IC697MDL750

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IC697MDL750 is a 32-point Series 90-70 24/48 VDC output module for switching high-inrush DC loads across four isolated groups.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IC697MDL750
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC697MDL750

  • Manufacturer:
    General Electric
  • Part Number:
    IC697MDL750
  • Product Family:
    GE 90-70 Series PLC
  • Product Type:
    Series 90-70 24/48 VDC Output Module
  • Stock:
    1
  • Output Count:
    32
  • Output Grouping:
    Four isolated groups of 8
  • Rated Voltage:
    24 or 48 VDC
  • Voltage Range:
    20 to 60 VDC
  • Point Current:
    0.5 A maximum
  • Group Current:
    2 A maximum
  • Inrush Current:
    10 A maximum for 20 ms
  • Response Time:
    1 ms maximum ON and OFF
  • Field-to-Backplane Isolation:
    1500 V
  • Group-to-Group Isolation:
    500 V
  • 5 V Bus Current:
    0.25 A
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Load Distribution Inrush Behavior Fuse Guidance Default & Status

Features:

  • Switches thirty-two 24/48 VDC loads in four isolated groups.
  • Provides 0.5 A point capacity with short 10 A inrush handling.
  • Offers 1 ms response and a logic-side indicator for every output.
IC697MDL750 combines high point density with separate field-power banks so four load sections can be organized in one slot.

Its surge capability supports compatible inductive or incandescent loads whose starting current exceeds their steady operating level.

Software-selected default behavior determines whether commanded states are retained or cleared during defined controller conditions.

The General Electric IC697MDL750 Series 90-70 Output Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IC697MDL750 Series 90-70 24/48 VDC Output Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Four independently powered banks

  • Point Layout: Thirty-two outputs are split into A, B, C, and D groups with eight points apiece.
  • Separate Supplies: Each bank has its own common and field-power terminal set.
  • Bank Limit: Combined continuous current in one eight-point section cannot exceed 2 A.
  • Point Limit: No individual output carries more than 0.5 A in steady operation.

Starting-current capability

  • Short Surge: One output can conduct as much as 10 A for a 20 ms interval.
  • Repetition Boundary: Permitted surge frequency falls as steady current and load duty cycle rise.
  • Typical Devices: Solenoids, motor starters, and indicator loads can use the available transient capacity.
  • Thermal Constraint: Group current remains the controlling limit even when individual points are below 0.5 A.

External branch protection

  • No Internal Fuses: The module does not place a replaceable fuse in series with each output point.
  • User Protection: Required overcurrent protection is installed in the external field wiring.
  • Recommended Rating: The documented point-fuse examples use a fast-acting 0.75 A, 250 V device.
  • One Fuse per Point: Separate branch protection prevents one field fault from depending on a shared group fuse.

Command visibility and fallback state

  • Point LEDs: Thirty-two indicators display the ON or OFF command presented on the PLC side.
  • Hold Option: A configured operating fault can leave the last output command unchanged.
  • Off Option: The alternative response clears the output points when the specified condition occurs.
  • Software Setup: Output references and fallback behavior are assigned without onboard jumpers or DIP switches.
Description
General Electric IC697MDL750 switches thirty-two 24 or 48 VDC field loads from one Series 90-70 rack position. The output section is arranged as four isolated banks of eight, each supplied through its own field-power connection.

A point on General Electric IC697MDL750 carries up to 0.5 A continuously, while each eight-point bank is limited to 2 A by the module's heat-dissipation boundary. Short load-starting surges can reach 10 A for 20 ms, supporting devices with substantial inrush current.

Solenoids, motor starters, and indicators can be assigned to General Electric IC697MDL750 when their steady current, surge profile, and duty cycle stay within the stated limits. The module contains no internal output fuses, so any required branch protection is provided in the external field circuit.

General Electric IC697MDL750 reports commanded ON/OFF state through thirty-two logic-side LEDs and responds within 1 ms in either direction. Programming software assigns I/O references and selects whether outputs hold their previous state or turn off when the controller enters a configured default condition.
Revisions

Revision Part #

Also known as

IC697MDL750G
IC697MDL750-G, Series G, Rev G
IC697MDL750E
IC697MDL750-E, Series E, Rev E
IC697MDL750D
IC697MDL750-D, Series D, Rev D
IC697MDL750C
IC697MDL750-C, Series C, Rev C
IC697MDL750B
IC697MDL750-B, Series B, Rev B
IC697MDL750A
IC697MDL750-A, Series A, Rev A
IC697MDL750 Ser 0
IC697MDL750/0, Series 0, Rev 0
IC697MDL750F
IC697MDL750-F, Series F, Rev F
IC697MDL750H
IC697MDL750-H, Series H, Rev H
Alternative Names
General Electric IC697MDL750 GE IC697MDL750 IC697-MDL750 IC697 MDL750 GE Fanuc IC697MDL750 Series 90-70 24/48 VDC Output IC697MDL750 Output Module IC697MDL75O
Technical notes
General Electric IC697MDL750 delivers thirty-two 24/48 VDC outputs in four isolated groups, rated 0.5 A per point with a 10 A, 20 ms inrush capability.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What loads are suited to General Electric IC697MDL750?
General Electric IC697MDL750 can switch compatible DC solenoids, motor starters, and indicators whose current and duty cycle remain within its limits.
How are the outputs divided on General Electric IC697MDL750?
General Electric IC697MDL750 contains four isolated banks, each carrying eight output points and its own field-power connection.
Can General Electric IC697MDL750 tolerate load inrush?
Each point on General Electric IC697MDL750 can conduct a transient surge up to 10 A for 20 ms, subject to repetition and duty-cycle limits.
Are output fuses built into General Electric IC697MDL750?
No. General Electric IC697MDL750 has no internal output fuses, so branch protection is added externally when the circuit design requires it.
What happens to General Electric IC697MDL750 outputs during a configured default condition?
Programming software can make General Electric IC697MDL750 hold the existing output state or turn all points off.
How quickly does General Electric IC697MDL750 switch?
The stated maximum turn-on and turn-off response of General Electric IC697MDL750 is 1 ms.
What isolation is provided by General Electric IC697MDL750?
General Electric IC697MDL750 provides 1500 V separation from the backplane and 500 V separation between output groups.
