General Electric IC200MDL740 is a VersaMax 16-point 12/24 V DC positive-logic sourcing output module rated at 0.5 A per point.
In Stock
Ships by Wednesday, September 30
Get a quick price for IC200MDL740
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC200MDL740

  • Manufacturer:
    General Electric
  • Part Number:
    IC200MDL740
  • Product Family:
    GE VersaMax
  • Product Type:
    16-Point 12/24 V DC Positive Logic Output Module
  • Stock:
    1
  • Output points:
    16 in one group
  • Output logic:
    Positive logic; sourcing
  • External supply / output voltage:
    +10.2 to +30 V DC; +12/24 V DC nominal
  • 12 V operation:
    Requires IC200MDL740B or later
  • Maximum output voltage drop:
    0.3 V
  • Maximum resistive load current:
    0.5 A per point at 30 V DC
  • Maximum inrush current:
    2.0 A for 100 ms
  • Maximum off-state leakage:
    0.5 mA at 30 V DC
  • Maximum on response:
    0.2 ms
  • Maximum off response:
    1.0 ms
  • Isolation:
    250 V AC continuous; 1500 V AC for 1 minute, output-to-logic/frame
  • 5 V backplane consumption:
    45 mA maximum
  • Indicators:
    One output-state LED per point, FLD PWR LED, and backplane-power OK LED
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Output Architecture Diagnostics Load Performance Application
  • Provides one group of sixteen positive-logic sourcing outputs for VersaMax control stations.
  • Uses external field power while intelligent processing is performed by the VersaMax CPU or network interface unit.
  • Includes individual output-state LEDs together with FLD PWR and OK indicators for status checks.

IC200MDL740 is the 16-point member of the VersaMax 12/24 VDC positive-logic output range and installs on a compatible I/O carrier.

The module connects a VersaMax controller or network interface unit to externally powered DC field circuits in local or distributed I/O stations.

Before commissioning, verify carrier wiring, sourcing polarity, load inrush, thermal derating, external protection, and revision B or later for 12 V operation.
