6ES7288-1ST60-0AA0

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6ES7288-1ST60-0AA0 is a SIMATIC S7-200 SMART CPU ST60 with 36 digital inputs, 24 transistor outputs, Ethernet and RS-485. It provides compact high-point-count control for machines and production equipment.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6ES7288-1ST60-0AA0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7288-1ST60-0AA0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7288-1ST60-0AA0
  • Product Family:
    Siemens Simatic S7-200
  • Product Type:
    CPU ST60 Compact Controller
  • Stock:
    1
  • Supply range:
    20.4 to 28.8 V DC
  • Integrated digital inputs:
    36
  • Integrated transistor outputs:
    24
  • Program memory:
    30 KB
  • Data memory:
    20 KB
  • Total user memory:
    50 KB
  • Maximum current consumption:
    710 mA
  • Inrush current:
    11.5 A at 28.8 V
  • Sensor supply capacity:
    300 mA
  • Backplane capacity:
    1.4 A
  • Power loss:
    20 W
  • Bit execution time:
    150 ns
  • Word execution time:
    1.2 µs
  • Floating-point time:
    3.6 µs
  • High-speed counters:
    6
  • High-speed outputs:
    3 at 100 kHz
  • Output current:
    0.5 A
  • Ethernet:
    10/100 Mbit/s
  • Serial interface:
    RS-485, up to 187.5 kbit/s
  • PROFINET device capacity:
    8 devices
  • Degree of protection:
    IP20
  • Horizontal operating temperature:
    0 to +55 °C
  • Vertical operating temperature:
    0 to +45 °C
  • Storage temperature:
    -40 to +70 °C
  • Relative humidity:
    Up to 95%
  • Maximum altitude:
    2000 m
  • Controller dimensions:
    175 x 100 x 81 mm
  • Weight:
    1.164 lbs (0.5282 kg)
  • Tariff Code:
    85371091
  • Country of origin:
    China
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Performance & Efficiency Connectivity Environmental Ratings

Features:

  • Integrates 36 digital inputs and 24 transistor outputs.
  • Provides six high-speed counters and three 100 kHz pulse outputs.
  • Combines 10/100 Ethernet, PROFINET IO and RS-485 communication.
The ST60 article is the 60-point DC/DC/DC S7-200 SMART CPU configuration.

It concentrates sequence control, fast counting and pulse generation in one compact controller.

Check field-output protection, project version, expansion current and network assignments before changing hardware.

The spare CPU is supplied after firmware and Micro/WIN SMART project compatibility are checked.
Verified resources for Siemens 6ES7288-1ST60-0AA0:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Control packaging, conveying and assembly equipment with dense digital I/O.
  • Generate pulse trains for compatible stepper or positioning functions.
  • Collect fast sensor events through the six integrated high-speed counters.
  • Six counters capture fast input events for counting and position-related logic.
  • Three transistor channels can generate pulses at up to 100 kHz.
  • Application timing must remain within the configured input-filter and output-load limits.
  • The Ethernet port supports 10/100 Mbit/s plant and engineering communication.
  • The CPU can control up to eight documented PROFINET devices.
  • An RS-485 interface provides the supported serial communication path.
  • IP20 construction requires installation inside a suitable enclosure.
  • Horizontal mounting supports operation up to 55 °C, while vertical mounting is limited to 45 °C.
  • Storage extends from -40 to +70 °C with relative humidity up to 95%.
Description
6ES7288-1ST60-0AA0 integrates 36 digital inputs and 24 transistor outputs in a 24 V DC S7-200 SMART CPU. Fifty kilobytes of combined program and data memory support compact automation without a separate I/O rack.

Six high-speed counters and three 100 kHz pulse outputs address positioning, counting and motion-oriented machine functions. Ethernet and RS-485 interfaces support engineering, PROFINET IO and serial communication within the documented resource limits.

Transistor outputs are rated for defined loads but are not short-circuit protected, so field protection and suppression remain essential. Verify firmware, Micro/WIN SMART project, power budget, port assignment and expansion modules before replacing the controller.
Alternative Names
6ES7288-1ST60-0AA0 6ES7288 1ST60 0AA0 6ES72881ST600AA0 Siemens 6ES7288-1ST60-0AA0 Siemens CPU ST60 Siemens SIMATIC S7-200 SMART ST60 Siemens SMART 60 Point CPU
Technical notes
6ES7288-1ST60-0AA0 transistor outputs lack short-circuit protection; isolate field faults and confirm output-group loading before fitting a replacement CPU.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which fast-control resources are built into Siemens 6ES7288-1ST60-0AA0?
The CPU includes six high-speed counters and three transistor pulse outputs capable of 100 kHz.
How does mounting orientation change Siemens 6ES7288-1ST60-0AA0 temperature limits?
Horizontal installation is specified to 55 °C, while vertical installation reduces the upper operating limit to 45 °C.
What field protection is necessary for Siemens 6ES7288-1ST60-0AA0 outputs?
External protection and suitable suppression are required because the integrated transistor outputs are not short-circuit protected.
Does Siemens 6ES7288-1ST60-0AA0 require a separate Ethernet communication module?
No. The ST60 CPU includes the documented Ethernet interface and can coordinate up to eight PROFINET devices within its communication resources.
What must be compared before replacing Siemens 6ES7288-1ST60-0AA0 with another SMART CPU?
Compare I/O count and type, pulse resources, expansion capacity, memory, ports, firmware and the Micro/WIN SMART project.
Which commissioning details should accompany Siemens 6ES7288-1ST60-0AA0 procurement?
Provide the full label, firmware, Micro/WIN SMART release, expansion list, output loads, network use, quantity and destination.
