Features:
- Provides sixteen 12/24 VDC negative-logic discrete outputs.
- Arranges the outputs as two groups with separate field commons.
- Preserves the submitted Revision C hardware identity without borrowing later-revision features.
The current ordering configuration is
IC693MDL741C, the 16-Point 12/24 VDC Negative Logic Output Module Revision C documented for Series 90-30.
In the intended system role, the module sinks current from user loads to the negative power bus and provides status indication for its output points. Field devices operate from an external 12/24 VDC supply.
For selection and commissioning, confirm the revision label, terminal-board type, external supply, group commons and per-point load before replacement. Do not assign features documented only for later hardware revisions.
Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for GE Vernova IC693MDL741C:
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- Switches DC solenoids, pilot lights and interposing relays from a Series 90-30 PLC in machine-control systems.
- Provides grouped negative-logic outputs for conveyors, packaging equipment and other sequential automation functions.
- Supports revision-controlled replacement of a sixteen-point discrete output position in an installed PLC rack.
- Sixteen negative-logic points sink current from user loads to the field common when their assigned PLC output references are commanded on.
- Two groups of eight outputs allow separate common connections while preserving individual control of every point.
- Front status indicators display the commanded state of each channel for sequence verification and control troubleshooting.
- The terminal board and field commons must be labelled before the module is exchanged, preserving the documented mounting arrangement.
- An external 12/24 VDC source supplies the connected output loads, as required by the installed hardware layout.
- Rack slot assignment and CPU configuration must retain the original I/O reference, before the equipment is returned to normal service.
- The output circuits are designed for a nominal 12/24 VDC negative-logic field system supplied from an external source.
- Per-point and per-group current must remain within the Series 90-30 derating limits for the actual ambient temperature.
- The open I/O module requires a suitable industrial enclosure that satisfies the rack's humidity and contamination limits.
