  • Lifecycle Status

    Discontinued

    Discontinued date: 2022-12-31

    Replacement category: Functional Replacement

    Functional replacement: 2198-E1004-ERS

2071-AP0

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 2071-AP0 is a discontinued Kinetix 3 50 W single-axis component servo drive for 220 V AC indexing applications.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 2071-AP0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2071-AP0

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2071-AP0
  • Product Family:
    Kinetix Servo Drive
  • Product Type:
    Kinetix 3 Component Servo Drive
  • Stock:
    1
  • Input Voltage:
    170…264 V rms
  • Input Phase:
    Single-phase
  • Input Frequency:
    47…63 Hz
  • Continuous Output Power:
    0.05 kW
  • Continuous Output Current:
    0.61 A rms
  • Continuous Output Current (0-pk):
    0.85 A
  • Peak Output Current:
    1.80 A rms
  • Peak Output Current (0-pk):
    2.55 A
  • Nominal Bus Voltage:
    311 V DC
  • PWM Frequency:
    10 kHz
  • Velocity Loop Bandwidth:
    550 Hz
  • Current Loop Bandwidth:
    2000 Hz
  • Operating Temperature:
    0…50 °C
  • Relative Humidity:
    5…95% noncondensing
  • Maximum Feedback Cable Length:
    30 m
  • Dimensions:
    5.3 × 15.5 × 15.34 cm
  • Weight:
    0.7 kg
  • Tariff Code:
    8503009090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Control Feedback Protection Application
  • Single-axis Kinetix 3 component drive with built-in indexing capability
  • Integrates with Micro800 or MicroLogix controller platforms
  • Supports documented breakout-board and programming-cable accessories
2071-AP0 provides the motion-control stage for one supported servo motor and uses the Kinetix 3 indexing functions documented by Rockwell Automation.

The drive can be commissioned through the documented programming connection, while motor feedback and machine I/O can be organized through the supported breakout-board options.

Before replacement, match the controller interface, motor winding, feedback device, cable set, saved parameters, grounding, clearances, and protective devices.

Availability, condition, price, and shipping time for 2071-AP0 are confirmed during quotation.

Allen-Bradley 2071-AP0 Kinetix 3 Component Servo Drive Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Built-in indexing functions support stored motion profiles
  • Velocity-loop bandwidth is specified as 550 Hz
  • Current-loop bandwidth is specified as 2000 Hz
  • 2071-TBMF provides a documented motor-feedback breakout option
  • Supported feedback-cable length is limited to 30 m
  • Motor and feedback combinations must follow the official selection tables
  • Short-circuit rating is 100,000 A rms symmetrical
  • AC line cycling is limited to one cycle every two minutes
  • Stored capacitor voltage requires at least a five-minute wait after power removal
  • Single-axis indexing mechanisms using a supported Kinetix 3 motor combination
  • Compact machines coordinated by a compatible Micro800 or MicroLogix controller
  • Retrofit projects where the original parameter and wiring records are available
Description
2071-AP0 is an Allen-Bradley Kinetix 3 component servo drive for one 50 W indexing axis supplied from 170…264 V rms single-phase power.

The drive provides 0.61 A rms continuous and 1.80 A rms peak output, with 0.05 kW continuous output, a 311 V DC nominal bus, and the documented Kinetix 3 control and feedback interfaces.

Before replacement, confirm the controller command method, motor winding, feedback device, 2090-series cables, indexing parameters, I/O assignments, grounding, branch protection, and enclosure clearances.
Alternative Names
2071-AP0 2071AP0 2071 AP0 Allen-Bradley 2071-AP0 Allen Bradley 2071-AP0 AB 2071-AP0 Rockwell Automation 2071-AP0 Kinetix 3 2071-AP0
Technical notes
Verify the motor-feedback combination, supported 2071-TBMF or 2071-TBIO accessory, 30 m maximum feedback-cable length, and branch protection before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which current Kinetix drive does Rockwell Automation identify as the functional replacement for Allen-Bradley 2071-AP0?
Rockwell Automation lists 2198-E1004-ERS as the functional replacement. Confirm the controller, motor, feedback, cabling, dimensions, and safety architecture before migration because the replacement is not a drop-in exchange.
Which motor-feedback accessory can simplify field wiring for Allen-Bradley 2071-AP0?
Rockwell Automation lists the 2071-TBMF motor-feedback breakout board for Kinetix 3 drives. Match the feedback device, connector kit, and cable pinout to the installed motor.
How is Allen-Bradley 2071-AP0 commissioned from a personal computer?
Use the documented 2090-CCMPCDS-23AA programming cable and the applicable Kinetix 3 configuration software. Save the existing parameters before replacing or recommissioning the drive.
Can Allen-Bradley 2071-AP0 use an I/O breakout board?
Yes. Rockwell Automation lists the 2071-TBIO I/O breakout board for Kinetix 3 I/O connections. Verify every assigned input and output against the machine drawings.
How long should power remain off before servicing Allen-Bradley 2071-AP0?
Rockwell Automation instructs users to disconnect input power and wait at least five minutes before touching the drive because hazardous capacitor voltage can remain after power is removed.
What should be backed up before replacing Allen-Bradley 2071-AP0?
Record the complete catalog number and hardware label, then save the drive parameters, indexing setup, I/O assignments, motor data, and controller settings used by the installed machine.
What identification should be included when requesting Allen-Bradley 2071-AP0?
Provide the complete 2071-AP0 catalog number, nameplate photos, motor catalog number, feedback type, controller platform, cable information, required condition, quantity, and destination.
