FBM214E

/ 4.9
1001 reviews | Need a Specific Revision?
Foxboro FBM214E is a Compact 16-channel 4–20 mA input interface that communicates with supported HART field devices.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for FBM214E
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FBM214E

  • Manufacturer:
    Invensys
  • Part Number:
    FBM214E
  • Product Family:
    Foxboro
  • Product Type:
    Compact 16-Channel HART Communication Input Interface Module
  • Stock:
    1
  • Input channels:
    16
  • Signal:
    4 to 20 mA with or without HART
  • HART communication:
    All 16 channels
  • Internal loop supply:
    24 VDC ±15%, one field device per channel
  • Input resistance:
    279 Ω external-power TA; 298 Ω internal-power TA
  • Control software:
    Control Core Services v9.5 or later
  • Power consumption:
    15 W maximum
  • Heat dissipation:
    8 W maximum
  • Dimensions:
    2.5 × 13.0 × 15.0 cm
  • HART support:
    Versions 5, 6 and 7
  • Input range:
    0 to 20.5 mA
  • Loop power current limit:
    Less than 33 mA
  • Isolation test:
    600 VAC for 1 minute between the group-isolated channels and ground
  • Operating temperature:
    -20 to +60°C
  • Storage temperature:
    -40 to +85°C
  • Relative humidity:
    5 to 95%, non-condensing
  • Vibration:
    0.75 g from 5 to 500 Hz
  • Weight:
    0.227 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals HART Integration Power Selection System Compatibility Application
  • Use FBM214E only where the Compact 16-channel HART architecture is required
  • Select RH101RT for external loop power or RH101RY for FBM auxiliary loop power
  • Confirm Control Core Services v9.5 or later before commissioning

Foxboro FBM214E is the functional designation for a Compact 16-channel HART communication input interface.

The current module order number is RH101RP; RH101RT and RH101RY identify different termination assemblies, not substitute module numbers.

Before replacement, confirm the exact module label, TA power arrangement, field-loop design, baseplate position and saved HART device configuration.

Availability, condition, price, and shipping time for FBM214E are confirmed during quotation.

Foxboro FBM214E Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Sixteen 4–20 mA channels support HART communication
  • One field device is supported per internally powered channel
  • Device diagnostics remain available through the control-system tools
  • RH101RT is used for customer-supplied external loop power
  • RH101RY uses the FBM auxiliary 24 VDC source
  • TA choice must match grounding and loop-power architecture
  • The module requires a Compact 200 Series baseplate
  • Control Core Services v9.5 or later is documented
  • Fieldbus communication uses the redundant 2 Mbps Module Fieldbus
  • HART-enabled process transmitter input
  • Centralized 4–20 mA measurement with field-device diagnostics
  • Compact DCS analog input migration using the documented FBM214E TA
Description
Foxboro FBM214E receives 4–20 mA process signals and exchanges HART data with up to sixteen supported field devices.

The module isolates its input group from module logic and ground while the matching TA determines whether loop power comes from an external supply or the FBM auxiliary 24 VDC source.

It supports process measurement together with HART diagnostics and configuration in Compact 200 Series installations using compatible Control Core Services software.
Alternative Names
FBM214E FBM 214E Foxboro FBM214E Invensys Foxboro FBM214E Compact FBM214E Foxboro Evo FBM214E Invensys FBM214E
Technical notes
FBM214E is an official functional designation, while RH101RP is the current exact module order number. Do not enter RH101RY as the module; RH101RY is the internal-power termination assembly.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which exact module should be supplied when a customer requests Foxboro FBM214E?
Confirm the label and quotation against RH101RP, the official current module part number, and identify the required termination assembly separately.
Can Foxboro FBM214E power every connected HART transmitter internally?
Only with the documented RH101RY internal-power TA and within its loop limits. Externally powered loops use RH101RT instead.
Can Foxboro FBM214E be installed in a standard 200 Series modular baseplate?
No. The official module mounts on a Compact 200 Series 16-slot horizontal baseplate, so the platform must be checked before replacement.
Why can Foxboro FBM214E show current but no HART communication?
Check the TA type, loop resistance, field-device HART support, polarity, wiring quality, channel configuration and the device diagnostic status.
Does Foxboro FBM214E isolate every channel from every other channel?
No. The channels are isolated as a group from ground and module logic, not individually from one another, so common-mode and grounding design still matter.
Which HART configuration records should be saved before removing Foxboro FBM214E?
Save channel scaling, HART device assignments, diagnostics, alarm configuration, TA power arrangement, slot location and the current Control Core Services database.
How should Foxboro FBM214E be recommissioned?
Verify loop current and HART communication on each channel, compare device tags and diagnostics with the backup, then prove alarms and control actions under controlled conditions.
