OCR3000

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson OCR3000 is a compact redundant Ovation controller with integrated I/O-interface functions.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for OCR3000
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for OCR3000

  • Manufacturer:
    Emerson
  • Part Number:
    OCR3000
  • Product Family:
    Ovation
  • Product Type:
    Ovation Compact Redundant Controller
  • Stock:
    1
  • Processor Architecture:
    Quad-Core System-on-Chip
  • Controller / I/O Interface:
    Combined in One Module
  • I/O Branches:
    16, scanned in parallel
  • Controller Capacity:
    Up to 64,000 points
  • Control Tasks:
    5
  • Task Periods:
    10 ms to 300 s
  • Ovation I/O Compatibility:
    All Ovation I/O modules
  • Ethernet Media:
    Copper and SFP
  • Controller Redundancy:
    Supported
  • Application Compatibility:
    OCR1100
  • Compliance:
    CE marked; IEC 61131-2
  • Tariff Code:
    9032899099
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Architecture Connectivity Mounting Application
  • Compact Ovation controller combining controller and I/O-interface functions in one module
  • Quad-core architecture scans 16 I/O branches in parallel
  • Supports redundant operation and application compatibility with the OCR1100 controller

OCR3000 is an Emerson compact redundant controller designed for the Ovation distributed control platform.

The integrated module provides controller execution, I/O-interface functions, copper and SFP Ethernet options, and support for all Ovation I/O modules.

Before installation or migration, verify the redundant pair, I/O branches, network media, Ovation software release, protocol drivers, and transferred controller application.

Availability, condition, price, and shipping time for OCR3000 are confirmed during quotation.

Emerson OCR3000 Ovation Compact Redundant Controller Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • A single OCR3000 module combines controller and I/O-interface functions
  • Primary and backup controllers communicate through an integrated backplane path
  • The controller supports the documented redundant Ovation architecture
  • Copper Ethernet connections are supported
  • SFP Ethernet interfaces provide an optical-media option
  • Embedded protocol drivers support communications with third-party devices
  • OCR3000 controllers and Ovation I/O modules are designed for DIN-rail mounting
  • Controller and I/O mounting plates can be installed in new or existing cabinet enclosures
  • Both top and bottom I/O-cable entry arrangements are available for supported cabinet layouts
  • Ovation distributed control in power-generation plants
  • Water and wastewater process-control systems
  • Redundant process automation requiring local, remote, or virtual Ovation I/O
Description
OCR3000 is an Emerson Ovation Compact Redundant Controller for the documented Ovation distributed control platform.

The controller combines controller and I/O-interface functions in one module, scans 16 I/O branches in parallel, and supports copper or SFP Ethernet, redundant operation, and application compatibility with OCR1100.

Before installation or migration, confirm the redundant-controller architecture, I/O branches, network media, Ovation software release, protocol drivers, connected I/O, and validated controller application.
Alternative Names
Emerson OCR3000 Emerson Ovation OCR3000 Ovation OCR3000 OCR 3000 OCR3000 Controller Ovation OCR3000 Controller Emerson OCR3000 Redundant Controller
Technical notes
Emerson OCR3000 deployment must verify the redundant pair, 16 I/O branches, network media, Ovation software release, protocol drivers, and migrated controller application.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can Emerson OCR3000 use existing OCR1100 controller applications?
Emerson states that OCR3000 is application compatible with OCR1100, but the migration still requires verification of the Ovation software release, I/O configuration, protocol drivers, and controller database.
How does Emerson OCR3000 scan connected Ovation I/O?
The quad-core architecture scans 16 I/O branches in parallel rather than processing them through a single sequential branch path.
Which network-media options are available on Emerson OCR3000?
Emerson documents copper Ethernet and SFP Ethernet interfaces, allowing the installed network design to use the supported electrical or optical media.
Does Emerson OCR3000 require a separate I/O-interface module?
No. Emerson combines the controller and I/O-interface functions in one OCR3000 module.
How is Emerson OCR3000 firmware authenticity protected?
Emerson documents cryptographic signing of OCR3000 firmware to protect firmware integrity and authenticity.
What controller capacity is documented for Emerson OCR3000?
Emerson specifies support for up to 64,000 points and five control tasks with periods from 10 ms to 300 seconds.
Can Emerson OCR3000 communicate with third-party devices?
Yes. Emerson documents embedded protocol drivers for third-party communication; the exact driver and device configuration must be validated for the installed Ovation release.
