        FBM217

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Foxboro FBM217 is a 32-channel discrete input module used for contact-sense and voltage-monitor signals through a selected termination assembly.
        In Stock
        Ships by Saturday, October 17
        Fast Shipping Available
        Get a quick price for FBM217
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for FBM217

        • Manufacturer:
          Invensys
        • Part Number:
          FBM217
        • Product Family:
          Foxboro
        • Product Type:
          Thirty-Two-Channel Discrete Input Module
        • Stock:
          1
        • Discrete input channels:
          32
        • Supported signal classes:
          30 VDC, 125 VDC, 120 VAC or 240 VAC, depending on TA
        • Filter/debounce:
          None, 4, 8, 16 or 32 ms
        • Maximum pulse-count rate:
          250 Hz
        • Redundant adapter:
          RH926ZY
        • Baseplate-to-TA cable:
          Type 4, up to 30 m
        • Dimensions:
          4.5 × 10.2 × 10.4 cm
        • Operating temperature:
          -20 to +70°C
        • Storage temperature:
          -40 to +70°C
        • Relative humidity:
          5 to 95%, non-condensing
        • Vibration:
          0.75 g from 5 to 500 Hz
        • Weight:
          0.284 kg
        • Tariff Code:
          8538900000
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals TA Selection Input Behavior Redundant Service Application
        • Handles 32 discrete field inputs through a selected TA
        • Choose the TA for the actual voltage and contact-sense method
        • Match filtering, redundancy and field power before installation

        FBM217 is selected for high-density discrete status acquisition where the termination assembly defines the field-voltage interface.

        The electronic module alone does not determine whether the installation monitors 30 VDC, 125 VDC, 120 VAC or 240 VAC inputs.

        Before replacement, document the main and expansion TAs, cable types, wetting supply, isolation groups and any RH926ZY redundant adapter.

        Availability, condition, price, and shipping time for FBM217 are confirmed during quotation.

        Foxboro FBM217 Manuals, Datasheets, Links

        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        • Choose the TA from the actual field voltage and sensing method
        • Confirm group isolation and external excitation needs
        • Keep main and expansion TA identities with the asset record
        • Configure debounce for the connected contact or sensor
        • Use pulse counting only within the documented rate
        • Verify wetting voltage and commons before software changes
        • Install RH926ZY only for the documented redundant arrangement
        • Check master and tracker health before maintenance
        • Prove all 32 points after a controlled switchover
        • High-density status and contact acquisition
        • Mixed-voltage discrete monitoring through selected TAs
        • Redundant Foxboro discrete input service
        Description
        Foxboro FBM217 converts 32 field contact or voltage states into data for the redundant Module Fieldbus.

        Selected TAs provide current limiting, high-voltage attenuation, optical isolation and field-power connections appropriate to the actual signal class.

        Configurable filtering supports stable state detection, while sequence-of-events and pulse-count functions can be assigned where the control database requires them.
        Alternative Names
        FBM217 FBM 217 Foxboro FBM217 Invensys Foxboro FBM217 I/A Series FBM217 Foxboro Evo FBM217 Invensys FBM217
        Technical notes
        FBM217 is the Foxboro DCS functional designation; RH914TR is the current electronic-module part number. Input voltage, isolation and field wiring depend on the selected TA, so verify the module, TA, cable and controller configuration before replacement.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        How should a buyer select the correct TA for Foxboro FBM217?
        Match the field signal class, contact-sense or voltage-monitor method, wetting supply, isolation groups, terminal style and required certifications to the official TA table.
        Can Foxboro FBM217 accept 30 VDC and 240 VAC directly on the same TA?
        Do not infer that from the module name; the installed TA defines the permitted signal class and channel arrangement.
        When is the RH926ZY adapter required with Foxboro FBM217?
        Use the documented redundant adapter when the system design uses a redundant FBM217 module pair connected to the termination assembly.
        Why can one input group on Foxboro FBM217 fail while others operate?
        Check that group’s TA circuitry, field supply or wetting voltage, common, cable path and database mapping because isolation and power are TA-dependent.
        How should filter time be chosen for Foxboro FBM217?
        Set the shortest value that rejects the real contact bounce or electrical noise without hiding required pulses or delaying protection and sequence logic.
        What should be recorded before replacing Foxboro FBM217?
        Record RH914TR or legacy module identity, baseplate slot, main and expansion TAs, cable numbers, field voltages, group commons, filter settings and redundancy state.
        What acceptance test is required for Foxboro FBM217?
        Exercise all 32 inputs using their real signal classes, verify polarity and group isolation, confirm filter and event behavior, then test redundant recovery where installed.
