330851-06-000-070-50-00-05

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330851-06-000-070-50-00-05 is a 3300 XL 25 mm Proximity Probe with M39 x 1.5 threaded case, 0 mm unthreaded length, 70 mm case length, 5.0 m (16.4 ft) lead, without armor, and multiple approvals.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 330851-06-000-070-50-00-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330851-06-000-070-50-00-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330851-06-000-070-50-00-05
  • Product Family:
    3300 XL 25mm Proximity Transducer System
  • Product Type:
    3300 XL 25 mm Proximity Probe
  • Stock:
    1
  • Component Type:
    3300 XL 25 mm Proximity Probe
  • Probe Case:
    M39 x 1.5 threaded case
  • Unthreaded Length:
    0 mm
  • Overall Case Length:
    70 mm
  • Total Length:
    5.0 m (16.4 ft)
  • Armor:
    Without armor
  • Agency Approval:
    Multiple approvals
  • Linear Range:
    12.7 mm (500 mils)
  • Weight:
    0.82 kg
  • Estimated shipping dimensions:
    25x22x5cm
  • Tariff Code:
    9031809090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Ordering Code System Matching Installation

Product overview:

  • •Function: Non-contact probe for differential-expansion measurement
  • •Mechanical configuration: M39 x 1.5 threaded case, 0 mm unthreaded, 70 mm overall
  • •Cable configuration: 5.0 m (16.4 ft), without armor

Bently Nevada 330851-06-000-070-50-00-05 is configured with M39 x 1.5 threaded case, 0 mm unthreaded length, 70 mm case length, 5.0 m (16.4 ft) lead, without armor, and multiple approvals.

Connect the 5.0 m probe directly to a 5 m Proximitor Sensor. Confirm target material, mounting, cable routing, and applicable approvals before installation.

Availability is subject to Apter Power's current inventory and sourcing confirmation.

Bently Nevada 330851-06-000-070-50-00-05 Specs

General

Manufacturer Bently Nevada
Model 330851-06-000-070-50-00-05
Condition New and factory sealed
Product Family 3300 XL 25mm Proximity Transducer System

Ordering code breakdown

  • •Base model: 330851 3300 XL 25 mm proximity probe
  • •Probe case: M39 x 1.5 threaded case
  • •Unthreaded length: 0 mm
  • •Overall case length: 70 mm
  • •Total length: 5.0 m (16.4 ft)
  • •Armor: Without armor
  • •Approval code 05: Multiple approvals

System matching guidance

  • •5 m system: Connect the 5.0 m probe directly to a 5 m Proximitor Sensor
  • •Extension cable: Do not add an extension cable to this 5.0 m configuration
  • •Linear range: 12.7 mm (500 mils)
  • •Scale factor: 0.787 V/mm (20 mV/mil)
  • •Reference target: AISI 4140 steel

Installation checks

  • •Nominal gap: 7.0 mm (275 mils) under the official reference conditions
  • •Temperature: -35 to +200 C continuous; +250 C for less than 24 hours
  • •Reference target: AISI 4140 steel; recommended minimum target diameter 61 mm (2.4 in)
  • •Connector: Make ClickLoc connections finger tight and keep connector protectors clean
  • •Cable routing: Maintain a 25.4 mm (1.0 in) minimum bend radius and avoid unsupported loads
  • •Commissioning: Verify target material, bracket stiffness, viewing clearance, gap, and electrical matching
Description

The Bently Nevada 330851-06-000-070-50-00-05 is a 3300 XL 25 mm Proximity Probe configured with M39 x 1.5 threaded case, 0 mm unthreaded length, 70 mm case length, 5.0 m (16.4 ft) lead, without armor, and multiple approvals.

The 3300 XL 25mm Proximity Transducer System provides a 12.7 mm (500 mils) linear range and a nominal scale factor of 0.787 V/mm (20 mV/mil) for differential-expansion measurements.

Connect the 5.0 m probe directly to a 5 m Proximitor Sensor. Confirm target material, mounting, cable routing, and applicable approvals before installation.

Alternative Names
330851-06-000-070-50-00-05 Bently Nevada 330851-06-000-070-50-00-05 Baker Hughes Bently Nevada 330851-06-000-070-50-00-05 330851-06-000-070-50-00-05 3300 XL 25 mm Proximity Probe 330851-06-000-070-50-00-05 3300 XL 25mm Proximity Transducer System 330851-06-000-070-50-00-05 datasheet 330851-06-000-070-50-00-05 quotation 33085106000070500005
Technical notes
330851-06-000-070-50-00-05 uses a M39 x 1.5 threaded case and a 5.0 m (16.4 ft) lead. Connect the 5.0 m probe directly to a 5 m Proximitor Sensor.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the Bently Nevada 330851-06-000-070-50-00-05?
It is a 3300 XL 25 mm Proximity Probe for the 3300 XL 25mm Proximity Transducer System.
What is the configuration of 330851-06-000-070-50-00-05?
M39 x 1.5 threaded case, 0 mm unthreaded length, 70 mm case length, 5.0 m (16.4 ft) lead, without armor, and multiple approvals.
What approval option is specified for 330851-06-000-070-50-00-05?
Code 05 indicates multiple approvals.
What measurement system uses 330851-06-000-070-50-00-05?
It belongs to the 3300 XL 25mm Proximity Transducer System, with a 12.7 mm (500 mils) system linear range.
What scale factor applies to 330851-06-000-070-50-00-05?
The official system nominal scale factor is 0.787 V/mm (20 mV/mil).
How should 330851-06-000-070-50-00-05 be matched?
Connect the 5.0 m probe directly to a 5 m Proximitor Sensor.
What is the lifecycle status of 330851-06-000-070-50-00-05?
Active / Available from OEM.
Can Apter Power support 330851-06-000-070-50-00-05?
Apter Power can provide quotations, technical documents, sourcing support, and system matching guidance.
