IC200ALG261

/ 4.9
1001 reviews | Need a Specific Revision?
The General Electric IC200ALG261 VersaMax Analog Input Module is a 8-channel differential voltage input module designed for industrial control systems, supporting ±10 VDC input range with high-resolution signal conversion.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for IC200ALG261
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC200ALG261

  • Manufacturer:
    General Electric
  • Part Number:
    IC200ALG261
  • Product Family:
    GE VersaMax
  • Product Type:
    Analog Input Module
  • Stock:
    1
  • Lifecycle Status:
    Active
  • Input Range:
    ±10 VDC
  • Number of Channels:
    8
  • External Power Supply:
    None
  • Resolution:
    Bipolar mode: 0 .3125 mV = 1 counts
  • Update Rate:
    7 .5 ms
  • Accuracy at 25°C:
    ±0 .3% typical of full scale, ±0 .5% maximum of full scale.
  • Input Impedance:
    Voltage mode: 100 kOhms maximum.
  • Input Filter Response:
    N/A
  • 5V Backplane Current Consumption (mA):
    200 maximum
  • LED Indicators:
    INT PWR LED indicates internally-generated field power is present . OK LED indicates backplane power is present .
  • Weight:
    0.15 kg
  • Estimated shipping dimensions:
    11x5.8x6.6cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Upgrade Application Safety

Features:

  • High-Precision 15-Bit Differential Voltage Input with Eight Independent Channels for Accurate Multi-Signal Data Acquisition.
  • Backplane-Powered Architecture Eliminates the Need for External Module Power, Simplifying System Installation and Wirin.
  • Integrated CPU- or NIU-Based Processing and Built-In Diagnostics Ensure Reliable Operation and Continuous System Monitoring.
The IC200ALG261 is widely used in industrial automation systems where accurate analog voltage acquisition is required. It provides stable performance across 8 differential input channels, making it suitable for complex control architectures. The IC200ALG261 is commonly integrated into plc-based systems for real-time monitoring and process regulation. Its backplane-powered design simplifies system architecture and reduces installation complexity.

In manufacturing environments, the IC200ALG261 plays a key role in converting field voltage signals into reliable digital data. The module supports fast update cycles of 7.5 ms, enabling responsive control in dynamic processes. The IC200ALG261 ensures consistent performance even under industrial electrical noise conditions. Its 15-bit resolution enhances data accuracy for critical automation tasks.

The IC200ALG261 is also designed for flexibility in installation and grounding configurations, ensuring stable signal integrity in various system layouts. It is suitable for energy systems, process industries, and automated production lines requiring high-channel analog input. The IC200ALG261 helps improve system efficiency by delivering precise and timely voltage measurements.

The IC200ALG261 General Electric VersaMax Analog Input Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IC200ALG261 VersaMax Analog Input Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
General Electric IC200ALG261 VersaMax Analog Input Module Specs

General

  • Manufacturer General Electric
  • Model IC200ALG261
  • Condition New Original ready stock
  • Product Family IC200CHS022,IC200ALG620,IC200MDL740
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Firmware Compatibility: Supports online firmware updates via the controller to enhance the ability to recognize the latest sensor protocols.
  • Hot-Swap: Supports module replacement while the base is powered on, greatly reducing system repair time after hardware failure.
  • Configuration Adjustment: Channel ranges (e.g., 0-10V or 4-20mA) can be switched via software without manual physical calibration.
  • Diagnostic Iteration: The new version enhances the over-range detection logic, providing more accurate data overflow alarms.
  • Environmental Monitoring: Connects to temperature and humidity transmitters for data acquisition in cleanrooms or temperature and humidity controlled warehouses.
  • Level Measurement: Connects to hydrostatic or ultrasonic level gauges for high-precision real-time monitoring of industrial storage tanks.
  • Pressure Control: Monitors pressure sensor feedback in hydraulic or water supply systems for PID closed-loop regulation.
  • Energy Management: Acquires analog signals from current and voltage converters for factory energy consumption analysis and power load monitoring.
  • Electrical Isolation: High-level isolation between channels and the backplane bus prevents field noise from interfering with CPU logic.
  • Status Monitoring: The panel is equipped with an OK indicator light, which can display the module hardware health status and whether there are configuration conflicts in real time.
  • Signal Filtering: Built-in digital filters can effectively suppress 50/60Hz power frequency interference, ensuring the authenticity of input signals.
  • Overvoltage Protection: The input terminal has a voltage clamping circuit to resist instantaneous overvoltage surges caused by incorrect field wiring.
Description
The IC200ALG261 is a high-performance analog input module designed for VersaMax PLC systems, offering 8 differential voltage input channels with a ±10 VDC input range. The IC200ALG261 converts field voltage signals into precise digital data with a 15-bit resolution, enabling accurate monitoring and control in industrial automation environments. With its backplane-powered design, the IC200ALG261 eliminates the need for an external power supply for module operation, simplifying system integration and reducing wiring complexity.

The IC200ALG261 features an update rate of 7.5 ms, allowing fast signal processing for dynamic industrial applications. It provides typical accuracy of ±0.3% at 25°C and a maximum accuracy of ±0.5% of full scale, ensuring stable measurement performance in varying operating conditions. The module also supports a maximum backplane current consumption of 200 mA, maintaining efficient power usage within VersaMax systems. Compared to similar modules such as the IC200ALG240 series, the IC200ALG261 offers improved channel density and refined voltage measurement precision for more demanding analog input applications.

The IC200ALG261 is designed with a 100 kΩ maximum input impedance in voltage mode, which minimizes signal loading and improves measurement stability. It also includes LED indicators for OK status and internal field power monitoring, providing real-time diagnostic feedback. The module integrates seamlessly into VersaMax architectures, with intelligent processing handled by the CPU or NIU, delivering 8 words of analog input data for system-level control and analysis. The IC200ALG261 is widely used in process industries, manufacturing automation, and energy systems where reliable voltage monitoring is critical.

The IC200ALG261 also supports flexible installation and grounding options for cable shield connections, ensuring stable signal integrity in electrically noisy environments. Its diagnostics capability includes detection of loss of internal power faults for field-side circuits, enhancing system safety and reliability. Overall, the IC200ALG261 is engineered for precision, durability, and seamless integration in complex industrial control networks.
Revisions

Revision Part #

Also known as

IC200ALG261C
IC200ALG261-C, Series C, Rev C
IC200ALG261D
IC200ALG261-D, Series D, Rev D
IC200ALG261D
IC200ALG261-D, Series D, Rev D
IC200ALG261F
IC200ALG261-F, Series F, Rev F
IC200ALG261H
IC200ALG261-H, Series H, Rev H
IC200ALG261J
IC200ALG261-J, Series J, Rev J
Alternative Names
IC200ALG230 IC200ALG262 IC200ALG320 IC200ALG322 IC200ALG620
Technical notes
The IC200ALG261 8-channel differential analog input module employs a high-resolution 15-bit analog-to-digital converter, achieving an input resolution step of approximately 0.3125 mV over a standard ±10 VDC signal range, making it ideal for precision monitoring applications.
