Allen-Bradley 2071-A10 is a discontinued Kinetix 3 1.0 kW three-phase component servo drive.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 2071-A10
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2071-A10

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2071-A10
  • Product Family:
    Kinetix Servo Drive
  • Product Type:
    Kinetix 3 Component Servo Drive
  • Stock:
    1
  • AC Input Voltage:
    170...264 V rms
  • AC Input Phase:
    Three-phase
  • AC Input Frequency:
    47...63 Hz
  • Continuous Output Power:
    1.0 kW
  • Continuous Output Current:
    7.07 A rms / 9.90 A 0-pk
  • Peak Output Current:
    18.88 A rms / 26.70 A 0-pk
  • Mains AC Input Current:
    8.75 A rms
  • Nominal DC Bus Voltage:
    311 V DC
  • PWM Frequency:
    10 kHz
  • Efficiency:
    90%
  • Dimensions:
    8.1 × 19.86 × 15.5 cm
  • Weight:
    1.75 kg
  • Tariff Code:
    8503009090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Cables Feedback Installation Application

Features:

  • Single-axis Kinetix 3 architecture with indexing capability
  • Serial programming connection supported through the documented PC interface cable
  • MicroLogix Modbus RTU connection supported with the specified communication cable
Allen-Bradley 2071-A10 provides one compact servo axis for a Kinetix 3 machine-control architecture.

Its system accessories include dedicated I/O and motor-feedback breakout boards, with the feedback cable limited to the documented maximum length.

Before migration to the functional replacement, compare the installed controller interface, motor and feedback devices, cable set, mounting, and Series A hardware.

Availability, condition, price, and shipping time for 2071-A10 are confirmed during quotation.

Allen-Bradley 2071-A10 Kinetix 3 Component Servo Drive Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • 2090-CCMPCDS-23AAxx supports the documented PC serial programming connection
  • 2090-CCMCNDS-48AAxx supports the documented MicroLogix Modbus RTU connection
  • Motor-feedback cable length is limited to 30 m in the Kinetix 3 system design
  • 2071-TBMF provides the documented 20-pin motor-feedback breakout connection
  • A 3.6 V 1/2AA battery supports absolute-position retention for compatible feedback systems
  • Motor and feedback cable selection must follow the exact Kinetix 3 drive-to-motor combination
  • M5 × 10 fasteners are specified for the top mounting hole and lower mounting slot
  • Two chassis-ground terminals are provided for protective grounding
  • Wait at least five minutes after removing power before touching the drive or wiring
  • Single-axis indexing sequences in compact motion-control equipment
  • Servo positioning systems using a supported Kinetix 3 motor and feedback combination
  • MicroLogix-controlled motion applications using the documented Modbus RTU interface
Description
Allen-Bradley 2071-A10 is a Kinetix 3 single-axis component servo drive with indexing mode for one 220 V-class motion axis.

It accepts 170...264 V rms three-phase input at 47...63 Hz and provides 1.0 kW continuous output, 7.07 A rms continuous current, and 18.88 A rms peak current.

Before installation or replacement, verify Series A hardware, controller interface, motor and feedback pairing, cable set, breakout boards, mounting, grounding, and the functional-replacement requirements.
Revisions

Revision Part #

Also known as

2071-A10 Ser A
2071-A10/A, Series A, Rev A
Alternative Names
2071-A10 2071A10 2071 A10 Allen-Bradley 2071-A10 Allen Bradley 2071-A10 AB 2071-A10 Rockwell Automation 2071-A10 Kinetix 3 2071-A10
Technical notes
Match the exact motor, feedback cable, breakout board, controller interface, Series A hardware, and firmware before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which feedback cable length limit applies to Allen-Bradley 2071-A10?
Rockwell Automation specifies a maximum motor-feedback cable length of 30 m for Kinetix 3 system configurations. Confirm the exact motor and feedback connector before ordering.
Can Allen-Bradley 2071-A10 be programmed from a PC?
Yes. Rockwell Automation lists the 2090-CCMPCDS-23AAxx serial interface cable for PC-to-Kinetix 3 programming connections.
Can Allen-Bradley 2071-A10 communicate with a MicroLogix controller over Modbus RTU?
Yes. The Kinetix 3 system-design guide lists the 2090-CCMCNDS-48AAxx cable for a MicroLogix Modbus RTU connection.
Which breakout boards are documented for Allen-Bradley 2071-A10?
Rockwell Automation lists the 2071-TBIO I/O breakout board and 2071-TBMF motor-feedback breakout board for Kinetix 3 drives.
How long should power remain removed before servicing Allen-Bradley 2071-A10?
The installation instructions require waiting at least five minutes after removing power before touching the drive or wiring.
Is Allen-Bradley 2198-E1015-ERS a direct drop-in replacement for 2071-A10?
Rockwell Automation identifies 2198-E1015-ERS as a functional replacement. Verify supply, motor and feedback compatibility, cables, controller configuration, mounting, and safety functions before migration.
What should be verified when sourcing Allen-Bradley 2071-A10 for an installed machine?
Match the complete catalog number, Series A hardware, firmware, motor, feedback connector, cable set, breakout boards, and control interface to the machine documentation.
