The Bosch 1070080132-103 is a COM-E communication module that adds 10Base-T Ethernet and isolated V.24/20 mA serial connectivity to CL400 and CL500 programmable controllers.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1070080132-103
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1070080132-103

  • Manufacturer:
    Bosch
  • Part Number:
    1070080132-103
  • Product Family:
    Bosch
  • Product Type:
    COM-E Ethernet and Serial Communication Module
  • Stock:
    1
  • Supported Controller Platforms:
    Bosch CL400 and CL500
  • Communication Channels:
    2
  • Channel 0 Interface:
    V.24/20 mA, 25-pin socket
  • Channel 0 Electrical Isolation:
    20 mA interface electrically isolated
  • Serial Protocols:
    BUEP03E, BUEP19E, BUEP64 and Tracer/Monitor
  • Serial Baud Rate:
    600 to 57,600 baud
  • Channel 1 Interface:
    Ethernet 10Base-T, RJ45
  • Ethernet Standard:
    IEEE 802.3 10Base-T
  • Ethernet Transfer Rate:
    10 Mbit/s maximum
  • Ethernet Segment Length:
    100 m maximum
  • Recommended Cable:
    100 Ω Category 5 shielded twisted pair
  • Internal Current at 5 V:
    500 mA typical
  • Internal Current at +12 V ISO:
    70 mA plus 20 mA per active current loop
  • Maximum Modules per Controller:
    5 in normal operation
  • Operating Temperature:
    0 to +55 °C
  • Storage Temperature:
    −25 to +70 °C
  • Protection:
    IP20 when installed in housing
  • Width:
    1 controller slot
  • Weight:
    0.3 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Networking Serial Installation Application
  • 10Base-T Ethernet channel with RJ45 connection
  • Electrically isolated V.24/20 mA serial interface
  • Rack-powered operation for Bosch CL400 and CL500 controllers

1070080132-103 is a Bosch COM-E communication module designed for CL400 and CL500 programmable controller systems.

Its two independent channels connect legacy Bosch control applications to 10Base-T Ethernet networks and V.24 or 20 mA serial devices without an external module power supply.

Before installation or replacement, verify the -103 order suffix, rack slot, controller release, network speed, addressing, serial protocol, cable pinout, grounding and saved configuration.

Availability, condition, price, and shipping time for 1070080132-103 are confirmed during quotation.

Bosch 1070080132-103 COM-E Ethernet and Serial Communication Module Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Uses IEEE 802.3 10Base-T in a star topology
  • Supports a maximum 100 m Ethernet segment
  • Provides link, receive and transmit status indications
  • Provides V.24 and electrically isolated 20 mA signaling
  • Supports 600 to 57,600 baud serial communication
  • Supports BUEP03E, BUEP19E, BUEP64 and Tracer/Monitor protocols
  • Receives operating power from the CL400 or CL500 rack power supply
  • Allows up to five COM-E modules per controller in normal operation
  • Requires a reduced 40 °C ambient limit for vertical rack installation
  • Communication between CL400 or CL500 controllers and other Bosch controllers
  • 10Base-T connection of CL400 or CL500 systems to Ethernet-capable industrial devices
  • Serial integration of V.24 or 20 mA devices using supported Bosch protocols
Description
1070080132-103 is a Bosch COM-E Ethernet and serial communication module for CL400 and CL500 programmable controllers.

The module provides one 10Base-T Ethernet channel and one V.24/20 mA serial channel, draws its power from the controller rack, and supports communication with Bosch controllers and other compatible industrial devices.

Before replacement, confirm the complete -103 suffix, CL400 or CL500 rack and slot, hardware and firmware levels, IP and protocol configuration, serial-interface wiring, and availability of a verified configuration backup.
Alternative Names
1070080132-103 1070 080 132-103 COM-E 1070080132-103 Bosch 1070080132-103 Bosch COM-E 1070080132-103 Bosch Rexroth 1070080132-103 Bosch Rexroth COM-E 1070080132-103
Technical notes
1070080132-103 is the Bosch COM-E order-number variant. Match the complete suffix, CL400 or CL500 rack slot, hardware and firmware levels, IP configuration, and serial-interface wiring before exchange.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can Bosch 1070080132-103 be connected directly to a modern managed Ethernet switch?
Only after confirming that the switch port can negotiate or be forced to 10 Mbit/s 10Base-T operation. The COM-E interface is not Fast Ethernet or Gigabit Ethernet, and unsuitable auto-negotiation settings can prevent a link.
What configuration should be recovered before replacing Bosch 1070080132-103?
Preserve the IP address, subnet mask, gateway, COM-E name, serial protocol, baud rate, block address, password settings and controller system-table entries; a powered replacement will not reproduce these site-specific values automatically.
Why might Bosch 1070080132-103 show no Ethernet link after a like-for-like exchange?
Check the RJ45 cable category and pinout, the 100 m segment limit, switch port speed, link integrity indication, rack supply, module seating and IP configuration before assuming the replacement module is defective.
Can the V.24/20 mA connector from another COM-E variant be reused with Bosch 1070080132-103?
Reuse it only after verifying the 25-pin assignment, active-current-loop wiring, shielding, partner-device interface and selected protocol; the isolated 20 mA path does not make an incorrectly wired cable safe.
Can Bosch 1070080132-103 be used in a vertically mounted controller rack at the normal 55 °C ambient limit?
No. Bosch documentation reduces the permitted ambient temperature to 40 °C when the controller rack is installed vertically. Confirm rack orientation, cabinet temperature, airflow and module spacing before using the replacement in this configuration.
What compatibility risk is created by the hardware and firmware level of Bosch 1070080132-103?
The available manual applies to hardware version 1.1 and firmware 1.2 or later. Confirm the label and displayed version before transferring configuration or relying on functions documented for that release level.
What separate items may be needed when purchasing Bosch 1070080132-103?
The module does not establish a working network by itself; confirm the rack, compatible CL400 or CL500 power supply, RJ45 network cable, V.24/20 mA cable or adapter, switch or hub, and configuration records are available separately.
