        • Lifecycle status

          Active / Available from OEM
          Apter Power supports sourcing, documentation, and system matching for General Electric IC200CPU005.

        IC200CPU005

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        General Electric IC200CPU005 is a VersaMax PLC CPU module for compact machine and distributed I/O control systems.
        In Stock
        Ships by Tuesday, September 29
        Fast Shipping Available
        Get a quick price for IC200CPU005
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IC200CPU005

        • Manufacturer:
          General Electric
        • Part Number:
          IC200CPU005
        • Product Family:
          GE VersaMax
        • Product Type:
          VersaMax CPU Module
        • Stock:
          1
        • Configurable Memory:
          128 kB
        • System Capacity:
          Up to 64 modules and 2048 I/O points
        • Program Storage:
          System flash and battery-backed RAM
        • Embedded Ports:
          One RS-232 and one RS-485
        • Serial Protocols:
          SNP slave, RTU master/slave, Serial I/O
        • Programming Languages:
          Ladder Diagram, Sequential Function Chart, Instruction List
        • Boolean Execution:
          0.5 ms/K typical
        • Floating Point:
          Supported
        • Backplane Current:
          35 mA at 5 V; 300 mA at 3.3 V
        • Memory Hold:
          1 hour by super capacitor; up to 6 months by battery
        • Operating Temperature:
          0 to 60 °C
        • Humidity:
          5% to 95%, noncondensing
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Memory & Logic Serial Setup Power & Expansion Applications

        Features:

        • IC200CPU005 provides 128 kB of configurable memory for VersaMax control programs.
        • Two embedded ports support RS-232 and RS-485 serial connections.
        • The CPU manages as many as 64 modules and 2048 I/O points.
        The larger memory space accommodates logic, registers, and configurable analog data within one compact controller.

        Separate electrical interfaces let a project connect point-to-point devices through RS-232 and multidrop equipment through RS-485.

        Local and expansion I/O can be organized under one VersaMax controller while the installed module count remains inside the supported system limit.

        The General Electric IC200CPU005 VersaMax CPU Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        General Electric IC200CPU005 VersaMax CPU Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Program resources and execution behavior

        • Memory Allocation: The 128 kB configurable space can be divided among logic, registers, and analog data areas.
        • Retentive Storage: System flash and battery-backed RAM preserve the project across planned power interruptions.
        • Language Support: Ladder Diagram, Sequential Function Chart, and Instruction List address different control tasks.
        • Numeric Processing: Floating-point functions support calculations that require real-number values.

        Port roles and communication planning

        • Port 1: The 9-pin RS-232 interface suits direct links whose cable length follows the selected data rate.
        • Port 2: The RS-485 connection supports longer runs and two-wire or four-wire RTU arrangements.
        • Mode Selection: Each port can be assigned to supported SNP slave, RTU, or Serial I/O operation in software.
        • Stop Behavior: Ports configured for Serial I/O revert to SNP slave when the controller enters Stop mode.

        Backplane planning and station growth

        • Supply Choice: An expanded 3.3 V VersaMax power supply is required for the CPU's backplane demand.
        • Current Budget: Allow 35 mA at 5 V and 300 mA at 3.3 V before adding accessory loads.
        • Module Count: The control station can extend to 64 modules when rack and power limits are respected.
        • I/O Scale: The architecture supports up to 2048 points distributed across the configured VersaMax station.

        Control roles suited to this CPU

        • Machine Sequences: Local logic can coordinate discrete and analog devices in compact equipment.
        • Serial Integration: Embedded interfaces connect RTU or SNP devices without a separate serial module.
        • Distributed I/O: Expansion capability supports machines whose field points span several rack sections.
        • Process Calculations: Floating-point operations suit control routines that use scaled engineering values.
        Description
        The General Electric IC200CPU005 is a VersaMax PLC CPU with 128 kB of configurable memory and controller capacity for as many as 64 modules and 2048 I/O points.

        Two embedded serial interfaces separate the connection roles: Port 1 uses RS-232, while Port 2 provides RS-485 for longer multidrop links. The ports can be assigned to SNP slave, RTU master or slave, and Serial I/O functions within their supported data-rate ranges.

        System flash and battery-backed RAM retain the control program, and the battery circuit also protects data and the time-of-day clock after the super capacitor's one-hour hold period. Ladder Diagram, Sequential Function Chart, and Instruction List programming are supported together with floating-point operations.

        This CPU requires an expanded 3.3 V VersaMax power supply. During integration, confirm the power budget, serial cable length, protocol settings, and the physical module count before downloading the application.
        Revisions

        Revision Part #

        Also known as

        IC200CPU005AB
        IC200CPU005-AB, Series AB, Rev AB
        Get Parts Quote
        IC200CPU005CF
        IC200CPU005-CF, Series CF, Rev CF
        Get Parts Quote
        IC200CPU005EF
        IC200CPU005-EF, Series EF, Rev EF
        Get Parts Quote
        IC200CPU005FF
        IC200CPU005-FF, Series FF, Rev FF
        Get Parts Quote
        IC200CPU005GG
        IC200CPU005-GG, Series GG, Rev GG
        Get Parts Quote
        IC200CPU005HG
        IC200CPU005-HG, Series HG, Rev HG
        Get Parts Quote
        Alternative Names
        IC200-CPU-005 GE Fanuc IC200CPU005 IC 200 CPU 005 VersaMax IC200CPU005 IC200 CPU005 GE IC200CPU005 IC200CPU005 PLC CPU IC2OOCPUOO5
        Technical notes
        General Electric IC200CPU005 combines 128 kB configurable memory with RS-232 and RS-485 serial control. Power integration depends on a VersaMax supply with expanded 3.3 V capacity.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Why does General Electric IC200CPU005 require a specific VersaMax power supply?
        Because General Electric IC200CPU005 draws 300 mA from the 3.3 V backplane output, it must be paired with an expanded 3.3 V VersaMax supply.
        How should serial cable length be planned for General Electric IC200CPU005?
        Cable length for General Electric IC200CPU005 Port 1 decreases as the RS-232 data rate rises, while Port 2 RS-485 can extend to 1200 m; use the limits that match the configured rate.
        What protects the program if power is removed from General Electric IC200CPU005?
        A super capacitor supports General Electric IC200CPU005 memory for about one hour, after which the backup battery can preserve program, data, and clock contents for up to six months.
        Can General Electric IC200CPU005 use both serial ports for the same protocol role?
        Both ports on General Electric IC200CPU005 can be configured for supported SNP, RTU, or Serial I/O roles, but port interface, baud rate, and wiring must agree with each connected device.
        Which checks prevent an I/O-capacity mismatch with General Electric IC200CPU005?
        Count every local and expansion module before loading the project; General Electric IC200CPU005 controls up to 64 modules and 2048 I/O points within the VersaMax architecture.
        What should be compared when replacing a controller with General Electric IC200CPU005?
        For a General Electric IC200CPU005 replacement, compare memory use, serial port assignments, protocol settings, power-supply capacity, I/O mapping, and the stored application before commissioning.
