MU-TAMT03 51309223-125

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell MU-TAMT03 51309223-125 is a LLMux Thermocouple Field Termination Assembly. It terminates sixteen low-level thermocouple channels for one LLMux unit.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for MU-TAMT03 51309223-125
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MU-TAMT03 51309223-125

  • Manufacturer:
    Honeywell
  • Part Number:
    MU-TAMT03 51309223-125
  • Product Family:
    Honeywell TDC 3000
  • Product Type:
    Thermocouple Field Termination Assembly
  • Stock:
    1
  • Assembly:
    LLMux thermocouple FTA with local cold-junction reference
  • Field terminals:
    Compression terminals
  • IOP interface:
    Single IOP
  • System capacity:
    Up to 16 thermocouple channels per LLMux unit
  • Channel allocation:
    Unit 0: channels 1-16; Unit 1: channels 17-32 in a two-unit arrangement
  • Compliance execution:
    CE-designated hardware in the official LLMux table
  • Weight:
    0.76 kg
  • Estimated shipping dimensions:
    12.1x5x30.8cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Temperature & Humidity Range Compatibility Installation & Integration

Features:

  • Terminates sixteen low-level thermocouple channels for one LLMux unit.
  • Provides a local cold-junction reference for compensated temperature conversion.
  • Uses compression terminals with a single I/O processor interface.
The assembly terminates low-level thermocouple circuits and provides the local cold-junction reference required by the LLMux temperature-measurement path.

Thermocouple millivolt signals and the local reference temperature are routed to the LLMux electronics. The processor compensates the cold junction and converts each channel to the configured engineering temperature.

Maintain thermocouple alloy continuity and polarity through the compression terminals, keep the local cold-junction reference in the intended cabinet environment, and verify unit addressing before commissioning.

Availability is reviewed against the exact MU-TAMT03 51309223-125 order identity and requested supply condition; manufacturer lifecycle status: Discontinued / Obsolete by OEM.
Verified resources for Honeywell MU-TAMT03 51309223-125:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • The FTA works with the LLMux I/O processor and power adapter. A single unit handles the first sixteen channels; the documented second unit extends the installation to channels 17-32.
  • It supports concentrated thermocouple acquisition for furnaces, reactors, rotating equipment and utility systems where the field signals are too small to tolerate careless grounding or routing.
  • Requires correct thermocouple polarity, alloy continuity and cabinet placement.
  • Terminates thermocouple circuits and provides the local cold-junction reference.
  • Routes thermocouple millivolts and reference temperature to LLmux electronics.
  • Processor applies cold-junction compensation before calculating engineering temperature.
  • Supports up to 16 thermocouple channels per LLMux unit.
  • Uses compression terminals for field thermocouple connections.
  • Part-number identity must match the documented FTA execution.
  • Maintain the thermocouple alloy continuity and polarity through every connection.
  • Keep the cold-junction reference within the intended cabinet environment.
  • The first unit covers channels 1–16, while a second extends coverage to 17–132.
Description
Honeywell MU-TAMT03 51309223-125 The assembly terminates low-level thermocouple circuits and provides the local cold-junction reference required by the LLMux temperature-measurement path. Thermocouple millivolt signals and the local reference temperature are routed to the LLMux electronics. The processor compensates the cold junction and converts each channel to the configured engineering temperature.

The FTA works with the LLMux I/O processor and power adapter. A single unit handles the first sixteen channels; the documented second unit extends the installation to channels 17-32. It supports concentrated thermocouple acquisition for furnaces, reactors, rotating equipment and utility systems where the field signals are too small to tolerate careless grounding or routing.

Maintain thermocouple alloy continuity and polarity through the compression terminals, keep the local cold-junction reference in the intended cabinet environment, and verify unit addressing before commissioning.
Alternative Names
MU-TAMT03 51309223-125 MU TAMT03 51309223 125 MUTAMT0351309223125 MU-TAMT03-51309223-125 Honeywell MU-TAMT03 51309223-125 Honeywell MU TAMT03 51309223 125 Honeywell MUTAMT0351309223125 Honeywell LLMux Thermocouple Field Termination Assembly
Technical notes
Thermocouple alloy continuity, polarity, local cold-junction reference placement, and LLMux unit addressing must all be maintained when Honeywell MU-TAMT03 51309223-125 is commissioned.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does Honeywell MU-TAMT03 51309223-125 support thermocouple measurement?
The assembly terminates low-level thermocouple circuits and provides the local cold-junction reference required by the LLMux temperature-measurement path.
Which complete model and part identity confirms Honeywell MU-TAMT03 51309223-125?
The manufacturer data specifies Part number as 51309223-125; the installed arrangement must match that exact value.
How is cold-junction compensation supported by Honeywell MU-TAMT03 51309223-125?
Thermocouple millivolt signals and the local reference temperature are routed to the LLMux electronics. The processor compensates the cold junction and converts each channel to the configured engineering temperature.
What alloy and polarity checks protect Honeywell MU-TAMT03 51309223-125?
Maintain thermocouple alloy continuity and polarity through the compression terminals, keep the local cold-junction reference in the intended cabinet environment, and verify unit addressing before commissioning.
What procurement limits follow the Honeywell MU-TAMT03 51309223-125 phase-out?
The page records Active / Available from OEM. Apter Power reviews the exact order identity and condition without presenting this as an OEM delivery promise.
Which thermocouple allocation records identify Honeywell MU-TAMT03 51309223-125?
Submit the complete nameplate, Channel allocation (Unit 0: channels 1-16; Unit 1: channels 17-32 in a two-unit arrangement), installed system evidence, condition, quantity and destination so the document and quotation match MU-TAMT03 51309223-125.
