  • Lifecycle Status

    Discontinued / Obsolete by OEM

    Apter Power provides quotations, technical documents, sourcing support, and system compatibility guidance.

1747-L543

/ 4.9
1001 reviews | Need a Specific Revision?
1747-L543 is an Allen-Bradley SLC 5/04 processor with 64K words of total memory, DH+, and RS-232 communication. It supports larger SLC 500 programs and modular local or scanner-based remote I/O applications.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1747-L543
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1747-L543

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1747-L543
  • Product Family:
    SLC 500
  • Product Type:
    SLC 5/04 Controller
  • Stock:
    1
  • User Memory:
    64K words total
  • I/O Capacity:
    4096 inputs and 4096 outputs maximum
  • Communication:
    DH+ and RS-232
  • Program Scan:
    0.9 ms/K typical
  • I/O Scan:
    0.225 ms typical
  • Local Chassis:
    3 maximum
  • Local Module Slots:
    30 maximum
  • Backplane Current:
    1.0 A at 5V DC; 200 mA at 24V DC
  • Tariff Code:
    8537101190
  • Country of origin:
    Singapore
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Performance DH+ Connectivity Programming Environment

Features:

  • Provides 64K words of total memory for larger SLC 5/04 programs and data tables.
  • Supports up to 4096 inputs and 4096 outputs in a modular SLC 500 system.
  • Combines Data Highway Plus and configurable RS-232 communication channels.

1747-L543 is the 64K-word SLC 5/04 processor configuration for a modular 1746 SLC 500 system. Its larger memory capacity supports control applications with more extensive program logic and data requirements.

The processor executes the stored control program, updates the chassis I/O image, and coordinates installed modules through the SLC backplane. Its typical program scan is 0.9 ms/K, and its typical I/O scan is 0.225 ms.

Confirm the required memory and I/O capacity, slot-0 placement, chassis power supply, compatible 1746 modules, and the DH+ and serial-channel configuration before installation or replacement.

Availability: OEM-discontinued; contact Apter Power for quotation, documentation, and sourcing support.

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • 1747-L541 provides 16K words of total memory: 12K words for program or data and 4K words reserved for data.
  • The processor supports up to 4096 inputs and 4096 outputs, with a typical program scan time of 0.9 ms/K and a typical I/O scan time of 0.225 ms.
  • It supports up to three local chassis and 30 local module slots, with a backplane load of 1.0 A at 5V DC and 200 mA at 24V DC.
  • Channel 1 provides Data Highway Plus communication for connection to a compatible DH+ network.
  • The DH+ channel supports communication with compatible SLC 5/04 processors, PLC processors, operator interfaces, and programming terminals.
  • Rockwell Automation identifies DH+ communication as three times faster than DH-485 communication in the SLC/1746 system.
  • 1747-L543 provides 64K words of total memory, including 60K words for program or data and 4K words reserved for data.
  • The processor executes the stored control program with a typical program scan time of 0.9 ms/K.
  • RSLogix 500 is used to configure the application program, data tables, processor mode, and communication-channel parameters.
  • The specified operating temperature range is 0 to 60 °C (32 to 140 °F).
  • The specified operating relative humidity range is 5 to 95 percent without condensation.
  • The modular SLC 500 hardware specification lists vibration acceleration of 2.5 g from 57 to 2,000 Hz.
Description
1747-L543 is an Allen-Bradley SLC 5/04 processor with 64K words of total memory. It provides 60K words for program or data and reserves 4K words for data, supporting larger SLC 500 applications than lower-memory SLC 5/04 configurations.

The processor addresses up to 4096 inputs and 4096 outputs and supports up to three local chassis with 30 module slots. Its typical program scan time is 0.9 ms/K, its typical I/O scan time is 0.225 ms, and its backplane load is 1.0 A at 5V DC plus 200 mA at 24V DC.

Channel 1 provides DH+ communication, while Channel 0 provides RS-232 communication and can also be configured for DH-485. These interfaces support programming, network communication, and connection to compatible SLC 500 system devices.

Confirm memory use, DH+ addressing, serial-channel settings, chassis capacity, backplane power, compatible 1746 modules, and the stored program before installation or replacement.
Alternative Names
1747 L543 1747L543 AB 1747-L543 Allen-Bradley 1747-L543 Allen Bradley 1747 L543 SLC 5/04 64K Controller
Technical notes
1747-L543 is an Allen-Bradley SLC 5/04 processor with 64K words of total memory, DH+, and RS-232. It supports larger modular SLC 500 control programs and networked I/O systems.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How much program and data memory does 1747-L543 provide?
1747-L543 provides 64K words total: 60K words for program or data and 4K words for data only.
Which communication channels are included with 1747-L543?
1747-L543 includes DH+ and RS-232 communication; its RS-232 port can be configured for DH-485.
What I/O capacity can 1747-L543 address?
1747-L543 can address up to 4096 inputs and 4096 outputs, subject to the selected local and remote I/O configuration.
What scan performance is specified for 1747-L543?
Rockwell Automation lists a typical program scan of 0.9 ms/K and a typical I/O scan of 0.225 ms.
What is the OEM lifecycle and replacement category for 1747-L543?
Rockwell Automation discontinued 1747-L543 on March 31, 2024 and lists an Engineering Replacement category.
Which manual covers 1747-L543 installation, and how can I request pricing?
Rockwell Automation publication 1747-IN009 covers installation. Contact Apter Power for manuals, sourcing checks, and pricing.
