The General Electric IS220PDIOH1B Mark VIe discrete I/O module combines 24 contact-input channels with control and feedback for 12 relay outputs.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IS220PDIOH1B
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS220PDIOH1B

  • Manufacturer:
    General Electric
  • Part Number:
    IS220PDIOH1B
  • Product Family:
    GE Mark VIe Distributed I/O
  • Product Type:
    Mark VIe Discrete Input/Output Module
  • Stock:
    1
  • Discrete Channels:
    24 inputs and 12 Form C outputs
  • Terminal Connector:
    DC-62
  • Input Isolation:
    1500 V optical group isolation
  • Hardware Input Filter:
    4 ms
  • Output Response:
    Typically 4 ms from Ethernet command
  • Ambient Rating:
    -40 to +70 °C
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Input Logic Output Control Board Pairing Event Setup

Features:

  • Combines contact-input acquisition and relay-output control.
  • Monitors commanded relay states through terminal-board feedback.
  • Supports configurable filtering, SOE capture and offline outputs.
IS220PDIOH1B brings the functions of a discrete input pack and a discrete output pack into one assembly.

Its terminal-board interface carries contact signals, relay-coil power, identity data and multiplexed feedback.

Separate command and enable paths prevent relay operation until the pack has completed initialization.

The General Electric IS220PDIOH1B Mark VIe Discrete Input/Output Module is listed as Active / Available from OEM. Apter Power provides IS220PDIOH1B quotations, product documentation and system-matching support.
General Electric IS220PDIOH1B Mark VIe Discrete Input/Output Module Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Discrete Channel Evaluation

  • Threshold: Contact inputs use a variable comparison level
  • Status: Yellow LEDs show picked-up channels
  • Isolation: Inputs are optically isolated as a group
  • SOE: Input transitions can be recorded at the event scan rate

Relay Command Supervision

  • Commands: Twelve open-collector command circuits drive relay logic
  • Load Check: Current monitors verify a connected picked-up load
  • Enable: An independent line blocks outputs during initialization
  • Feedback: Relay and fuse states return through multiplexed monitors

Terminal Interface Choices

  • Simplex: TDBS boards provide one DC-62 pack position
  • TMR: TDBT boards provide three pack positions
  • Voltage: The terminal board sets contact-input capability
  • Options: Supported option boards add designated output monitoring paths

Configurable Operating Behavior

  • Input Use: Each contact channel can be enabled or left unused
  • Polarity: Signal logic can be normal or inverted
  • Filtering: Software filtering supplements the 4 ms hardware filter
  • Offline State: Relay behavior is selected for loss of controller communication
Description
Within Mark VIe discrete control, General Electric IS220PDIOH1B provides one networked interface for contact acquisition and relay actuation. The module handles as many as 24 contact inputs, commands 12 Form C relay outputs and receives terminal-board feedback.

Field circuits terminate at the DC-62 connection on IS220PDIOH1B. Two RJ-45 ports carry I/O Ethernet traffic, a three-pin input supplies 28 VDC power, and the selected terminal board defines the contact-input voltage and relay-monitoring arrangement.

On the input side, IS220PDIOH1B applies variable-threshold comparison, filtering, hysteresis and optical group isolation before reporting contact state to the controller.

For relay control, current monitoring in IS220PDIOH1B compares each command with the detected load condition. An independent enable path keeps the outputs inactive until the internal startup checks are complete.

Configuration for IS220PDIOH1B can enable input inversion, sequence-of-events recording, selectable digital filtering and defined relay behavior after controller communication is lost. Pack diagnostics monitor internal supplies, hardware identity, wetting voltage, channel response and relay feedback.
Alternative Names
IS220 PDIO H1B IS220-PDIOH1B IS 220 PDIO H1B General Electric IS220PDIOH1B GE IS220PDIOH1B Mark VIe PDIOH1B Module IS220PDIOH1B Discrete I/O Pack IS220PDI0H1B
Technical notes
General Electric IS220PDIOH1B integrates 24 discrete inputs, 12 Form C outputs, feedback monitoring and dual Ethernet communication.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
An IS220PDIOH1B output command is present but its relay LED stays dark. What does the monitor need to detect?
IS220PDIOH1B must detect a picked-up output with a connected load; if load current is not sensed, the monitor remains false and the status LED stays off.
Before a solenoid is wired to IS220PDIOH1B, which limit belongs to the terminal board rather than the pack?
Confirm that the solenoid voltage and current remain within the contact rating of the TDBS or TDBT board paired with IS220PDIOH1B.
A wetting-voltage alarm appears while IS220PDIOH1B Ethernet communication is healthy. Where should troubleshooting move next?
Trace the terminal-board excitation source and associated field wiring, because that supply establishes the contact-input threshold seen by IS220PDIOH1B.
All IS220PDIOH1B relays remain off immediately after power is applied. Is that necessarily a failed output section?
No. IS220PDIOH1B holds its independent output-enable path inactive until the required self-tests and initialization conditions have passed.
After a terminal-board change, IS220PDIOH1B feedback points no longer match the expected relays. What should be verified?
Verify the connected board identity and configuration because IS220PDIOH1B uses that identity to assign relay, coil and fuse-feedback inputs.
If controller communication is interrupted, what determines the resulting IS220PDIOH1B relay state?
The configured offline-output mode for IS220PDIOH1B determines whether each relay powers down, holds its last value or follows a defined value.
