Bently Nevada 330881-28-04-214-00-02 is a metric PROXPAC XL assembly combining a 3300 XL 8 mm probe, 214 mm penetration, 3/4-14 NPT sleeve, and integral Proximitor Sensor for casing installations.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 330881-28-04-214-00-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330881-28-04-214-00-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330881-28-04-214-00-02
  • Product Family:
    PROXPAC XL Proximity Transducer Assembly
  • Stock:
    1
  • Product detail:
    Base 330881 metric PROXPAC XL
  • Option A 28:
    3300 XL 8 mm probe with multiple approvals
  • Option B 04:
    40 mm standoff adapter
  • Option C 214:
    214 mm probe penetration
  • Option D 00:
    no fittings; plugs and washers
  • Option E 02:
    3/4-14 NPT outer sleeve assembly
  • Integrated assembly:
    3300 XL Proximitor Sensor
  • Housing rating:
    Type 4X and IP66
  • Internal cable:
    1 m 75 Ω triaxial FEP-insulated probe cable
  • Field wiring:
    0.2 to 1.5 mm²; maximum 305 m
  • System linear range and nominal ISF:
    2.0 mm; nominal ISF 7.87 V/mm
  • Extension cable requirement:
    between probe and integral Proximitor Sensor
  • Dimensions:
    1.8x1.6x113cm
  • Weight:
    0.05 kg
  • Tariff Code:
    9031809090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Housing Conduit Service Access Application
  • Integrated PROXPAC assembly combines sensing and conditioning
  • 214 penetration is matched to casing and target location
  • Conduit and housing sealing are part of installation review

330881-28-04-214-00-02 is a Bently Nevada PROXPAC XL proximity transducer assembly for the PROXPAC XL Proximity Transducer Assembly.

PROXPAC XL combines the 3300 XL probe and integral Proximitor Sensor in a sealed housing, removing the need for a separate extension cable and separate Proximitor housing. The metric assembly is intended for severe industrial environments.

Before installation or replacement, confirm the complete catalog number, compatible system components, target and mounting arrangement, wiring, approvals and saved channel configuration.

Availability, condition, price, and shipping time for 330881-28-04-214-00-02 are confirmed during quotation.

Bently Nevada 330881-28-04-214-00-02 PROXPAC XL proximity transducer assembly Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Treat the probe and Proximitor Sensor as one PROXPAC assembly
  • Check the 214 configuration against the casing drawing
  • Keep the housing orientation in the equipment record
  • Verify the 3/4-14 NPT entry and no-fitting arrangement
  • Provide sleeve support where the machine drawing requires it
  • Prevent conduit loads from reaching the housing
  • Confirm cover and seal condition before adjustment
  • Protect field wiring from liquid ingress and strain
  • Record the installed target position after service
  • Radial vibration measurement
  • Axial position measurement
  • Speed or phase-reference measurement
Description
330881-28-04-214-00-02 is a Bently Nevada PROXPAC XL proximity transducer assembly for the PROXPAC XL Proximity Transducer Assembly.

Bently Nevada 330881-28-04-214-00-02 is an integrated PROXPAC housing with the 214 mm penetration selected for the documented machine casing and sleeve arrangement.

Before installation or replacement, confirm the complete catalog number, compatible equipment, wiring, mounting, approvals and saved configuration.
Alternative Names
330881-28-04-214-00-02 33088128042140002 330881/28/04/214/00/02 Bently Nevada 330881-28-04-214-00-02 PROXPAC XL 330881-28-04-214-00-02 330881-28-04-214-00-02 PROXPAC assembly
Technical notes
Before replacing 330881-28-04-214-00-02, verify the PROXPAC XL suffix, 40 mm standoff, 214 mm probe penetration, fittings, mounting thread, field wiring, and monitor compatibility against the installed assembly.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What does the PROXPAC XL assembly 330881-28-04-214-00-02 include as one unit?
It combines the 3300 XL 8 mm probe and Proximitor Sensor inside the PROXPAC XL housing, so a separate probe-to-sensor extension cable and separate sensor housing are not required.
How should the 214 mm penetration on 330881-28-04-214-00-02 be evaluated?
Compare the penetration and 40 mm standoff selection with the machine-case drawing, target position and required sleeve support before ordering.
What conduit arrangement is needed for 330881-28-04-214-00-02?
Verify the 3/4-14 NPT outer sleeve and the no-fitting option, then confirm that the chosen plugs, washers and conduit seal match the site installation.
Why is housing integrity important for 330881-28-04-214-00-02?
The PPS housing provides the documented Type 4X and IP66 protection only when the cover, seals, fittings and field wiring are installed correctly.
Can an ordinary 3300 XL probe be substituted into 330881-28-04-214-00-02?
No. The assembly is ordered as an integrated PROXPAC configuration; substitution requires manufacturer or engineering approval for the complete housing and sensor arrangement.
What must be verified before adjusting 330881-28-04-214-00-02 in service?
Confirm the target surface, probe clearance, sleeve support, monitor scaling and approved maintenance state before making an external adjustment.
What documents should accompany a 330881-28-04-214-00-02 request?
Provide the full assembly code, machine-case drawing, conduit orientation, target location, approval requirement and any installed PROXPAC maintenance record.
