          Apter Power supports quotation, code verification, documentation, and matching sensor review.

        330710-004-054-50-02-05

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Bently Nevada 330710-004-054-50-02-05 is an M16x1.5 armored 3300 XL 11 mm probe with 4 mm unthreaded length, 54 mm case, 5.0 m standard cable and multiple approvals.
        In Stock
        Ships by Wednesday, September 30
        Fast Shipping Available
        Get a quick price for 330710-004-054-50-02-05
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330710-004-054-50-02-05

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330710-004-054-50-02-05
        • Product Family:
          3300 XL 11mm Proximity Transducer System
        • Product Type:
          Proximity Probe
        • Stock:
          1
        • Thread:
          M16 x 1.5
        • Armor:
          With armor
        • Unthreaded length:
          4 mm
        • Overall case length:
          54 mm
        • Total probe length:
          5.0 m (16.4 ft)
        • Connector and cable:
          02 = ClickLoc connector, standard cable
        • Connector protector:
          Not included by option 02
        • Agency approval:
          05 = Multiple approvals
        • System linear range:
          4.0 mm (160 mils)
        • Nominal scale factor:
          2.0 V/mm (50 mV/mil)
        • Measurement frequency range:
          0 to 8 kHz
        • Reference target:
          AISI 4140 steel, 31 mm minimum diameter
        • System power:
          -17.5 to -26 VDC without barriers; 12 mA maximum
        • Output resistance:
          50 ohms
        • Extension-cable capacitance:
          69.9 pF/m typical
        • Maximum field-wire length:
          305 m (1000 ft)
        • Probe-to-cable pull strength:
          330 N (75 lb)
        • Connector family:
          Gold-plated brass ClickLoc
        • Standard calibration:
          AISI 4140 steel
        • Recommended field wiring:
          Three-conductor shielded triad
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Applications Configuration Protection Certifications

        Features:

        • Combines an M16x1.5 armored case with a 4 mm unthreaded tip section.
        • Uses a 54 mm case and 5.0 m standard cable with a ClickLoc connector.
        • Retains the 05 multiple-approval option in the complete ordering identity.
        The current ordering configuration is 330710-004-054-50-02-05, the M16x1.5 armored probe with 4 mm unthreaded length, 54 mm case and 5.0 m standard cable.

        The probe detects shaft-to-tip distance changes for radial vibration, axial position or Keyphasor measurement within the 3300 XL 11 mm system.

        Before installation, verify the metric thread, insertion depth, armor routing, missing protector option, five-metre system match and approval label.

        Availability is subject to Apter Power inventory and sourcing confirmation.
        Verified resources for Bently Nevada 330710-004-054-50-02-05:
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Measures shaft radial vibration where a four-millimetre linear range is needed.
        • Tracks axial position in machinery fitted with an M16x1.5 probe port.
        • Provides a Keyphasor phase-reference signal when installed against an appropriate timing target.
        • The 004 field selects 4 mm unthreaded length and the 054 field selects a 54 mm overall case.
        • The 50 code selects a five-metre probe cable intended for the five-metre sensor configuration.
        • The 02 connector option supplies standard cable without the connector protector.
        • Armor protects the lead from routine mechanical contact but does not replace proper strain relief.
        • Install an approved connector protector when the ClickLoc junction will be exposed to humidity or liquids.
        • Safety-wire the locknut where required by the machine installation procedure.
        • The final 05 code selects the multiple-approval ordering option.
        • Only certification markings present on the supplied probe and system components apply to the installation.
        • Hazardous-area wiring must follow the applicable Bently Nevada installation drawing and site control document.
        View as PDF
        Description
        330710-004-054-50-02-05 is the armored M16x1.5 metric probe configuration in the Bently Nevada 3300 XL 11 mm family. Its 4 mm unthreaded length and 54 mm overall case define the mechanical reach at the mounting port.

        The probe includes a five-metre standard cable and miniature coaxial ClickLoc connector without the optional connector protector. Its larger 11 mm transducer geometry supports a four-millimetre system range for position, vibration and phase-reference measurements.

        This ordering identity suits metric probe ports where armor is required along the installed lead. Commissioning depends on the matching five-metre Proximitor Sensor, correct AISI 4140 target setup and confirmed hazardous-area marking.
        Alternative Names
        330710-004-054-50-02-05 330710004054500205 330710 004 054 50 02 05 330710-004-054-50-02-05 3300 XL 11 mm Proximity Probe 330710-004-054-50-02-05 M16 x 1 Proximity Probe 330710-004-054-50-02-05 54 mm Armored Probe 330710-004-054-50-02-05 5.0 m ClickLoc Probe Bently Nevada 3300 XL 11 mm Proximity Transducer System
        Technical notes
        330710-004-054-50-02-05 uses connector option 02 without a protector; add approved junction protection where oil or condensation can reach the ClickLoc connection.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        How is the insertion geometry of 330710-004-054-50-02-05 defined?
        The code specifies 4 mm of unthreaded length within a 54 mm M16x1.5 armored probe case.
        Does 330710-004-054-50-02-05 include a connector protector?
        No. Connector option 02 provides the standard ClickLoc connection without the protector.
        Which measurement range applies to 330710-004-054-50-02-05?
        When paired with the correct 3300 XL 11 mm components, the documented system linear range is 4.0 mm.
        Can 330710-004-054-50-02-05 replace an unarmored M16 probe?
        Only after checking mounting clearance and cable routing; the armored 330710 body differs from unarmored metric variants.
        What should be verified after installing 330710-004-054-50-02-05?
        Verify static gap, scale factor, cable restraint, connector sealing and channel configuration with the machine safely isolated.
        Which manual identifies 330710-004-054-50-02-05?
        Use Bently Nevada Datasheet 146256 for the 3300 XL 11 mm transducer system and retain the complete ordering code in the inquiry.
