General Electric IC200ALG327 is a 12-channel VersaMax analog voltage output module with jumper-selectable unipolar or bipolar operation.
In Stock
Ships by Thursday, October 1
Fast Shipping Available
Get a quick price for IC200ALG327
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC200ALG327

  • Manufacturer:
    General Electric
  • Part Number:
    IC200ALG327
  • Product Family:
    GE VersaMax
  • Product Type:
    12-Channel Analog Voltage Output Module
  • Stock:
    1
  • Output Channels:
    12 single-ended channels, one group
  • Output Ranges:
    -10.24 to +10.24 V or 0 to +10.24 V
  • Resolution:
    13-bit; 1.25 mV per 4 counts
  • Module Update:
    15 ms maximum
  • Field Supply:
    +18 to +30 VDC, 112 mA maximum
  • Load:
    5 kΩ minimum; 1.0 µF maximum
  • Isolation:
    250 VAC continuous; 1500 VAC for 1 minute, user side to logic/frame
  • Diagnostics:
    Loss of user-side power
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Output Ranges Carrier Jumpers Channel Wiring Data Scaling

Features:

  • Provides twelve single-ended voltage output points.
  • Uses FLD PWR and OK indicators for separate field-side and backplane checks.
  • Operates across the documented temperature range without thermal derating.
The General Electric IC200ALG327 catalog number identifies the high-density 13-bit voltage member of the VersaMax output family; its range selection is made for the complete channel bank.

Loss-of-field-power reporting gives the host a direct indication when output energy disappears, while the two front LEDs separate that condition from missing rack power.

During a replacement, confirm the carrier terminal style, both jumper positions and the host configuration before transferring any of the six output-return pairs.

The General Electric IC200ALG327 12-Channel Analog Voltage Output Module is supported by Apter Power with documentation and system-matching assistance.
General Electric IC200ALG327 12-Channel Analog Voltage Output Module Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Bipolar and Unipolar Selection

  • Range Link: JMP1 open selects -10.24 to +10.24 V; installed selects 0 to +10.24 V.
  • Group Scope: The selected range applies to all twelve outputs.
  • Configuration Match: The CPU or NIU hardware configuration must match the carrier jumper.
  • Change Control: Remove module and field power before moving the range link.

Fallback Link Behavior

  • Hold State: Leaving JMP2 open retains the most recent output command.
  • Default State: Installing JMP2 selects a 0 V response.
  • Power Dependency: The external field supply must remain present for either documented behavior.

Paired Return Layout

  • Channels 1-2: Both outputs use the return assigned at B6.
  • Channels 3-4: The corresponding return is B10.
  • Channels 5-6: Their shared pair return is A3.
  • Channels 7-8: Their shared pair return is A7.
  • Channels 9-10: Their shared pair return is A11.
  • Channels 11-12: Their shared pair return is A15.

Count-to-Voltage Handling

  • Bipolar Formula: Use the documented 20.5 V span relationship for signed counts.
  • Unipolar Formula: Use the documented 10.25 V span relationship for positive counts.
  • Valid Steps: Output data is resolved in multiples of four counts.
  • Rounding: A value between valid steps is rounded downward by the module.
Description
Twelve voltage commands share one single-ended output group in the General Electric IC200ALG327. A carrier link selects either -10.24 to +10.24 V bipolar service or 0 to +10.24 V unipolar service, allowing one module to match either documented range.

A maximum 15 ms module update lets the General Electric IC200ALG327 refresh all twelve host output words together. The 13-bit conversion resolves each valid command in 1.25 mV steps, and out-of-step controller values are rounded down to a multiple of four counts.

Field-side power for the General Electric IC200ALG327 must remain within +18 to +30 VDC, including ripple. Its six paired returns, shielded twisted-pair guidance and hold-last or 0 V fallback jumper need to be matched to the selected carrier before commissioning.
Revisions

Revision Part #

Also known as

IC200ALG327A
IC200ALG327-A, Series A, Rev A
IC200ALG327F
IC200ALG327-F, Series F, Rev F
IC200ALG327G
IC200ALG327-G, Series G, Rev G
IC200ALG327H
IC200ALG327-H, Series H, Rev H
IC200ALG327J
IC200ALG327-J, Series J, Rev J
Alternative Names
IC200-ALG327 IC200 ALG327 IC 200 ALG 327 GE IC200ALG327 GE Fanuc IC200ALG327 Emerson IC200ALG327 VersaMax IC200ALG327 12-Channel Voltage Output IC2OOALG327
Technical notes
General Electric IC200ALG327 provides twelve single-ended VersaMax voltage outputs with 13-bit conversion and jumper-selected bipolar or unipolar range.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why does General Electric IC200ALG327 produce only positive voltage when the project expects a bipolar signal?
General Electric IC200ALG327 uses JMP1 for the whole output group. Remove power, confirm that B1-B2 is open for bipolar operation, and make the CPU or NIU hardware configuration agree with that physical selection.
How should an unstable field voltage from General Electric IC200ALG327 be traced?
For General Electric IC200ALG327, measure the external supply at B18-B17 under load, check the paired channel return, and terminate the shield through the grounding method specified for the installed carrier.
A device connected to General Electric IC200ALG327 never reaches the commanded level; what should be compared?
General Electric IC200ALG327 requires at least 5 kΩ resistive loading and limits capacitance to 1.0 µF. Compare the receiver and cable load with those limits before evaluating converter accuracy.
Can General Electric IC200ALG327 retain twelve output commands during a controller interruption?
General Electric IC200ALG327 holds the last values when JMP2 is absent and field power remains available. Installing JMP2 selects a 0 V fallback for the documented interruption events.
What causes a small count-to-voltage mismatch on General Electric IC200ALG327?
General Electric IC200ALG327 accepts commands in four-count increments and rounds other values down. Apply the manual's bipolar or unipolar scaling equation to the rounded count, not the original value.
Which terminal grouping matters when replacing wiring on General Electric IC200ALG327?
General Electric IC200ALG327 pairs channels 1-2, 3-4, 5-6, 7-8, 9-10 and 11-12 with separate listed returns. Preserve the correct pair-return relationship instead of treating the module as one common-return bank.
