspect the mounting plate, connectors, cable and strain relief together.
  • Marked scope: the cable carries a Class I, Division 2 designation for Groups A, B, C and D.
  • Approval marks: FM and CSA symbols apply to the complete labeled assembly.
  • Design boundary: the marking does not approve an undocumented cabinet or field modification.
  • Installation authority: the applicable control drawing and local code govern the final use.
  • Current-interruption warning: do not use NKTU01-20 as a disconnect; isolate with the approved upstream device.
  • Mounting: retain the bracket, strain relief and cable support as part of the assembly.
  • Routing: prevent sharp bends, abrasion and unsupported connector load.
  • Channel proof: verify continuity, isolation and the functional I/O path after reconnection.
  • INFI 90 termination loops: connects documented Bailey cabinet hardware in the installed I/O path.
  • Approved Division 2 cabinets: retains the labeled cable within the applicable hazardous-area design.
  • Rated loop-cable replacement: preserves the specified 300 V, 80°C and #22 AWG assembly attributes.
  • Field I/O restoration: returns a documented termination loop to service after cable or connector damage.
Description
NKTU01-20 is identified on both the package and cable assembly as an ABB INFI 90 termination loop cable. The cable label adds the receiving details that matter most: 300 V, 80°C and #22 AWG.

The marked NKTU01-20 assembly carries Class I, Division 2 Groups A, B, C and D information with FM and CSA symbols. Those markings apply to the complete labeled cable within an approved cabinet and control-drawing context; they do not approve an undocumented modification.

NKTU01-20 is not intended for interrupting current. Isolate the circuit with the approved upstream device, retain the mounting plate and strain relief, reproduce the supported route, and prove every affected channel before returning the termination loop to service.
Alternative Names
NKTU0120 NKTU01 20 ABB NKTU01-20 Bailey NKTU01-20 NKTU-01-20 NKTU01/20 ABB Bailey NKTU01-20 NKTU01 termination loop cable 20
Technical notes
NKTU01-20 is explicitly marked not for interrupting current, so its connector must never be used as the switching device for an energized circuit. Isolate and verify absence of energy through the approved upstream means, then inspect the contacts before reconnecting and testing the affected I/O path.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
A stored NKTU01-20 has jacket damage beside the mounting plate. Can it be installed if continuity still passes?
No. Damage near the support can worsen under bending and compromise the approved assembly; hold it until insulation depth and strain relief are evaluated.
The replacement NKTU01-20 reaches both endpoints only when the mounting plate is left unsupported. Can it be commissioned?
No. Resolve the route and mounting so the bracket carries cable and connector load before any channel returns to service.
A stocked NKTU01-20 has a different jacket rating from the installed cable. Can it still be accepted?
No. Reconcile the printed voltage, temperature, conductor and area markings with the approved installation record before acceptance.
Does the NKTU01-20 label alone approve any hazardous-area installation?
No. The cable marking applies only within the approved cabinet design, control drawing and local code requirements.
An NKTU01-20 has clear FM and CSA markings but its mounting plate is missing. Can it be installed?
No. Treat the bracket, strain relief, connectors and labeled cable as one assembly; obtain the complete approved configuration before installation.
How should NKTU01-20 be tested after replacement?
Verify conductor continuity and isolation first, then prove every affected channel and host indication under the site commissioning procedure.
