1794-OE12

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1794-OE12 provides twelve high-density, 16-bit analog outputs with field-power, wire-off, and safe-state status in FLEX I/O.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1794-OE12
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1794-OE12

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1794-OE12
  • Product Family:
    Flex I/O
  • Product Type:
    FLEX I/O 12-Point Analog Output Module
  • Stock:
    1
  • Analog outputs:
    12 single-ended, nonisolated channels
  • Output ranges:
    0...20 mA, 4...20 mA, or +10 V
  • Resolution:
    16 bits
  • Terminal bases:
    1794-TB3G, TB3GS, TB3GK, or TB3GSK
  • External supply:
    24 V DC nominal
  • Status:
    Wire off, field power fault, and general fault
  • Safe state:
    Value, reset, or hold selection
  • Operating temperature:
    -20...+60 °C
  • Enclosure:
    Open style
  • Weight:
    0.106 kg
  • Estimated shipping dimensions:
    4.6 x 9.4 x 5.4 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Singapore
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Channel Pairs Power Check Fault Check Product Applications

Features:

  • Dense analog station: twelve output channels in one FLEX I/O module
  • Shared fault visibility: wire-off, field-power, and general status
  • Grounded base design: dedicated TB3G-family termination and shielding
1794-OE12 reduces module count where many analog final elements are concentrated at one remote station.

Its engineering distinction is the combination of high channel density, grouped configuration, and station-level power diagnostics.

The accepted build should link channel pairs, field supply, grounded terminal base, shields, safe states, and test results.

Apter Power can coordinate official-document review, quotation, and sourcing support for 1794-OE12.
1794-OE12 FLEX I/O 12-Point Analog Output Module Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Device mapping: place compatible signal requirements in the documented adjacent pairs.
  • Range record: preserve the selected mode with the controller word map.
  • Change control: retest both affected channels when a paired setting is altered.
  • Grounded base: use an approved TB3G-family terminal assembly.
  • Supply separation: do not extend an unreviewed digital-base power chain into the analog base.
  • Status first: examine field-power fault data before tracing multiple channel loops.
  • Wire-off flags: identify the affected current-loop channels.
  • General fault: compare module status with supply and configuration information.
  • Fallback check: verify safe-state behavior for every connected final element.
  • Multi-loop process skids: command numerous analog final elements from one station.
  • Concentrated drive references: distribute qualified analog setpoints with a shared diagnostic image.
  • Remote control panels: reduce module count where twelve analog outputs are required.
Description
1794-OE12 is a twelve-channel FLEX I/O analog output module for applications that need dense current or voltage command capacity. The module uses a grounded TB3G-family terminal base and returns both output and diagnostic data to the controller.

With 1794-OE12, adjacent channels share documented configuration grouping while wire-off, field-power, and general-fault information help isolate station-level problems. Safe-state selection defines the commanded behavior when the controlling system changes state.

Panel approval for 1794-OE12 should be based on the complete twelve-channel terminal schedule and the official analog-power segregation rules. Confirm the grounded base, shield treatment, load limits, and controller word map before field outputs are released.
Revisions

Revision Part #

Also known as

1794-OE12 Series A
1794-OE12/A, Series A
Alternative Names
Allen-Bradley FLEX I/O OE12 Rockwell 1794 OE12 High-Density Output 1794OE12 twelve-channel analog module FLEX I/O 16-bit output station
Technical notes
Loss of 24 V DC field power on 1794-OE12 can produce several channel symptoms at once. Check the field-power status before opening individual loops, keep the grounded analog base separate from unreviewed digital power chains, and prove each configured safe-state response under a controlled load after supply restoration.
