    Honeywell documentation identifies FS-TERM-0002 as the non-conformal-coated terminator for redundant Safety Manager I/O bus configurations.

FS-TERM-0002

/ 4.9
1001 reviews | Need a Specific Revision?
FS-TERM-0002 is a non-conformal-coated redundant i/o bus terminator for Honeywell Safety Manager systems.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for FS-TERM-0002
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FS-TERM-0002

  • Manufacturer:
    Honeywell
  • Part Number:
    FS-TERM-0002
  • Product Family:
    Honeywell Safety Systems
  • Product Type:
    Redundant I/O bus terminator
  • Stock:
    1
  • Module function:
    Redundant I/O bus termination
  • Bus arrangement:
    I/O bus 1.x and 2.x kept separate
  • Termination network:
    54 resistors, 1 kΩ each
  • Connectors:
    2 × 50-pin SMC female
  • Supply current:
    50 mA from the 5 V DC Control Processor
  • Dimensions:
    19.7 × 38.1 × 7.8 mm
  • Approximate weight:
    4.5 g
  • Coating:
    Non-conformal-coated FS version
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Safety & Compliance Performance & Efficiency

Product overview:

  • Redundant Safety Manager I/O bus termination
  • 54 termination resistors with separated bus sections
  • Two 50-pin SMC female connectors

FS-TERM-0002 completes the signal path at the end of a redundant Safety Manager I/O bus and helps prevent communication errors caused by an unterminated cable path.

The controller software checks for terminator presence, so the correct module and placement should be verified before commissioning or service replacement.

Verified resources for FS-TERM-0002:

Verified specifications for FS-TERM-0002:

  • Module function: Redundant I/O bus termination
  • Bus arrangement: I/O bus 1.x and 2.x kept separate
  • Termination network: 54 resistors, 1 kΩ each
  • Connectors: 2 × 50-pin SMC female
  • Supply current: 50 mA from the 5 V DC Control Processor
  • Dimensions: 19.7 × 38.1 × 7.8 mm
  • Approximate weight: 4.5 g
  • Coating: Non-conformal-coated FS version

Typical applications:

  • Termination of redundant Safety Manager I/O buses
  • Controller and redundant I/O chassis interconnection
  • Maintenance replacement for an existing FS terminator

The module is intended for the physical end of a redundant bus path, not for general signal conditioning or non-redundant I/O termination.

Safety and compliance:

  • Documented approvals: CE, TÜV, UL, CSA and FM
  • Correct terminator presence is checked by system software
  • Bus 1.x and bus 2.x remain separated

Commissioning should include a bus-termination check and confirmation that the installed module matches the Safety Manager project documentation.

Performance and efficiency:

  • Passive termination network
  • 50 mA load from 5 V DC Control Processor supply
  • Compact 19.7 × 38.1 × 7.8 mm construction

Correct termination supports stable bus communication without adding an active processing stage to the redundant I/O path.

Description

FS-TERM-0002 is a non-conformal-coated redundant i/o bus terminator for the Honeywell Safety Manager platform. The module provides the correct end termination for redundant I/O bus cabling and contains 54 termination resistors while maintaining separation between I/O bus 1.x and 2.x.

Use FS-TERM-0002 only with the documented redundant Safety Manager I/O bus arrangement. Confirm that every used I/O bus is terminated, that both 50-pin SMC connections are fully seated and that the non-conformal-coated construction is suitable for the cabinet environment.

Alternative Names
FS-TERM-0002 FS TERM 0002 Honeywell FS-TERM-0002 Honeywell FS TERM 0002 Safety Manager FS-TERM-0002 FS-TERM-0002 Redundant I/O bus terminator FSTERM0002 Redundant I/O bus terminator Honeywell Safety Manager FS-TERM-0002
Technical notes
FS-TERM-0002 is the non-conformal-coated redundant I/O bus terminator with two 50-pin SMC connectors. It must be installed at the documented redundant bus termination point.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How is FS-TERM-0002 integrated into a Safety Manager configuration?
Use it with redundant I/O connected by the documented IOBUS-CPIO or IOBUS-CPIOx flat-cable arrangement.
Which technical interfaces or ratings define FS-TERM-0002?
The key documented points are Module function: Redundant I/O bus termination; Bus arrangement: I/O bus 1.x and 2.x kept separate; Termination network: 54 resistors, 1 kΩ each; Connectors: 2 × 50-pin SMC female. Confirm these values against the installed chassis and project hardware list.
Which compatibility checks are required before installing FS-TERM-0002?
Verify redundant bus topology, connector type, terminator position, controller generation and the cabinet coating requirement.
Which slot, bus position or chassis location is specified for FS-TERM-0002?
It is fitted at the required termination position on the redundant I/O bus path, with both 50-pin connectors aligned and fully engaged.
What diagnostic symptoms can indicate a FS-TERM-0002 connection or hardware problem?
Missing, incorrect or poorly seated FS-TERM-0002 termination can create I/O bus reflections, communication errors and a terminator diagnostic from the control processor. Inspect both 50-pin connections and confirm the required bus-end position.
Can FS-TERM-0002 replace a related FS, FC, S or R version directly?
Do not substitute a TERM-0001 non-redundant terminator; confirm the redundant bus configuration and coating version before replacement.
Which commissioning checks should be completed after fitting FS-TERM-0002?
Verify terminator detection in system diagnostics, continuity of both redundant paths, cable seating and separation of I/O bus 1.x and 2.x before returning the system to service.
Which engineering data is needed to match and quote FS-TERM-0002?
Provide the complete FS-TERM-0002 reference, controller and chassis type, Safety Manager release, slot or bus arrangement, coating requirement, existing hardware revision, required quantity and project approval requirements.
