1794-PS1

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1794-PS1 is a 120/230 V AC input power supply that provides 1 A at 24 V DC for compatible FLEX I/O equipment.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1794-PS1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1794-PS1

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1794-PS1
  • Product Family:
    Flex I/O
  • Product Type:
    FLEX I/O 24 V DC Power Supply
  • Stock:
    1
  • Nominal Input Voltage:
    120/230 V AC
  • Input Voltage Range:
    85…264 V AC
  • Input Frequency:
    47…63 Hz
  • Maximum Real Input Power:
    37 W
  • Maximum Apparent Input Power:
    71 VA
  • Maximum Transformer Load:
    93 VA
  • Output:
    1.0 A at 24 V DC
  • Operating Temperature:
    0…55 °C
  • Storage Temperature:
    -40…85 °C
  • Relative Humidity:
    5…95%, noncondensing
  • Dimensions:
    8.7 × 6.8 × 6.9 cm
  • Weight:
    0.2 kg
  • Tariff Code:
    8504401990
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals AC Input DC Load System Connection Application
  • AC-powered FLEX I/O supply for nominal 120 or 230 V AC systems
  • Accepts an 85…264 V AC input across the 47…63 Hz frequency range
  • Provides external 24 V DC power up to the documented 1 A capacity

1794-PS1 supplies the external 24 V DC source used by legacy FLEX I/O adapters and connected modules.

Its wide AC input range supports nominal 120 or 230 V systems while the output remains limited to the documented 1 A capacity.

Do not parallel this power supply with another unit, and review downstream startup current and any controller-specific resistor requirement before energizing.

Availability, condition, price, and shipping time for 1794-PS1 are confirmed during quotation.

Allen-Bradley 1794-PS1 FLEX I/O 24 V DC Power Supply Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The supply accepts the documented 85…264 V AC range at 47…63 Hz.
  • Branch protection, disconnecting means, conductor rating, and grounding remain installation responsibilities.
  • Measure the AC source under load rather than relying only on nominal system voltage.
  • The 24 V DC output is rated for 1 A total user current.
  • Include the adapter, I/O modules, startup demand, and cable loss in the load calculation.
  • Do not wire two 1794-PS1 or related FLEX I/O supplies in parallel.
  • Observe output polarity and the official adapter or controller connection diagram.
  • Use the documented resistor when a 1794-PS1 supplies a FlexLogix controller.
  • Verify output voltage and downstream status before reconnecting field devices.
  • Providing 24 V DC power to compatible FLEX I/O adapters and their local modules.
  • Supplying legacy distributed I/O assemblies from nominal 120 or 230 V AC sources.
  • Powering documented FlexLogix controller arrangements that include the required output-side resistor.
Description
Allen-Bradley 1794-PS1 converts an 85…264 V AC source to a 24 V DC, 1 A output for compatible FLEX I/O assemblies.

The historical Rockwell selection data identifies 47…63 Hz input, 37 W maximum real input power, and a compact DIN-rail-adjacent enclosure for distributed I/O power.

Before reuse or replacement, verify the complete model, input branch protection, output loading, polarity, grounding, spacing, ambient temperature, and any model-specific load or resistor requirement.
Alternative Names
1794-PS1 1794PS1 1794 PS1 Allen-Bradley 1794-PS1 Allen Bradley 1794-PS1 AB 1794-PS1 Rockwell Automation 1794-PS1
Technical notes
1794-PS1 supplies 24 V DC to legacy FLEX I/O equipment; confirm AC input protection, total load, polarity, grounding, clearance, and any FlexLogix resistor requirement, because parallel operation is prohibited.
