AFIN-02C

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB AFIN-02C (3AXD50000038423) is an industrial-grade motor control board powered by 24Vdc. It supports 24Vdc digital input and 0–10V/4–20mA analog input, is compatible with multiple industry standards, and is suitable for signal acquisition and control scenarios of small and medium-sized motors.
Get a quick price for AFIN-02C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for AFIN-02C

  • Manufacturer:
    ABB
  • Part Number:
    AFIN-02C
  • Product Family:
    ABB Drives
  • Product Type:
    3AXD50000038423
  • Digital Inputs:
    24 Vdc
  • Analog Inputs:
    0–10 V / 4–20 mA
  • Operating Temperature:
    -10°C to +50°C
  • Humidity:
    5–95% non-condensing
  • Voltage:
    24 Vdc (±10%)
  • Consumption:
    ≤ 10 W
  • Standards:
    CE, UL, cUL, RoHS
  • Weight:
    0.15 kg
  • Estimated shipping dimensions:
    14.2x10x3.8cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The AFIN-02C Motor Control Board (3AXD50000038423) is engineered for ABB ACS series drives, providing robust and precise motor control. It supports a wide range of digital and analog input signals, allowing seamless integration with modern drive systems.

Equipped with 24 V DC digital inputs and 0–10 V / 4–20 mA analog inputs, the board offers flexibility for varied control and monitoring applications. Its design ensures stable operation within a wide temperature range of -10°C to +50°C and high humidity resilience from 5–95% non-condensing, making it suitable for industrial environments.

The board is optimized for energy efficiency, consuming ≤10 W while operating at 24 V DC ±10%, and it complies with global standards including CE, UL, cUL, and RoHS.With ABB’s engineering and quality assurance, the AFIN‑02C ensures safe, reliable, and long-lasting operation, supporting both routine motor control and advanced protection features for drive systems.
Alternative Names
AF1N-02C AFIN-O2C AFIN-0ZC AFIN02C AF1N02C AFINO2C AFIN0ZC
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does the board support both digital and analog inputs?
Yes, it supports 24 V DC digital inputs and 0–10 V / 4–20 mA analog inputs.
What is the warranty period?
The board comes with a 12-month warranty covering any manufacturing defects.
Can I see more photos or details of the AFIN-02C board?
Yes, additional high-resolution photos of the board, including connector layouts, are available on request.
What are the operating conditions?
The board operates in -10°C to +50°C with 5–95% non-condensing humidity.
