IC693BEM340

/ 4.9
1001 reviews | Need a Specific Revision?
GE Fanuc IC693BEM340 is a Series 90-30 FIP Bus Controller linking the PLC backplane to a 1 MHz FIP I/O network through dual media connectors.
In Stock
Ships by Thursday, October 29
Get a quick price for IC693BEM340
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC693BEM340

  • Manufacturer:
    General Electric
  • Part Number:
    IC693BEM340
  • Product Family:
    GE 90-30 Series PLC
  • Product Type:
    FIP Bus Controller Module
  • Stock:
    1
  • Network protocol:
    FIP / Factory Instrumentation Protocol
  • Network rate:
    1.0 MHz
  • Bus media:
    Simplex or redundant
  • FIP connectors:
    2 × 9-pin D-sub
  • Service connector:
    15-pin RS-485
  • Status indicators:
    6 front-panel LEDs
  • Module OK indicator:
    Green OK LED provided
  • RUN indicator:
    Green RUN LED provided
  • Channel 1 indicators:
    Channel 1 Carrier Detect and Transmit Enable LEDs
  • Channel 2 indicators:
    Channel 2 Carrier Detect and Transmit Enable LEDs
  • Rack type:
    Series 90-30 CPU or I/O rack
  • Preferred location:
    Main rack
  • CPU compatibility:
    IC693 CPU models 311 through 351
  • Minimum CPU firmware:
    Release 5.0 for original operation; later modes may require newer release
  • Module setup switches:
    No DIP switches or jumpers
  • Firmware loading:
    Via front RS-485 port
  • Configuration modes:
    10, 11, 20 and later mode 30 by firmware
  • Redundancy support:
    Dual FIP media
  • Installation power state:
    Power OFF required
  • Primary reference:
    GFK-1213
  • Weight:
    0.661 lbs (0.3 kg)
  • Estimated shipping dimensions:
    3.5 × 13 × 13.5 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Communication Configuration Compatibility

Features:

  • Interfaces a Series 90-30 PLC to a 1.0 MHz FIP I/O network.
  • Provides two nine-pin bus connectors for simplex or redundant media.
  • Includes an RS-485 serial port for configuration and firmware loading.
The catalog number designates the 1.0 MHz Series 90-30 FIP Bus Controller rather than the separate Genius controller model.

It coordinates remote I/O data, network configuration and diagnostic reporting across the FIP fieldbus.

The installed CPU release, rack location, operating mode and network speed must satisfy the manual before the module is commissioned.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for GE Fanuc IC693BEM340:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Connects Field Control I/O stations to a Series 90-30 controller over FIP.
  • Supports remote Series 90-30 I/O drops and compatible Series 90-70 PLC nodes.
  • Provides a redundant fieldbus path for control systems that use dual FIP media.
  • The controller operates on the documented 1.0 MHz FIP network used by IC693BEM340.
  • Two nine-pin D-sub bus connectors support one or two FIP media channels.
  • A front fifteen-pin RS-485 port is reserved for configuration and firmware-loading functions.
  • The module supports the manual-defined operating modes, including later mode 30 firmware capability.
  • Configuration can be entered with supported Series 90-30 programming tools or the FBCLOAD utility.
  • CPU and software revision requirements must be checked against the installed module firmware.
  • The module plugs into a Series 90-30 CPU or I/O rack, with the main rack preferred for performance.
  • Field Control stations, remote drops and supported FIP devices can share the connected network.
  • IC693BEM341 is the 2.5 MHz counterpart and must not be substituted on a 1.0 MHz network without redesign.
Description
GE Fanuc IC693BEM340 is the rack-mounted FIP Bus Controller for Series 90-30 PLC systems. It links the controller to Factory Instrumentation Protocol devices through two front-panel fieldbus connectors and an onboard RS-485 service port. Two nine-pin FIP connectors serve the network media, while the front fifteen-pin RS-485 service port is reserved for maintenance and firmware loading.

The module manages cyclic I/O exchange, configuration data and fault reporting for Field Control stations, remote I/O drops, compatible Series 90-70 nodes and generic FIP devices. Redundant media can be implemented by using both FIP channels. Six LEDs separate module health, run state and carrier/transmit activity for the two network channels, helping technicians localize media or controller faults.

Selection must not be confused with the IC693BEM331 Genius Bus Controller. Confirm the 1.0 MHz network, CPU firmware, configuration mode, software revision, rack slot and fieldbus connector wiring before installation. The controller is intended for supported Series 90-30 CPU and I/O racks, with operating modes determined by CPU and module firmware rather than hardware switches.
Revisions

Revision Part #

Also known as

IC693BEM340AA
IC693BEM340-AA, Series AA, Rev AA
IC693BEM340CC
IC693BEM340-CC, Series CC, Rev CC
IC693BEM340CD
IC693BEM340-CD, Series CD, Rev CD
IC693BEM340CE
IC693BEM340-CE, Series CE, Rev CE
IC693BEM340EF
IC693BEM340-EF, Series EF, Rev EF
IC693BEM340EG
IC693BEM340-EG, Series EG, Rev EG
Alternative Names
IC693BEM340 GE Fanuc IC693BEM340 IC693 BEM340 IC693-BEM340 GE IC693BEM340 IC693BEM340 FIP Bus Controller Module IC693BEM340 GE Series 90-30 PLC GE Fanuc IC693BEM340 Series 90-30 FIP Bus Controller
Technical notes
IC693BEM340 is a FIP controller, not a Genius module; power must be off before installation and the unused FIP connector requires its protective cap.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which signal or interface value should be checked first for IC693BEM340?
IC693BEM340 is identified by its 1.0 MHz FIP interface, two nine-pin bus connectors and fifteen-pin service port.
How is IC693BEM340 matched to the installed rack or termination path?
Match the Series 90-30 rack, CPU firmware, FIP network speed, configuration tool and intended operating mode.
What field application makes practical use of IC693BEM340?
It exchanges I/O and diagnostic data between the PLC and FIP-connected stations, remote drops and compatible devices.
How is an available-condition offer for IC693BEM340 established?
Apter Power can verify the exact catalog label, revision, condition and lead time before an outage order is placed.
Which engineering comparison reduces replacement risk for IC693BEM340?
Keep the node plan, media redundancy, connector pinout and configured COMV data consistent, then test communications after replacement.
What documentation is useful when requesting pricing for IC693BEM340?
Send the label revision, CPU model and firmware, FIP speed, operating mode, network diagram, quantity and destination.
