Allen-Bradley 2198-D006-ERS4 is a Kinetix 5700 dual-axis safe speed drive with 2.5 A rms continuous output per axis and Advanced Safety.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 2198-D006-ERS4
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2198-D006-ERS4

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2198-D006-ERS4
  • Product Family:
    Kinetix Servo Drive
  • Product Type:
    Kinetix 5700 Dual Axis Safe Speed Drive
  • Stock:
    1
  • DC Input Voltage:
    276...747 V DC
  • Continuous Output Current:
    2 × 2.5 A rms
  • Peak Output Current:
    2 × 6.3 A rms
  • Output Power at 240 V:
    2 × 0.9 kW
  • Output Power at 480 V:
    2 × 1.7 kW
  • Axis Configuration:
    Dual-axis
  • PWM Frequency:
    4 kHz
  • Safety:
    Advanced Safety
  • Weight:
    4.16 kg
  • Estimated shipping dimensions:
    5.5 × 35.8 × 26.75 cm
  • Tariff Code:
    8503009090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Control Wiring Installation Application

Features:

  • Dual-axis Kinetix 5700 architecture serves two lower-current servo axes
  • ERS4 identifies the Advanced Safety catalog configuration
  • The latest technical data specifies 6.3 A rms peak output per axis
Allen-Bradley 2198-D006-ERS4 supports compact two-axis sections at either the documented 240 V or 480 V three-phase operating condition.

Verify voltage class, both motor-feedback combinations, shared-bus hardware, firmware, cabling, cooling, and the complete safety design before commissioning.

Availability, condition, price, and shipping time for 2198-D006-ERS4 are confirmed during quotation.

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Integrated Motion over EtherNet/IP exchanges motion commands and drive status with a Logix controller
  • Two Ethernet ports support linear, star, and device-level ring network layouts
  • Studio 5000 Logix Designer is used to configure both motion axes and Advanced Safety
  • Separate motor power and feedback connections are provided for the two integrated axes
  • The Kinetix 5700 shared-bus system distributes DC-bus and 24 V control power between modules
  • Protective bonding, cable shielding, and connector torque follow the 2198-UM002 installation instructions
  • Zero-stack mounting permits adjacent Kinetix 5700 modules in a shared-bus lineup
  • IP20 open-type construction requires a suitable enclosure with documented clearances
  • Panel depth, cooling airflow, branch protection, and regeneration are verified for the complete system
  • Compact machine sections requiring two independently configured servo axes
  • 240 V or 480 V three-phase Kinetix 5700 systems sized to the documented power ratings
  • Integrated-motion applications that require the ERS4 Advanced Safety configuration
Description
Allen-Bradley 2198-D006-ERS4 is a Kinetix 5700 dual-axis safe speed drive with Advanced Safety for Integrated Motion over EtherNet/IP systems.

Each axis provides 2.5 A rms continuous and 6.3 A rms peak output for up to 1.0 second, with 0.9 kW at 240 V three-phase or 1.7 kW at 480 V three-phase.

Confirm the voltage class, both motor and feedback combinations, shared DC-bus hardware, controller firmware, cabling, regeneration, enclosure cooling, and safety configuration before installation or replacement.
Revisions

Revision Part #

Also known as

2198-D006-ERS4 Series A
2198-D006-ERS4/A, Series A
Alternative Names
Allen-Bradley 2198-D006-ERS4 Rockwell Automation 2198-D006-ERS4 2198-D006-ERS4 2198 D006 ERS4 2198D006ERS4 AB 2198-D006-ERS4 Kinetix 5700 2198-D006-ERS4 Kinetix 5700 Dual Axis Safe Speed Drive 2198-D006-ERS4 2198-D006-ERS4 Series A 2198-D006-ERS4/A
Technical notes
Allen-Bradley 2198-D006-ERS4 provides 2.5 A rms continuous output per axis with Advanced Safety. Verify voltage class, both motor loads, shared DC-bus hardware, firmware, and safety configuration before installation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What DC-bus values are documented for Allen-Bradley 2198-D006-ERS4?
Rockwell Automation lists 2.7 A DC input current and 165 µF DC-bus capacitance. Use these values when checking converter loading, the shared-bus module combination, and regenerative-energy capacity.
What humidity conditions must be controlled around Allen-Bradley 2198-D006-ERS4?
The specified relative-humidity range is 5...95% noncondensing. The enclosure must prevent condensation while maintaining the documented temperature and cooling conditions.
What velocity-loop performance is documented for Allen-Bradley 2198-D006-ERS4?
Rockwell Automation specifies a maximum velocity-loop bandwidth of 400 Hz. Actual response depends on the selected motor, feedback device, load inertia, mechanical resonance, and completed axis tuning.
What hardware must be compatible with Allen-Bradley 2198-D006-ERS4?
Verify the shared DC-bus and 24 V control-power hardware, compatible Kinetix motors and feedback devices, cable sets, Logix motion controller, firmware, and Advanced Safety configuration.
What must be checked before replacing an older drive with Allen-Bradley 2198-D006-ERS4?
Compare the full ERS4 catalog number, Series A firmware, voltage class, 2.5/6.3 A per-axis ratings, 55 × 358 × 267.5 mm envelope, connectors, feedback, and safety architecture.
Which Rockwell Automation documents cover Allen-Bradley 2198-D006-ERS4?
Use Kinetix Servo Drives Specifications KNX-TD003 for current ratings and dimensions, and Kinetix 5700 Servo Drives User Manual 2198-UM002 for installation, wiring, startup, and safety instructions.
What should be included in an inquiry for Allen-Bradley 2198-D006-ERS4?
State the exact catalog number, quantity, destination, 240 V or 480 V system class, both motors and feedback types, shared-bus arrangement, firmware, and required safety functions for a checked quotation.
