Features:
- Metric format: M8 × 1 unarmored 3300 5 mm probe for restricted machinery locations.
- Lead configuration: 50 mm case with a 1.0 m standard cable and miniature coaxial ClickLoc connector.
- Measurement role: Non-contact shaft vibration or position sensing in a matched transducer system.
The smaller probe geometry supports installations where the available access or mounting envelope does not suit an 8 mm probe.
Its complete order code fixes the metric case, unthreaded length, case length, lead length, connector and approval option.
System performance depends on the matching extension cable, Proximitor Sensor, target material, operating gap and monitor channel.
Apter Power provides documentation, quotation and procurement support for the Bently Nevada 330173-00-05-10-02-00 3300 5 mm M8 x 1 Unarmored Proximity Probe.
Bently Nevada 330173-00-05-10-02-00 3300 5 mm M8 x 1 Unarmored Proximity Probe Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- 330173: M8 x 1 metric 3300 5 mm probe without armor.
- 00: 0 mm unthreaded length.
- 05: 50 mm overall case length.
- 10 / 02 / 00: 1.0 m total probe length, miniature coaxial ClickLoc on standard cable, and agency-approval option code 00.
- Total length: Probe plus extension cable must equal the Proximitor Sensor system length.
- Cable pairing: A 1.0 m probe uses a 4.0 m extension cable for a 5 m system or an 8.0 m cable for a 9 m system.
- Performance basis: Linear range and scale factor apply to the matched transducer chain under OEM reference conditions.
- Commissioning: Confirm the Proximitor model, monitor channel, target material and operating gap before return to service.
- Thread engagement: Maximum engagement for the M8 x 1 probe case is 12 mm.
- Operating gap: Use the OEM nominal gap for the completed 3300 5 mm system and verify channel response.
- Connector: ClickLoc is tightened by hand; option 02 uses standard cable without a connector protector.
- Clearance: Maintain the specified side-view and tip-to-tip spacing and route the unarmored cable away from mechanical damage.
- Radial vibration: Non-contact observation of shaft motion in rotating machinery.
- Axial position: Thrust or shaft-position measurement when the complete channel is configured for that duty.
- Restricted access: Smaller probe geometry for locations where an 8 mm probe will not fit.
- Speed reference: Keyphasor or speed use requires OEM application guidance and validation of the complete measurement channel.
