80190-380-02-R is identified by Rockwell Automation as a packaged customer SCB-inverter board.

The PowerFlex 7000 synchronous-transfer guide identifies SCBM 80190-380-02 alongside SCBL 80190-380-01 and provides a hardware-specific test-point cross-reference.

The available exact-model sources do not publish complete ratings, connector mapping, dimensions, weight, or a universal interchangeability statement; verify the installed SCB assembly before ordering or service.

Availability, condition, price, and shipping time for 80190-380-02-R are confirmed during quotation.

Allen-Bradley 80190-380-02-R SCB-Inverter Board Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Rockwell identifies the complete part as a packaged customer SCB-inverter board.
  • The PowerFlex 7000 guide identifies the hardware role as SCBM 80190-380-02.
  • Do not confuse the SCBM board with the separately referenced SCBL 80190-380-01.
  • The official guide provides a cross-reference for 80190-380-series SCB test points.
  • Select the SCBM column for 80190-380-02 hardware before comparing signals.
  • Do not apply 80190-280-series point numbers without using the Rockwell cross-reference.
  • The exact sources establish the SCB-inverter designation and PowerFlex 7000 SCBM context.
  • They do not establish the published dimensions, weight, full connector map, or universal direct replacement.
  • Use the installed drive and SCB assembly records for every unresolved compatibility point.
  • PowerFlex 7000 synchronous-transfer commissioning using the 80190-380 SCB test-point cross-reference.
  • Identification of SCBM 80190-380-02 in an assembly using the documented SCBL 80190-380-01 hardware.
  • Hardware-specific SCB waveform and diagnostic comparison under the applicable Rockwell procedure.
Description
80190-380-02-R is an Allen-Bradley packaged customer SCB-inverter board identified as SCBM 80190-380-02 in PowerFlex 7000 documentation.

Rockwell’s synchronous-transfer guide references this SCBM hardware with SCBL 80190-380-01 and supplies a separate test-point cross-reference for the 80190-380 SCB generation.

Before ordering, diagnostics, or replacement, confirm the installed SCBL/SCBM combination, parent drive configuration, connector layout, and applicable hardware-specific test-point table.
Alternative Names
80190-380-02-R Cat. No. 80190-380-02-R Allen-Bradley 80190-380-02-R Rockwell Automation 80190-380-02-R 80190-380-02-R Packaged Customer SCB-Inverter Board Allen-Bradley 80190-380-02-R SCB-Inverter Board
Technical notes
80190-380-02-R is the PowerFlex 7000 SCBM hardware referenced with SCBL 80190-380-01 in Rockwell’s synchronous-transfer test-point cross-reference; use the correct hardware-specific table before diagnostics.
