200150-06-05

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 200150-06-05 is a high-performance, wide-frequency seismic transducer designed for continuous machinery vibration monitoring within Trendmaster ProTIM and Trendmaster 2000 networks.
In Stock
Ships by Wednesday, September 30
Fast Shipping Available
Get a quick price for 200150-06-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 200150-06-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    200150-06-05
  • Product Family:
    200150,200155and200157 Accelerometers
  • Product Type:
    General Purpose Trendmaster Accelerometer
  • Stock:
    1
  • Transducer Type:
    Piezoelectric General-Purpose Accelerometer
  • Sensitivity:
    10.2 mV/(m/s²) (100 mV/g ±12%) at 80 Hz
  • Measurement Limit:
    ±245 m/s² (±25 g) peak acceleration
  • Frequency Range:
    10 Hz to 1,000 Hz (600 to 60,000 cpm) ±10%
  • Mounted Resonant Frequency:
    >20 kHz (>1,200 kcpm)
  • Housing Material:
    Hermetically sealed 304L Stainless Steel
  • Operating Temperature:
    -40°C to +105°C (-40°F to +221°F)
  • Mounting Stud Thread:
    3/8-24 to 1/4 NPT adapter stud (3/4-inch hex)
  • Agency Approvals:
    Multiple Hazardous Location Approvals (CSA, ATEX, IECEx)
  • Weight:
    0.12 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Environmental Ratings Safety & Compliance Firmware & Updates

Features:

  • Converts dynamic machinery shock forces into proportional differential voltage output signals.
  • Utilizes a shear ceramic element encased in a hermetically sealed 304L stainless steel casing.
  • Includes a 3/8-24 to 1/4 NPT mounting adapter stud and 5-pin top connection receptacle.
Order designation 200150-06-05 specifies the general-purpose Trendmaster piezoelectric accelerometer equipped with a 1/4 NPT threaded mounting adapter and multiple hazardous location agency approvals.

Engineered for continuous plant-wide machinery health monitoring, this seismic transducer streams raw vibration acceleration data into Trendmaster scanning infrastructure to track asset degradation.

Field mounting requires torquing the 3/4-inch hex base between 2.7 and 6.8 N·m onto a flat, smooth, surface-prepared machine casing to guarantee optimal high-frequency acoustic transmission.

Availability: Standard Dispatch - Verified In Stock
Bently Nevada 200150-06-05 Trendmaster Accelerometer Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Serves as a permanent sensing node within Trendmaster ProTIM continuous machinery health networks.
  • Captures early mechanical dynamic signature changes caused by bearing element wear and structural looseness.
  • Provides continuous housing vibration data inputs to prevent catastrophic unbalance in rotating machinery skids.
  • Features a hermetically sealed 304L stainless steel casing engineered for harsh industrial washdown environments.
  • Provides continuous ingress protection against moisture penetration, fine particulate dust, and process chemical vapors.
  • Withstands mechanical base shock up to 4,905 m/s² peak without causing sensor housing degradation.
  • Holds multiple hazardous location certifications, including CSA, ATEX, and IECEx intrinsically safe ratings.
  • Satisfies European CE directives for high-level immunity against industrial electromagnetic interference.
  • Meets American Petroleum Institute (API) 670 machinery protection system standards for housing-mounted sensors.
  • Operates as a pure analog piezoelectric sensor without requiring embedded internal firmware updates.
  • Maintains fixed factory-calibrated sensitivity without digital field flash re-programming dependencies.
  • Integrates seamlessly into updated Bently Nevada System 1 diagnostic software scanning schedules.
Description
The Bently Nevada 200150-06-05 accelerometer delivers continuous machinery dynamic vibration data directly to Trendmaster health monitoring architecture. By converting mechanical shock and shaft vibration forces into proportional differential voltage output signals, this case-mounted sensor enables automated plant-wide predictive maintenance strategies across balance-of-plant machinery.

Engineered to operate reliably under severe ambient plant conditions, the Bently Nevada 200150-06-05 features a robust 304L stainless steel enclosure and a top-mounted 5-pin quick-connect terminal. Its internal shear sensing geometry isolates the active piezoelectric ceramic crystal from base bending strain and high-temperature thermal shock transients, maintaining precise measurement integrity during sudden operational load shifts.

Deploying the Bently Nevada 200150-06-05 ensures early detection of mechanical degradation, including rotor unbalance, shaft misalignment, bearing looseness, and structural resonance. Maintenance teams integrate this transducer across boiler feed pumps, cooling tower blowers, gearboxes, and electric motors to minimize unexpected forced downtime and safeguard critical plant operations.
Alternative Names
200150-06-05 200150 06 05 2001500605 Bently Nevada 200150-06-05 BN2001500605 BN 200150-06-05 200150-06-05 Vibration Transducer Bently Nevada Trendmaster 200150 Sensor
Technical notes
When installing the Bently Nevada 200150-06-05, apply a tightening torque of 2.7 to 6.8 N·m (2 to 5 ft·lbf) to ensure solid acoustic coupling without stripping the casing base threads.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What measurement function does the Bently Nevada 200150-06-05 accelerometer perform?
The Bently Nevada 200150-06-05 is a piezoelectric seismic sensor designed to measure dynamic casing acceleration and casing vibration on rotating industrial machinery.
What mounting adapter stud is included with the Bently Nevada 200150-06-05?
The Bently Nevada 200150-06-05 features the -06 mounting option, which specifies a 3/8-24 to 1/4 NPT thread adapter stud with a 3/4-inch hex base.
Is the Bently Nevada 200150-06-05 certified for use in hazardous plant environments?
Yes, the -05 approval option equips the Bently Nevada 200150-06-05 with multiple hazardous area safety certifications, including CSA, ATEX, and IECEx standards.
Which monitoring networks and modules are compatible with the Bently Nevada 200150-06-05?
The Bently Nevada 200150-06-05 interfaces directly with Trendmaster proTIMs, 200100 Dual Acceleration-to-Velocity modules, 89130-01 TIMs, and 1900/25 monitors.
What are the primary machinery applications for the Bently Nevada 200150-06-05?
The Bently Nevada 200150-06-05 is widely deployed on balance-of-plant rotating machinery, such as centrifugal water pumps, electric induction motors, process gearboxes, and industrial fans.
What details are required when requesting a price quote for the Bently Nevada 200150-06-05?
To receive a formal price and delivery quotation for the Bently Nevada 200150-06-05, please specify the full model number 200150-06-05, required purchase quantity, destination country/postal code, and target delivery schedule.
