MVI56E-GSC

/ 4.9
1001 reviews | Need a Specific Revision?
ProSoft MVI56E-GSC is a Generic ASCII Serial Enhanced Communication Module. It adds two configurable ASCII serial communication ports to ControlLogix.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for MVI56E-GSC
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MVI56E-GSC

  • Manufacturer:
    ProSoft
  • Part Number:
    MVI56E-GSC
  • Product Family:
    ProSoft
  • Product Type:
    Generic ASCII Serial Enhanced Communication Module
  • Stock:
    1
  • Configuration Ports:
    10/100Mb Ethernet
  • Serial Ports:
    2 ASCII ports (RS-232/422/485)
  • Support:
    Up to 4096 characters or bytes per port
  • Power Supply:
    Typical 800mA @5VDC; 3mA @24VDC
  • Mounting Slots:
    Single slot, backplane compatible with ControlLogix racks
  • Weight:
    0.26 kg
  • Estimated shipping dimensions:
    3.5x14x14.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications ASCII Data Serial Ports Diagnostics

Features:

  • Two independently configurable ASCII serial ports
  • Character strings or byte streams up to 4096 bytes per port
  • 110 baud to 115.2 kbps communication range
MVI56E-GSC provides two general-purpose serial channels for ControlLogix applications that exchange non-specific ASCII text or binary byte streams.

Each port is configured independently for transmit and receive behavior, packet termination, electrical standard, framing, and hardware handshaking.

Before commissioning, define the expected message boundaries and maximum length, select RS-232, RS-422, or RS-485 jumpers, and validate the controller transfer logic.

The ProSoft MVI56E-GSC Generic ASCII Serial Enhanced Communication Module is listed as Active / Available from OEM. Apter Power supports serial-interface review and sourcing.

ProSoft MVI56E-GSC Generic ASCII Serial Enhanced Communication Module Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ProSoft MVI56E-GSC Generic ASCII Serial Enhanced Communication Module Specs

General

  • ManufacturerProSoft Technology
  • ModelMVI56E-GSC
  • ConditionNew Original ready stock
  • Product FamilyControlLogix Communication Module

Message assembly and transfer

  • Payload length: Each port can send or receive strings and byte streams up to 4096 characters or bytes.
  • Stream mode: Continuous data can be received without a packet terminator when stream operation is selected.
  • Character termination: One or more configured characters can mark the end of a received message.
  • Timeout methods: Message-length and inter-character timers provide additional packet completion options.

Independent channel setup

  • Port count: P1 and P2 are separate serial application ports with individual settings.
  • Electrical modes: Each channel can be jumper-selected for RS-232, RS-422, or RS-485.
  • Baud setting: The documented rate range extends from 110 baud to 115.2 kbps.
  • Hardware control: RS-232 handshaking supports modem, radio, and multidrop applications.

Enhanced maintenance tools

  • Ethernet service: The 10/100 Base-T port is used for configuration and diagnostic access.
  • Display feedback: A four-character scrolling display presents module, IP, port, and error information.
  • Controller status: Port receive and transmit states, counts, and errors are returned to the processor.
  • Remote access: CIPconnect supports diagnostic paths through compatible EtherNet/IP and ControlNet bridges.
Description
The MVI56E-GSC is a high-performance serial communication module designed by ProSoft specifically for the ControlLogix platform. It aims to provide two fully configurable ASCII serial communication ports without occupying controller front-end ports or consuming excessive controller processing resources.

The MVI56E-GSC features a single-slot, backplane-compatible design and can be installed in a ControlLogix rack. Each communication port supports sending and receiving ASCII strings or byte streams up to 4096 characters or bytes.

The MVI56E-GSC is suitable for scenarios requiring the integration of multiple ASCII serial devices (such as printers, barcode scanners, robots, machine tools, and legacy PLCs) into a ControlLogix control system. Its powerful configuration and diagnostic functions, as well as its ability to transmit large amounts of serial data, make it an ideal choice for upgrading and modernizing industrial communication systems.
Alternative Names
MVI56E GSC MVI56EGSC ProSoft MVI56E-GSC PST MVI56E-GSC MVI56E-GSC ControlLogix Communication Module MVI56E-GSC Communication Module MVI56E-GSC Datasheet MVI56E-GSC Manual
Technical notes
MVI56E-GSC Generic ASCII Serial Enhanced Communication Module adds two configurable ASCII serial communication ports to ControlLogix. Verify ASCII Data, Serial Ports, Diagnostics settings against the official ProSoft documentation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What type of serial data can MVI56E-GSC process?
MVI56E-GSC exchanges non-specific ASCII character strings or byte-value streams with serial devices.
How many application ports are included on MVI56E-GSC?
MVI56E-GSC provides two independently configurable serial application ports.
What is the maximum message size for MVI56E-GSC?
Each MVI56E-GSC port can transmit or receive up to 4096 characters or bytes.
Which packet termination methods does MVI56E-GSC support?
MVI56E-GSC supports stream mode, configured terminators, message timeout, inter-character timeout, and packet-size limits.
How should MVI56E-GSC port wiring be selected?
For MVI56E-GSC, set each hardware jumper and configuration for the required RS-232, RS-422, or RS-485 interface.
What diagnostics are available for MVI56E-GSC?
MVI56E-GSC reports port states and counters to ControlLogix and provides Ethernet access plus a scrolling diagnostic display.
Where can MVI56E-GSC documentation and quotation support be requested?
The MVI56E-GSC Manuals tab includes the official datasheet, and Apter Power can assist with configuration review and quotation.
