          Model matching and product manuals for 6ES7215-1AG31-0XB0 are available through Apter Power.

        6ES7215-1AG31-0XB0

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        With 14 digital inputs, 10 transistor outputs and four analog channels onboard, Siemens 6ES7215-1AG31-0XB0 is a CPU 1215C DC/DC/DC for SIMATIC S7-1200 control.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for 6ES7215-1AG31-0XB0
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 6ES7215-1AG31-0XB0

        • Manufacturer:
          Siemens
        • Part Number:
          6ES7215-1AG31-0XB0
        • Product Family:
          Siemens Simatic S7-1200
        • Product Type:
          CPU 1215C DC/DC/DC Compact CPU
        • Stock:
          1
        • Engineering Software:
          STEP 7 V11 SP2 or higher
        • Supply Range:
          20.4–28.8 V DC
        • Work Memory:
          100 KB
        • Integrated Load Memory:
          4 MB
        • Digital Inputs:
          14 integrated, 24 V DC
        • Digital Outputs:
          10 transistor, 24 V DC, 0.5 A
        • Analog Inputs:
          2, 0–10 V DC
        • Analog Outputs:
          2, 0–20 mA
        • PROFINET Ports:
          2 × RJ45
        • High-Speed Counters:
          6, up to 100 kHz
        • Pulse Train Outputs:
          4, up to 100 kHz
        • Expansion Capacity:
          8 signal modules, 3 communication modules, 1 signal board
        • Degree of Protection:
          IP20
        • Operating Temperature:
          -20 to +60 °C horizontal; -20 to +50 °C vertical
        • Weight:
          1.146 lbs (0.52 kg)
        • Estimated shipping dimensions:
          13.4×11×8.5cm
        • Tariff Code:
          85371091
        • Country of origin:
          China
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals I/O Organization Technology Channels PROFINET Paths Expansion Limits

        Features:

        • 6ES7215-1AG31-0XB0 accepts a 20.4–28.8 V DC supply and uses DC transistor outputs.
        • The onboard signal set includes digital I/O, voltage inputs and current outputs.
        • Two RJ45 ports share the integrated PROFINET communication interface.
        The CPU keeps 100 KB of executable work data available while 4 MB of integrated load memory stores the project content.

        Selectable input delays and dedicated high-speed channels separate standard field sensing from counting tasks.

        Local expansion can add signal, communication and plug-in signal-board functions within the documented module limits.

        The Siemens 6ES7215-1AG31-0XB0 CPU 1215C DC/DC/DC may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        Siemens 6ES7215-1AG31-0XB0 CPU 1215C DC/DC/DC Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Local Signal Arrangement

        • Digital sensing: Fourteen 24 V DC inputs bring discrete field states directly into the CPU.
        • Digital actuation: Ten transistor outputs switch 24 V DC loads, with external short-circuit protection required.
        • Analog acquisition: Two voltage inputs accept 0–10 V signals through twisted, shielded cabling.
        • Analog command: Two current outputs deliver 0–20 mA references to connected devices.

        Counting and Pulse Paths

        • Counter inputs: Six digital inputs can be assigned to high-speed counting instead of standard input service.
        • Frequency groups: Single-phase counter channels are divided between 100 kHz and 30 kHz operation.
        • Pulse outputs: Four onboard outputs can generate pulse trains at up to 100 kHz.
        • Project assignment: STEP 7 selects the technological role and timing for each dedicated channel.

        Ethernet Communication Flow

        • Physical access: Two RJ45 sockets provide the cable entry points for the integrated PROFINET interface.
        • Controller role: PROFINET IO controller functions exchange cyclic data with configured devices.
        • Open communication: TCP/IP, ISO-on-TCP and UDP carry supported Ethernet data outside cyclic I/O.
        • Service access: The web server and S7 communication use the same onboard network hardware.

        Station Growth Rules

        • Signal modules: Up to eight modules extend the local input and output capacity.
        • Communication modules: No more than three communication modules can be assigned to the station.
        • Plug-in board: One signal board adds a compact function without consuming a side-module position.
        • Project boundary: The STEP 7 hardware configuration must remain within all three expansion limits.
        Description
        Siemens 6ES7215-1AG31-0XB0 is a SIMATIC S7-1200 CPU 1215C DC/DC/DC compact controller. It executes the user program while the integrated I/O handles local digital and analog field signals without a separate base I/O module.

        Fourteen 24 V DC inputs enter 6ES7215-1AG31-0XB0 alongside ten 24 V DC transistor outputs rated at 0.5 A. Two 0–10 V analog inputs and two 0–20 mA analog outputs extend that local signal set, while six inputs can serve high-speed counting and four outputs can generate pulse trains at up to 100 kHz.

        Network traffic reaches 6ES7215-1AG31-0XB0 through two RJ45 PROFINET ports. The CPU supports PROFINET IO controller operation, S7 communication, TCP/IP, ISO-on-TCP, UDP, Modbus and an integrated web server, so programming, controller communication and Ethernet data exchange share the onboard interface.

        The 100 KB work memory and 4 MB integrated load memory of 6ES7215-1AG31-0XB0 hold the executable program and project data. Hardware expansion is limited to eight signal modules, three communication modules and one signal board, defining how the compact base unit can be extended.

        Powered from 20.4–28.8 V DC, 6ES7215-1AG31-0XB0 carries IP20 protection. Horizontal mounting permits operation from -20 to +60 °C, while the upper limit is +50 °C in the vertical position.
        Alternative Names
        6ES72151AG310XB0 6ES7215 1AG31 0XB0 6ES7 215-1AG31-0XB0 Siemens 6ES7215 1AG31 0XB0 SIMATIC S7-1200 CPU 1215C DC/DC/DC 6ES7215-1AG31-0XB0 CPU 1215C 6ES72I5-1AG31-0XB0 6ES7215-1AG3I-0XB0
        Technical notes
        Siemens 6ES7215-1AG31-0XB0 combines CPU processing, mixed onboard signals and a two-port PROFINET interface in one S7-1200 controller. Match the DC/DC/DC output design and STEP 7 project hardware entry before commissioning.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        How can I distinguish Siemens 6ES7215-1AG31-0XB0 from a relay-output CPU 1215C?
        Siemens 6ES7215-1AG31-0XB0 is the DC/DC/DC version: its ten onboard digital outputs are 24 V DC transistor channels rated at 0.5 A, not relay contacts.
        Which analog signals can 6ES7215-1AG31-0XB0 handle without an added signal module?
        The onboard channels of 6ES7215-1AG31-0XB0 accept two 0–10 V inputs and provide two 0–20 mA outputs; those ranges are not interchangeable.
        Do the two RJ45 sockets on 6ES7215-1AG31-0XB0 represent two separate PROFINET interfaces?
        No. 6ES7215-1AG31-0XB0 has one integrated PROFINET interface presented through two RJ45 ports.
        When does 6ES7215-1AG31-0XB0 need external output protection?
        The transistor outputs of 6ES7215-1AG31-0XB0 do not include short-circuit protection, so protection must be provided externally for the connected loads.
        What changes if 6ES7215-1AG31-0XB0 is mounted vertically?
        Vertical mounting lowers the documented upper operating temperature of 6ES7215-1AG31-0XB0 from +60 °C to +50 °C.
        How far can an S7-1200 station be expanded around 6ES7215-1AG31-0XB0?
        A station based on 6ES7215-1AG31-0XB0 supports up to eight signal modules, three communication modules and one signal board.
