The Bently Nevada 3500/92 136180-01 Communication Gateway module is designed to provide comprehensive communication capabilities for integration with process control systems and other automation applications.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 3500/92 136180-01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3500/92 136180-01

  • Manufacturer:
    Bently Nevada
  • Part Number:
    3500/92 136180-01
  • Product Family:
    3500 System
  • Product Type:
    Communication Gateway Module
  • Stock:
    1
  • Signal Type:
    PLC, DCS communication
  • Operating Temperature Range:
    -30°C to +65°C(-22°F to +149°F)
  • Storage Temperature Range:
    -40°C to 85°C (-40°F to 185°F)
  • Humidity:
    95%, non-condensing
  • Protocol:
    Ethernet TCP/IP frameand Modbus/TCP
  • Communication Link:
    Ethernet, 10Mbps, andconforms to IEEE802.3
  • Weight:
    0.82 kg
  • Estimated shipping dimensions:
    2.5x25.8x12cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Data Integration Network Management Application

Features:

  • Reliable communication gateway enabling integration of 3500 series monitoring systems with external control and data networks
  • Stable data exchange between machinery protection systems and plant-level automation or condition monitoring platforms
  • Efficient system connectivity within the Bently Nevada 3500 monitoring architecture for industrial asset protection
The 3500/92 136180-01 Communication Gateway Module is designed as an important interface component within the 3500 machinery protection system. The 3500/92 136180-01 plays a key role in connecting monitoring data from the rack system to higher-level industrial control and information systems. By enabling structured data communication, the 3500/92 136180-01 helps operators achieve better visibility of machine health conditions. It is widely applied in industries where continuous monitoring and centralized control are required. The 3500/92 136180-01 supports reliable system integration in complex industrial environments.

In practical operation, the 3500/92 136180-01 ensures smooth data transmission between the 3500 monitoring rack and external systems such as SCADA or plant DCS networks. The 3500/92 136180-01 helps convert monitoring signals into usable information for analysis and decision-making. It is commonly used in power generation, oil and gas, and large-scale manufacturing facilities. The 3500/92 136180-01 improves operational awareness by enabling real-time access to machine condition data. This makes the 3500/92 136180-01 an essential part of modern predictive maintenance strategies.

From an industrial value perspective, the 3500/92 136180-01 enhances overall system connectivity and data accessibility in machinery protection applications. The 3500/92 136180-01 supports long-term operational stability by ensuring consistent communication between monitoring modules and control platforms. Compared with isolated monitoring systems, the 3500/92 136180-01 enables a more integrated and intelligent plant architecture. It contributes to improved maintenance planning and reduced downtime. Overall, the 3500/92 136180-01 is a key communication component within the 3500 system ecosystem.

The 3500/92 136180-01 Bently Nevada Communication Gateway Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 3500/92 136180-01 Communication Gateway Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 3500/92 136180-01 Communication Gateway Module Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 3500/92 136180-01
  • Condition New Original ready stock
  • Product Family 3500/92,137494-01,125736-01
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Unified Viewpoint: Aggregates complex mechanical data from multiple monitoring modules within the framework and outputs it to the higher-level system through a single channel, eliminating information silos.
  • Format Conversion: Automatically converts proprietary monitoring protocols at the lower level into a common industrial standard language, ensuring seamless communication with mainstream control systems.
  • High-Frequency Refresh: Optimizes internal data exchange paths, ensuring that key vibration, displacement, and speed indicators are transmitted to the control room with extremely low latency.
  • Load Sharing: Independently handles communication tasks, effectively reducing the computational burden on the main monitoring module and ensuring the overall stability of the framework.
  • Architecture Expansion: Supports multi-point physical interface connections, facilitating flexible deployment of communication links based on the plant's network topology.
  • Link Diagnostics: Built-in status self-checking function monitors communication quality in real time, quickly triggering system alarms in case of packet loss or interruption.
  • Remote Configuration: Allows technicians to adjust communication parameters from the control room via management software, eliminating the need for manual hardware adjustments on-site.
  • Security Hardening: Provides restricted data access permission management to prevent unauthorized external commands from interfering with the normal parameter settings of the monitoring framework.
  • Distributed Control System Integration: Transmits real-time monitoring values ​​from the 3500 system to the DCS system for implementing logical interlock protection of the process flow.
  • Plant-Level Monitoring Connection: Acts as a bridge to connect mechanical status data to the Plant Information System (PIMS), providing long-term trend analysis for asset management.
  • Status Diagnostic Services: Works with System 1 software to acquire high-resolution waveform data through a gateway for in-depth identification of mechanical fault characteristics.
  • Control Room Visualization: Displays real-time snapshots of the operation of large rotating machinery on the Human-Machine Interface (HMI), assisting operators in making decisions.
Description
The Bently Nevada 3500/92 136180-01 Communication Gateway module is designed to provide comprehensive communication capabilities for integration with process control systems and other automation applications.

It supports seamless communication between the 3500 rack system and external systems using both Ethernet TCP/IP and serial communication protocols such as RS232, RS422, and RS485. This enables the transfer of all monitored values and statuses from the 3500 Rack system to third-party control systems, ensuring real-time data access for efficient monitoring and decision-making.In addition to standard protocols, the 3500/92 supports Modbus Modicon and Modbus/TCP, offering enhanced flexibility for diverse communication needs.The device also integrates with Bently Nevada's Rack Configuration Software and Data Acquisition Software, ensuring full functionality for system setup and data collection.

The 3500/92 includes a Configurable Modbus Register Utility, allowing users to configure the Modbus registers as needed, replacing the primary Modbus registers previously required by the older 3500/90 model.

Designed to handle extensive system data, this gateway module supports both Ethernet TCP/IP and serial communication interfaces (RS-232, RS-422, RS-485), allowing flexible connectivity across diverse network architectures.The module's communication capabilities include support for Modicon® Modbus® protocol over serial links, Modbus/TCP over Ethernet, and the proprietary Bently Nevada protocol for rack configuration and data acquisition software, ensuring broad compatibility with modern PLCs, distributed control systems (DCS), SCADA platforms, and third-party monitoring solutions.
Alternative Names
35OO/92 13618O-O1 3500/92 I36180-0I 350092 13618001 3500/92 04425545 3500/92 137495-01 3500/92 137494-01 3500/92 125736-01 3500/92 133323-01
Technical notes
The Bently Nevada 3500/92 136180-01 is a high-performance communication gateway module designed to bridge machinery protection data with plant automation systems by providing real-time Ethernet and serial connectivity through Modbus protocols, featuring a customizable register utility for flexible data mapping within a ruggedized 3500 rack environment.
