Features:
- Routes isolated firing pulses from the drive control section to the SCR power bridge.
- Supports both forward and reverse bridge gate connections through dedicated pulse paths.
- Combines AC-line and DC-bus snubber networks with a DCFB-linked G1 interface.
The G1 arrangement distinguishes DS200PCCAG1A from PCCA groups built around other power-supply interfaces.
Pulse-transformer isolation keeps the low-level firing circuitry electrically separated from the SCR gate paths.
Connector and jumper positions must match the bridge wiring and voltage-feedback arrangement used by the installed drive.
The General Electric DS200PCCAG1A DC2000 Power Connect Card may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric DS200PCCAG1A DC2000 Power Connect Card Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Isolated Firing Paths
- Forward Pulses: Six FPL paths carry commands for the forward SCR bridge devices.
- Reverse Pulses: Six RPL paths support reverse-bridge gate firing in regenerative arrangements.
- Pulse Transformers: Gate commands cross isolated transformer stages before reaching the SCRs.
- Control Input: The 5PL connector brings firing signals and control power from the DCFB board.
Transient Limiting Paths
- AC Protection: AC-line snubbers suppress switching spikes on the incoming power path.
- DC Protection: DC-bus snubbers limit transient voltage across the rectified link.
- Gate Protection: The network reduces stress around the bridge gate-drive circuits.
- Group Layout: The G1 configuration includes both AC and DC snubber functions.
DC2000 Connection Map
- 5PL Link: The main control connection interfaces the PCCA with the DCFB power-supply board.
- FPL Set: Forward gate outputs are separated into individually identified bridge connections.
- RPL Set: Reverse gate outputs provide the corresponding regenerative bridge paths.
- Feedback Points: P3 through P10 accommodate voltage-feedback scaling resistors.
Group-One Setup
- Board Match: The G1 board selection must agree with the installed DC2000 power structure.
- Jumper Use: Configurable jumpers set voltage-feedback and snubber-related options.
- Frame Support: The board group is used with C-frame and G-frame drive arrangements.
- Assembly Check: Connector designations provide the reference for reproducing the installed wiring layout.
