    Apter Power provides quotations, official documents, migration review, and DH485 system-matching support for ProSoft A-DH485R/B.

A-DH485R/B

/ 4.9
1001 reviews | Need a Specific Revision?
The ProSoft A-DH485R/B DH485 Router provides intelligent routing between EtherNet/IP and DH485 for controller migration, programming, and serial integration.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for A-DH485R/B
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for A-DH485R/B

  • Manufacturer:
    ProSoft
  • Part Number:
    A-DH485R/B
  • Product Family:
    ProSoft
  • Product Type:
    DH485 Router
  • Stock:
    1
  • Ethernet Connector:
    RJ45
  • Ethernet Conductors:
    CAT5 STP/UTP
  • ARP Connections:
    40 maximum
  • TCP Connections:
    40 maximum
  • CIP Connections:
    10 maximum
  • Ethernet Rate:
    10/100 Mbps
  • Duplex Mode:
    Full or Half
  • Auto-MDIX:
    Supported
  • Controller Support:
    ControlLogix, CompactLogix, MicroLogix, SLC
  • Embedded Switch:
    2 Ethernet ports
  • Serial Connector:
    9-way shared terminal
  • Serial Interfaces:
    RS232 and RS485
  • RS232 Isolation:
    1000 VDC
  • RS485 Isolation:
    1500 Vrms for 1 minute
  • Serial Baud Rates:
    1200 to 115200 bps
  • Parity:
    None, Even, Odd
  • Transparent Mode Mappings:
    20 maximum
  • Logix Tag Mode Mappings:
    20 maximum
  • Power Supply:
    10 to 32 VDC; 67 mA at 24 VDC
  • Power Consumption:
    1.7 W; 173 mA maximum
  • Enclosure:
    IP20, NEMA/UL Open Type; indoor use
  • Operating Temperature:
    -20 to 70 °C
  • Relative Humidity:
    5 to 90% RH, non-condensing
  • Altitude:
    Below 2000 m
  • Estimated shipping dimensions:
    149.0 x 34.0 x 116.0 mm
  • Tariff Code:
    8517623990
  • Country of origin:
    United States
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Routing Modes Configuration Diagnostics

Features:

  • Intelligent routing between EtherNet/IP and DH485
  • AIC Mode conversion between RS485 and RS232
  • Transparent PCCC access for SLC5/03 programming
Legacy DH485 equipment can be reached from an Ethernet-based Logix architecture through the A-DH485R/B Series B router. The unit is also suitable for remote SLC5/03 programming over Ethernet.

Routing Table, Transparent PCCC, and AIC modes address different migration needs. AIC operation converts between RS-485 and RS-232, while mapped routing can direct DH485 destination nodes and data files toward configured Logix controllers.

Select the operating mode before building the Slate project, then confirm node addresses, serial wiring, Ethernet routes, and controller ownership. Packet displays in the webserver provide useful evidence when a mapped destination does not respond.
Migration documentation and system-matching support for the ProSoft A-DH485R/B DH485 Router can be obtained from Apter Power.
ProSoft A-DH485R/B DH485 Router Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ProSoft A-DH485R/B DH485 Router Specs

General

  • ManufacturerProSoft Technology
  • ModelA-DH485R/B
  • ConditionNew Original ready stock
  • Product FamilyDH485 Router
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

DH485 routing and migration functions

  • Transparent mode: AIC Mode converts between RS485 and RS232
  • Routing table: Transparent PCCC supports SLC5/03 programming
  • AIC mode: DH485 destination and data-file mapping routes traffic
  • Controller access: Logix-owned and standalone operation are supported

Slate project and network settings

  • Configuration utility: Slate Configuration Utility defines router settings
  • Node mapping: Mapping table supports up to eight Logix controllers
  • Ethernet setup: Reactive and Scheduled tag mapping are supported
  • Project backup: Built-in webserver displays configuration and packets

DH485 and Ethernet fault indicators

  • Assembly status: Input and output assemblies expose Logix diagnostics
  • Web diagnostics: Webserver shows system status and DH485 packets
  • Traffic visibility: Ethernet and serial activity can be checked separately
  • Port isolation: Isolated serial ports help separate network segments
Description
The A-DH485R/B is a ProSoft DH485 Router that provides intelligent data routing between EtherNet/IP and DH485. It is intended to simplify migration from MicroLogix and SLC systems with DH485 communications to EtherNet/IP-based ControlLogix or CompactLogix platforms. The router can also support remote programming of an SLC5/03 controller through Ethernet. A mapping table uses the DH485 destination node address and, in applicable modes, the data file address to direct traffic to as many as eight Logix controllers.

The A-DH485R/B includes AIC Mode for direct conversion between RS485 and RS232, making it suitable as a functional replacement for the Rockwell 1761-NET-AIC in supported applications. Transparent PCCC mode permits programming and connection to SLC5/03 controllers, while Direct-To-Tag technology supports Logix integration. Reactive tag mapping and Scheduled tag mapping cover slave and master-style exchanges, and PLC5/SLC mapping is supported. PanelView Plus and PV800 terminals can be interfaced from Ethernet to the supported serial networks.

The A-DH485R/B can operate in Logix-owned or standalone mode. When a Logix connection is used, input and output assemblies make additional diagnostic information available in the controller environment. Its isolated RS232 and RS485 interfaces share a nine-way terminal, while two Ethernet ports can form a Device Level Ring or an embedded switch. Slate Configuration Utility and the built-in webserver provide configuration, troubleshooting, received-packet display, and detailed operating diagnostics.
Revisions

Revision Part #

Also known as

A-DH485R Ser B
A-DH485R/B, Series B, Rev B
Alternative Names
A-DH485R-B A DH485R B ADH485RB ProSoft A-DH485R/B ProSoft Technology A-DH485R/B Aparian A-DH485R/B A-DH485R/B Datasheet A-DH485R/B Manual
Technical notes
A-DH485R/B is a ProSoft DH485 Router for industrial network integration. Verify protocol roles, controller compatibility, power, and environmental limits in the official documentation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can A-DH485R/B connect my SLC or MicroLogix system to EtherNet/IP?
A-DH485R/B supports intelligent routing among compatible Logix, SLC, and MicroLogix controllers; verify the selected routing mode and controller firmware.
Can A-DH485R/B replace a 1761-NET-AIC?
A-DH485R/B provides AIC Mode for direct RS485-to-RS232 conversion, but wiring, baud rate, and application behavior must be reviewed before replacement.
How is A-DH485R/B configured?
A-DH485R/B is configured with Slate Configuration Utility; define Ethernet settings, DH485 parameters, controller connections, and the required mapping table.
What should I check when A-DH485R/B is not communicating?
A-DH485R/B troubleshooting should start with Ethernet link, DH485 node address, baud rate, parity, serial wiring, mapping status, and webserver diagnostics.
Can A-DH485R/B program an SLC5/03 remotely?
A-DH485R/B supports remote SLC5/03 programming over Ethernet when Transparent PCCC mode and the supported communication path are configured correctly.
Where is the official A-DH485R/B documentation?
A-DH485R/B official ProSoft datasheet is the first link in the Manuals tab; use the current official user manual for installation and commissioning.
What information is needed to quote A-DH485R/B?
A-DH485R/B enquiries should include quantity, controller models, DH485 topology, serial interface, required operating mode, and delivery destination.
