MC-IOLX02 51304419-150

/ 4.9
1001 reviews | Need a Specific Revision?
The Honeywell MC-IOLX02 51304419-150 is a standard I/O link extender card used in Honeywell TPS and TDC 3000 systems to enable long-distance communication between controllers and remote I/O modules. It supports fiber-optic based I/O Link extension for distributed process control architectures.
Get a quick price for MC-IOLX02 51304419-150
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MC-IOLX02 51304419-150

  • Manufacturer:
    Honeywell
  • Part Number:
    MC-IOLX02 51304419-150
  • Product Family:
    Honeywell TPS Series
  • Product Type:
    Standard I/O Link Extender Card
  • Fiber Link Length:
    1.2 km
  • Fiber Size:
    62.5/125 µm
  • Wave Length:
    820 nanometers
  • Fiber Power Budget Over-Temperature Range:
    5.5 dB
  • Compatible Controllers:
    PM, APM, HPM, EHPM
  • Operating Temperature:
    -40°C to +70°C
  • Protection Rating:
    With G3-level Conformal Coating
  • Compliance Certifications:
    CE, TUV, UL508, CSA
  • Weight:
    0.58 kg
  • Estimated shipping dimensions:
    3x31.8x28m
  • Tariff Code:
    3912310000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Operation Installation Application Scenarios

Features:

  • Fiber-optic I/O Link extension enables long-distance communication between control and remote I/O sites
  • Multi-controller compatibility supports PM, APM, HPM, and EHPM system architectures
  • Industrial-grade environmental design with wide temperature range and protective coating
The Honeywell MC-IOLX02 51304419-150 is a Standard I/O Link Extender Card used in Honeywell TPS and TDC 3000 distributed control systems. It provides fiber-optic communication capability between controllers and remote I/O modules. The Honeywell MC-IOLX02 51304419-150 is designed to support extended system architectures requiring distributed I/O placement.

In process control environments, the Honeywell MC-IOLX02 51304419-150 enables remote installation of I/O processors and field termination assemblies. It supports fiber-based communication links with defined parameters such as 1.2 km link length and 820 nanometer wavelength. The Honeywell MC-IOLX02 51304419-150 allows system expansion across multiple remote card files within a structured control network.

The Honeywell MC-IOLX02 51304419-150 is compatible with PM, APM, HPM, and EHPM controllers used in Honeywell distributed control platforms. It operates within a wide temperature range from -40°C to +70°C and includes G3-level conformal coating protection. The Honeywell MC-IOLX02 51304419-150 supports reliable system communication in fiber-based I/O Link configurations across industrial environments.

The MC-IOLX02 51304419-150 Honeywell Standard I/O Link Extender Card may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell MC-IOLX02 51304419-150 Standard I/O Link Extender Card Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Honeywell MC-IOLX02 51304419-150 Standard I/O Link Extender Card Specs

