          Apter Power supports 6DL1131-6BL00-0PH1 quotations, manuals, terminal-block checks, and exact-module matching.

        6DL1131-6BL00-0PH1

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The 32-channel Siemens 6DL1131-6BL00-0PH1 is an ET 200SP HA digital input module that brings 24 V field states and channel diagnostics into distributed control.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for 6DL1131-6BL00-0PH1
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 6DL1131-6BL00-0PH1

        • Manufacturer:
          Siemens
        • Part Number:
          6DL1131-6BL00-0PH1
        • Product Family:
          Siemens Simatic ET 200SP
        • Product Type:
          SIMATIC ET 200SP HA DI 32x24VDC Digital Input Module
        • Stock:
          1
        • Digital Inputs:
          32
        • Input Type:
          24 V DC, source/sink P-reading
        • IEC Input Characteristic:
          Type 1 and Type 3
        • Rated Supply Voltage:
          24 V DC
        • Permissible Supply Range:
          19.2 to 28.8 V DC
        • Reverse-Polarity Protection:
          Yes
        • Typical Module Current:
          11.5 mA
        • Maximum Module Current:
          15 mA
        • Typical Power Loss:
          1.6 W
        • Maximum Power Loss:
          2.8 W
        • Input Signal 0:
          -30 to +5 V DC
        • Input Signal 1:
          +11 to +30 V DC
        • Typical Input Current:
          2.5 mA
        • Two-Wire Sensor Current:
          Up to 1.5 mA
        • Shielded Cable Length:
          Up to 1000 m
        • Unshielded Cable Length:
          Up to 600 m
        • Address Space:
          4 input bytes plus 4 quality-information bytes
        • Terminal Block:
          H1/P0
        • Configuration Software:
          STEP 7 TIA Portal V16, STEP 7 V5.6, PCS 7 V9 or PCS neo V3
        • Diagnostics:
          Supply monitoring, channel status and wire-break diagnostics
        • Isolation Test:
          1500 V DC for 1 minute
        • Weight:
          0.3307 lbs (0.15 kg)
        • Estimated shipping dimensions:
          3.5x15x13cm
        • Tariff Code:
          85389091
        • Country of origin:
          Germany
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Channel Wiring Quality Information Channel Diagnosis Configuration Tools

        Features:

        • Thirty-two 24 V DC inputs deliver process states and quality information separately.
        • The H1/P0 terminal block organizes field wiring, supply distribution and channel returns.
        • Channel diagnostics and LEDs connect an invalid signal to its physical input.
        Field contacts and sensors feed the assigned input circuits.

        Voltage thresholds convert the electrical states into process bits and quality bytes.

        The interface module transfers those bytes to the automation system for logic and diagnostics.

        The Siemens 6DL1131-6BL00-0PH1 ET 200SP HA DI 32x24VDC Module may remain available for quotation and support beyond End-Of-Life (EOL) by the manufacturer (OEM).
        Siemens 6DL1131-6BL00-0PH1 ET 200SP HA DI 32x24VDC Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Organizing thirty-two field inputs on the terminal block

        • Signal source: Dry contacts or powered sensors present a 24 V state to the selected channel.
        • P-reading input: Each channel evaluates the positive signal against its assigned reference.
        • Two-wire sensors: Sensor current stays within the documented channel supply path.
        • Cable boundary: Shielded and unshielded runs remain inside their separate length limits.

        Keeping process state and data validity distinct

        • Process bytes: Four bytes carry the thirty-two input states.
        • QI bytes: Four additional bytes indicate the validity of the corresponding channels.
        • PLC interpretation: Controller logic can reject or qualify a process bit when its QI is invalid.
        • Recovery: A valid quality bit confirms that the field state is again usable.

        Locating a field problem without losing module context

        • Supply monitor: The module supervises the 24 V input supply.
        • Wire break: Configured diagnostics detect an open sensor circuit under the documented conditions.
        • Channel LED: Local indication identifies the affected input and its state.
        • Station message: Diagnostic data reaches the engineering and control system through the ET 200SP HA path.

        Applying the same channel behavior in the automation project

        • TIA Portal: Version 16 or later can parameterize the module.
        • Classic STEP 7: Version 5.6 supports the documented hardware configuration.
        • Process systems: PCS 7 V9 and PCS neo V3 integrate the module in their station projects.
        • Parameter record: Input delay, diagnostics, alarms, addresses, and terminal assignment remain archived together.
        Description
        The ET 200SP HA station receives thirty-two 24 V DC field states through Siemens 6DL1131-6BL00-0PH1, its DI 32x24VDC HA digital input module. The module transfers both process bits and quality information to the connected automation system.

        The channels of 6DL1131-6BL00-0PH1 read source or sink P-signals through an H1/P0 terminal block. Field switches and two-wire sensors use the assigned 24 V supply path, while the module compares each input voltage with its documented 0 and 1 thresholds before updating the process image.

        Four process-data bytes and four quality-information bytes let 6DL1131-6BL00-0PH1 separate the input state from its validity. Channel diagnostics, supply monitoring, wire-break evaluation, and LEDs then connect a questionable field signal to the affected channel instead of presenting only a module-level fault.

        Configuration for 6DL1131-6BL00-0PH1 defines input delay, diagnostic response, process alarm behavior, and integration in TIA Portal, STEP 7, PCS 7, or PCS neo. The terminal block, field commons, cable limits, parameter set, and assigned addresses must therefore be preserved with the module.
        Alternative Names
        6DL11316BL000PH1 6DL1 131-6BL00-0PH1 6DL1131 6BL00 0PH1 Siemens 6DL1131-6BL00-0PH1 6DL1131-6BL00-0PH1 DI32 DI 32x24VDC HA 6DL1131-6BL00-0PH1 6DL 1131 6BL00 0PH1 6DL1131/6BL00/0PH1
        Technical notes
        Installed as 6DL1131-6BL00-0PH1, the H1/P0 terminal block, sensor-supply arrangement, channel parameters, quality information, and field-cable record must remain together.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Why can Siemens 6DL1131-6BL00-0PH1 show an input bit while its quality information is invalid?
        Siemens 6DL1131-6BL00-0PH1 keeps process state and channel validity separate; review supply, field wiring, diagnostic parameters, wire-break conditions, and the matching QI bit.
        Which terminal block belongs with 6DL1131-6BL00-0PH1?
        The documented terminal-block type for 6DL1131-6BL00-0PH1 is H1/P0, and its supply and channel assignments must match the project and field wiring.
        How should a long sensor cable be checked on Siemens 6DL1131-6BL00-0PH1?
        For Siemens 6DL1131-6BL00-0PH1, verify cable shielding, route, reference conductor, voltage at the input, sensor leakage current, and the applicable 1000 m shielded or 600 m unshielded limit.
        What project information should be saved before replacing 6DL1131-6BL00-0PH1?
        Save the 6DL1131-6BL00-0PH1 rack position, addresses, H1/P0 terminal map, input delays, diagnostics, alarm settings, QI use, sensor types, and cable record.
        Why does a two-wire sensor remain on when connected to Siemens 6DL1131-6BL00-0PH1?
        Compare the sensor off-state leakage with the 6DL1131-6BL00-0PH1 input thresholds and two-wire sensor current path, then check the field return and configured channel type.
