Features:
- 16 hart detector channels
- 24 v dc detector loops with hart support
- Matched with SAI-1620m safe analog input module
FC-TSGASH-1624 provides HART-enabled gas and flame detector termination in a Honeywell Safety Manager installation.
Its conformal-coated fc construction and the documented 24 V DC detector loops with HART support must match the cabinet and field design.
Verify HART communication, detector supply and readback and the complete connected path before the equipment is released to operation.
The Honeywell FC-TSGASH-1624 16-Channel HART Gas and Flame Detector Input FTA is available for quotation and technical support from Apter Power.
Verified resources for FC-TSGASH-1624:
Signal Data:
- 16 HART detector channels
- 24 V DC detector loops with HART support
- System role: HART-enabled gas and flame detector termination
Use the documented FC-TSGASH-1624 electrical limits when calculating the complete connected circuit.
Diagnostics:
- Hart communication, detector supply and readback
- Check channel and system alarms
- Document normal and fault-state results
Resolve all FC-TSGASH-1624 wiring, power, communication and system diagnostics before release to operation.
Compatibility:
- Matched hardware: SAI-1620m safe analog input module
- Construction: Conformal-coated FC construction
- Confirm firmware and hardware revision
Match FC-TSGASH-1624 to the approved cabinet, cable, termination and field-device arrangement.
Installation Check:
- Verify power, polarity and grounding
- Confirm terminal allocation and cable identification
- Prove the complete end-to-end function
Record the final configuration and all functional-test results after installing FC-TSGASH-1624.