General

  • Manufacturer Honeywell
  • Model MC-IOLX02 51304419-150
  • Condition New Original ready stock
  • Product Family MC-ILDX03,MC-IOLM02
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Link Health Diagnosis: Onboard status LEDs provide real-time feedback on the physical layer status of the communication link, helping operators intuitively determine whether the link is active or interrupted.
  • Automatic Redundancy Switching: During operation, if link A suffers physical damage, the expansion card can work with the system to automatically switch to link B within milliseconds, ensuring uninterrupted control logic.
  • Wide Temperature Range: Designed for industrial-grade operating environments, it supports continuous operation in extremely high or low cabinet environments, reducing reliance on precision air conditioning.
  • Transparent Data Forwarding: The data frame structure remains unchanged during operation, achieving "zero-latency" transparent communication between the controller and field modules, ensuring the accuracy of process control.
  • Standardized Slots: Utilizing a standard HPM card physical structure, it can be directly inserted into the controller's standard rack (file) without additional mechanical modifications.
  • Hot-Swap Support: The design allows module replacement without interrupting the system's main power supply, significantly simplifying emergency maintenance operations during production operation.
  • Automatic Address Identification: Node identification is achieved through physical location on the backplane or simple hardware jumpers, eliminating the need for complex low-level software programming.
  • Solid Terminal Connection: Equipped with a dedicated I/O link interface, supporting a highly reliable connector locking mechanism to effectively prevent wiring loosening caused by industrial vibration.
  • Remote Rack Interconnection: Specifically designed for physical connections between Process Manager (PM/APM/HPM) controller racks and remote I/O racks, breaking the spatial limitations of traditional cabling.
  • Distributed Architecture Expansion: In large-scale oil refineries, pharmaceutical plants, and other factories requiring cross-regional I/O deployment, it serves as a core link extension component, enabling centralized control of remote field signals from the control center.
  • Fiber Optic Isolated Transmission: When used with a fiber optic link converter, it can achieve signal transmission over several kilometers and provides a natural barrier against lightning strikes and electromagnetic interference for the control system.
  • Deployment in Harsh Industrial Environments: This module model features a "CC" (Conformal Coating) protective coating, suitable for chemical production plants with high corrosive gas content.
Description
The Honeywell MC-IOLX02 51304419-150 is a standard I/O link extender card designed for use in Honeywell process control systems such as PM, APM, and HPM. It is implemented within TPS (TotalPlant Solution) and TDC 3000 architectures to extend communication between controllers and remote I/O modules. The Honeywell MC-IOLX02 51304419-150 operates as part of a fiber-optic I/O Link extension system.

In system configuration, the Honeywell MC-IOLX02 51304419-150 supports remote I/O installations across multiple sites, allowing distributed I/O processors and field termination assemblies to be located away from the main control area. The Honeywell MC-IOLX02 51304419-150 is used in redundant fiber-optic cable configurations to maintain stable data communication across extended distances.

The fiber link specifications associated with the Honeywell MC-IOLX02 51304419-150 include a fiber link length of 1.2 km, fiber size of 62.5/125 µm, and a wave length of 820 nanometers. The Honeywell MC-IOLX02 51304419-150 also specifies a fiber power budget over temperature range of 5.5 dB for communication performance considerations.

From an environmental perspective, the Honeywell MC-IOLX02 51304419-150 operates within a temperature range of -40°C to +70°C. It is supported by G3-level conformal coating for protection. The Honeywell MC-IOLX02 51304419-150 is compatible with PM, APM, HPM, and EHPM controllers used in Honeywell distributed control systems.

The Honeywell MC-IOLX02 51304419-150 is defined as a Standard I/O Link Extender Card used in I/O Link Interface Module configurations. It supports system architectures where multiple remote card files are interconnected, enabling structured data exchange between local and remote I/O subsystems within Honeywell TPS and TDC 3000 environments.
Alternative Names
MU-IOLX02 MU-IOLM02 MU-ILDX03 MU-ILES01 MC-IOLM02 MC-ILDX03
Technical notes
Honeywell MC-IOLX02 51304419-150 Standard I/O Link Extender Card, fiber link length 1.2 km, fiber size 62.5/125 µm, wave length 820 nanometers, fiber power budget over-temperature range 5.5 dB, compatible with PM, APM, HPM, EHPM controllers, operating temperature -40°C to +70°C, G3-level conformal coating protection, used in Honeywell TPS and TDC 3000 systems for I/O Link extension between controllers and remote I/O modules.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the primary function of the MC-IOLX02 card?
It extends I/O Link communication between controllers and remote I/O modules in Honeywell TPS and TDC 3000 systems.
How does MC-IOLX02 support remote I/O installation?
It allows I/O processors and field termination assemblies to be placed at remote sites connected via fiber optic links.
What types of controllers are compatible with MC-IOLX02?
It is compatible with PM, APM, HPM, and EHPM controller systems.
How is the I/O Link structured in multi-site configurations?
It allows up to six remote sites connected through IOLE pairs, supporting distributed I/O architecture.
