3500/94 190214-01

/ 4.9
1001 reviews | Need a Specific Revision?
The Bently Nevada 3500/94 190214-01 is a full-height rear I/O module designed for the 3500/94M VGA display monitor system, facilitating the connection between the 3500/94M main display module and an external touchscreen monitor.
In Stock
Ships by Friday, October 16
Fast Shipping Available
Get a quick price for 3500/94 190214-01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3500/94 190214-01

  • Manufacturer:
    Bently Nevada
  • Part Number:
    3500/94 190214-01
  • Product Family:
    3500 System
  • Product Type:
    Normal I/O Module
  • Stock:
    1
  • System Compatibility:
    3500 Machinery Protection System
  • Rack Space Requirement:
    1 full-height rear slot
  • Power Consumption:
    Powered via 3500 rack backplane / system power supply
  • Video Signal Output:
    VGA port (Analog Red, Green, Blue, and Sync signals)
  • Data Communications:
    RS232 port (Touch screen controller data)
  • Operating Temperature:
    -20°C to 65°C (-4°F to 149°F)
  • Storage Temperature:
    -40°C to 85°C (-40°F to 185°F)
  • Operating Humidity:
    95% non-condensing
  • EMC Standards:
    EN 61000-6-2, EN 61000-6-4
  • Electrical Safety Standards:
    CSA C22.2 61010-1, UL EN 61010-1
  • Hazardous Area Approval (ATEX/IECEx):
    II 3G Ex nA nC ic IIC T4 Gc
  • Weight:
    0.34 kg
  • Estimated shipping dimensions:
    241.3 x 24.4 x 99.1 mm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Communication & Connectivity Compatibility Configuration

Features:

  • Serves as a full-height rear I/O module providing physical connection interfaces for the 3500/94M VGA display system.
  • Features dedicated VGA analog video output ports and RS232 serial communication ports for touch controller data.
  • Built to industrial standards supporting operating temperatures from -20°C to 65°C and up to 95% non-condensing humidity.
The Bently Nevada 3500/94 190214-01 is ordered as the Normal I/O Module component for the 3500/94M VGA Display Monitor system, providing the necessary rear backplane interfaces for external display connection.

This module routes analog RGB video signals and touch screen data from the front 3500/94M processing module directly to supported external display hardware or router boxes within the 3500 Machinery Protection System.

Installation requires one full-height rear slot in a standard 3500 rack, proper mating with the 3500/94M front module (P/N 184826-01), and presence of a 3500/22 Transient Data Interface (TDI) module.

The 3500/94 190214-01 is subject to standard factory lead times when not available in current stock; contact sales for real-time inventory and delivery schedules supported by the manufacturer (OEM).
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Used in industrial plant operator stations to output machinery vibration and status graphics to local touch screen displays.
  • Applied in rotating machinery protection systems to transmit VGA video signals across control cabinet displays.
  • Deployed in remote machinery monitoring setups utilizing Display Router Boxes or KVM extension hardware.
  • Outputs analog Red, Green, Blue (RGB), and Sync video signals directly through an onboard VGA output connector.
  • Provides dedicated RS232 serial interface communication for receiving touch screen controller input commands.
  • Supports direct cable runs up to 6 meters (20 feet) or fiber optic KVM extender links up to 10 kilometers (6.2 miles).
  • Requires standard integration with the front-slot 3500/94M VGA Display Processing Module (P/N 184826-01).
  • Operates seamlessly with Advantech 10-inch (ANA-D3510-100-A1) and 15-inch (FPM-8151) touch screen displays.
  • Connects directly to the 3500/94 Display Router Box for multi-display signal routing across 3500 machinery protection racks.
  • Configured using 3500 Rack Configuration Software to set up custom machine train display screens and layout pages.
  • Requires 3500/94M Firmware version 4.06 (Revision C or higher) for full software and hardware feature support.
  • Allows operators to configure language preferences, screen timeout durations, and password access levels.
Description
Bently Nevada 3500/94 190214-01 Normal I/O Module serves as the dedicated backplane interface card for the 3500/94M VGA Display Monitor assembly within the 3500 Machinery Protection System. Installed in a full-height rear rack slot, this module establishes direct connectivity between the main processing electronics and external display hardware, delivering real-time machinery protection data to operators in industrial environments.

Designed for seamless system integration, the Bently Nevada 3500/94 190214-01 routes analog RGB video signals and RS232 touch screen communication data directly to supported display units or router hardware. This enables operators to continuously monitor critical machine parameters, system event logs, alarm statuses, and customizable machine train display pages directly from control cabinets or remote operator stations.

Engineered to withstand rigorous industrial conditions, the Bently Nevada 3500/94 190214-01 operates reliably within a wide temperature range from -20°C to 65°C and supports up to 95% non-condensing humidity. It forms an indispensable communication link in critical rotating equipment monitoring applications across power generation, oil and gas, and heavy manufacturing facilities.
Alternative Names
190214-01 19021401 350094 190214-01 3500/94 190214-01 3500/94M 190214-01 Bently Nevada 3500/94 IO Card Bently Nevada 3500/94M Normal I/O Module
Technical notes
The Bently Nevada 3500/94 190214-01 module requires a 3500/22 Transient Data Interface (TDI) module and compatible 3500/94M firmware for proper operation within the 3500 rack.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the physical rack space requirement for Bently Nevada 3500/94 190214-01?
Bently Nevada 3500/94 190214-01 occupies one full-height rear slot in a standard Bently Nevada 3500 system rack.
What hardware and firmware are mandatory for operating Bently Nevada 3500/94 190214-01?
Bently Nevada 3500/94 190214-01 requires a 3500/22 Transient Data Interface (TDI) module, 3500/94M Firmware 4.06 (Rev. C or higher), and 3500 Rack Configuration Software.
How far can the display screen be positioned from Bently Nevada 3500/94 190214-01?
Using standard cables, the display screen can be installed up to 6 meters (20 feet) away; with a Single-mode Fiber Optic KVM Extender, distance can be extended up to 10 kilometers (6.2 miles).
Which touch screen displays are directly supported by Bently Nevada 3500/94 190214-01?
Bently Nevada 3500/94 190214-01 supports Advantech 10" (ANA-D3510-100-A1 / P/N 120M8155-01) and Advantech 15" (FPM-8151 / P/N 102M8950) touch screen displays.
How does Bently Nevada 3500/94 190214-01 differ from the 190214-02 I/O module?
Bently Nevada 3500/94 190214-01 is the Normal I/O module providing standard video/data interfaces, whereas 190214-02 is a Power-only I/O module designed specifically for front-mount display setups.
How can I submit a price inquiry or RFQ for Bently Nevada 3500/94 190214-01?
You can contacting our sales team directly with your needed quantity and delivery location for Bently Nevada 3500/94 190214-01.
