    Honeywell documentation identifies FS-IOCHAS-0001R as the non-conformal-coated redundant I/O chassis for paired Safety Manager modules.

FS-IOCHAS-0001R

/ 4.9
1001 reviews | Need a Specific Revision?
FS-IOCHAS-0001R is a non-conformal-coated redundant i/o chassis for Honeywell Safety Manager systems.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for FS-IOCHAS-0001R
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FS-IOCHAS-0001R

  • Manufacturer:
    Honeywell
  • Part Number:
    FS-IOCHAS-0001R
  • Product Family:
    Honeywell Safety Systems
  • Product Type:
    Redundant I/O chassis
  • Stock:
    1
  • Configuration:
    Redundant Safety Manager I/O chassis
  • Rack format:
    19-inch, 21-slot housing
  • I/O capacity:
    Up to 9 redundant module pairs
  • I/O slots:
    Slots 1–18 used in odd/even pairs
  • Extender positions:
    IO-0001 in slots 20 and 21
  • Dimensions:
    482.6 mm wide × 280 mm deep
  • Approximate weight:
    8.5 kg
  • Coating:
    Non-conformal-coated FS version
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Safety & Compliance Performance & Efficiency

Product overview:

  • 19-inch redundant Safety Manager I/O chassis
  • Up to nine pairs of redundant I/O modules
  • Two IO-0001 extender positions in slots 20 and 21

FS-IOCHAS-0001R houses redundant I/O modules in paired odd and even slots so each control processor has a defined I/O path.

The chassis includes the redundant backplane and horizontal bus structure required for the paired architecture; slot 19 remains unused.

Verified resources for FS-IOCHAS-0001R:

Verified specifications for FS-IOCHAS-0001R:

  • Configuration: Redundant Safety Manager I/O chassis
  • Rack format: 19-inch, 21-slot housing
  • I/O capacity: Up to 9 redundant module pairs
  • I/O slots: Slots 1–18 used in odd/even pairs
  • Extender positions: IO-0001 in slots 20 and 21
  • Dimensions: 482.6 mm wide × 280 mm deep
  • Approximate weight: 8.5 kg
  • Coating: Non-conformal-coated FS version

Typical applications:

  • Redundant process-safety I/O assemblies
  • Nine-pair Safety Manager I/O expansion
  • 19-inch safety-system cabinet integration

The chassis supports redundant field I/O architectures where separate processor paths and paired module positions are required.

Safety and compliance:

  • Documented approvals: CE, UL, CSA, TÜV and FM
  • Odd and even slots are controlled by separate processor paths
  • Slot 19 is not used

The certified system arrangement depends on correct module pairing, bus routing, power distribution and mechanical installation.

Performance and efficiency:

  • Nine redundant module pairs in one 19-inch chassis
  • Separate 35 mA extender loads on the two 5 V rails
  • 280 mm chassis depth

Paired slot allocation simplifies redundant I/O organization while maintaining separation between the two controller paths.

Description

FS-IOCHAS-0001R is a non-conformal-coated redundant i/o chassis for the Honeywell Safety Manager platform. The non-conformal-coated 19-inch chassis provides 21 positions, with slots 1 through 18 arranged as nine redundant I/O pairs and two IO-0001 extender modules located in slots 20 and 21.

FS-IOCHAS-0001R separates the odd-slot and even-slot I/O paths between Control Processor 1 and Control Processor 2. Verify the backplane, extender modules, bus cables, power distribution, address settings and cabinet space before assembly or replacement.

Alternative Names
FS-IOCHAS-0001R FS IOCHAS 0001R Honeywell FS-IOCHAS-0001R Honeywell FS IOCHAS 0001R Safety Manager FS-IOCHAS-0001R FS-IOCHAS-0001R Redundant I/O chassis FSIOCHAS0001R Redundant I/O chassis Honeywell Safety Manager FS-IOCHAS-0001R
Technical notes
FS-IOCHAS-0001R is the non-conformal-coated 19-inch redundant I/O chassis for nine Safety Manager module pairs. Slots 20 and 21 are reserved for the two IO-0001 extender modules.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How is FS-IOCHAS-0001R integrated into a Safety Manager configuration?
It is used with redundant Safety Manager controllers, paired I/O modules, two IO-0001 extender modules and the matching redundant backplane and bus assemblies.
Which technical interfaces or ratings define FS-IOCHAS-0001R?
The key documented points are Configuration: Redundant Safety Manager I/O chassis; Rack format: 19-inch, 21-slot housing; I/O capacity: Up to 9 redundant module pairs; I/O slots: Slots 1–18 used in odd/even pairs. Confirm these values against the installed chassis and project hardware list.
Which compatibility checks are required before installing FS-IOCHAS-0001R?
Confirm chassis generation, odd/even module pairing, backplane type, two IO-0001 modules, power cables, address jumpers and 19-inch cabinet clearance.
Which slot, bus position or chassis location is specified for FS-IOCHAS-0001R?
Mount it in a 19-inch cabinet with the specified vertical clearance, leave slot 19 unused and install the two extender modules in slots 20 and 21.
What diagnostic symptoms can indicate a FS-IOCHAS-0001R connection or hardware problem?
An incorrect slot map, extender position, backplane connection or power distribution in FS-IOCHAS-0001R can interrupt several I/O channels or defeat the intended redundant/non-redundant architecture. Check the affected slot group and processor path first.
Can FS-IOCHAS-0001R replace a related FS, FC, S or R version directly?
A non-redundant IOCHAS-0001S is not a direct substitute; preserve the redundant backplane, paired modules and controller mapping.
Which commissioning checks should be completed after fitting FS-IOCHAS-0001R?
Confirm chassis address, module slot allocation, IO-0001 position, backplane and horizontal-bus type, 5 V supply path and controller diagnostics after installation.
Which engineering data is needed to match and quote FS-IOCHAS-0001R?
Provide the complete FS-IOCHAS-0001R reference, controller and chassis type, Safety Manager release, slot or bus arrangement, coating requirement, existing hardware revision, required quantity and project approval requirements.
