    Apter Power provides factory-fresh, genuine Bently Nevada 3500/42M 176449-02 monitor modules to keep your 3500 condition monitoring system fully operational and optimized for shaft vibration tracking.

3500/42M 176449-02

/ 4.9
1001 reviews | Need a Specific Revision?
The 3500/42M 176449-02 Proximitor Seismic Monitor is a four-channel monitoring module designed for machinery protection and condition monitoring. It accepts inputs from both proximity probes and seismic transducers.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 3500/42M 176449-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3500/42M 176449-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    3500/42M 176449-02
  • Product Family:
    3500 System
  • Product Type:
    Proximitor Seismic Monitor
  • Stock:
    3
  • Inputs Signal:
    Accepts from 1 to 4 proximity, velocity or acceleration transducer signals
  • Power consumption:
    7.7 watts, typical
  • Input Impedance Standard I/O:
    10 kΩ (Proximitor and acceleration inputs)
  • Output Impedance:
    550 Ω
  • Transducer Power Supply:
    -24 Vdc
  • Shaft Absolute Output Impedance:
    300 Ω
  • Signal Conditioning:
    Specified at +25 ºC (+77 ºF) unless otherwise noted
  • Radial Vibration Frequency Response:
    Gap filter -3 dB at 0.09 Hz
  • Weight:
    0.8 kg
  • Estimated shipping dimensions:
    2.5x25.6x24cm
  • Tariff Code:
    8537109090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Use Cases Firmware & Updates Configuration & Programming

Features:

  • Interface Between Proximity/Seismic Transducers and 3500 Rack Monitoring System
  • Combines Capability of Signal Conditioning with Multi-Function Monitoring Support
  • Operates in Conjunction with the M Series and Standard 3500 Monitors
The 3500/42M 176449-02 operates as the Proximitor Seismic Monitor in a 3500 rack, providing continuous machinery protection by comparing monitored parameters against configured alarm setpoints. It continuously accepts input from proximity and seismic transducers, conditions the signals to provide vibration and position measurements, and distributes these conditioned signals through the rack backplane to support steady state operation of all monitoring functions. Seamless channel programming is standard with the 3500/42M 176449-02, however using flexible configuration options will allow simultaneous execution of multiple monitoring functions across its four channels. The 3500/42M 176449-02 has made improvements in several areas over previous monitor designs in addition to incorporating universal transducer input capability within the 3500 rack.

The 3500/42M 176449-02 provides essential monitoring functions common to the entire rack, and is a critical component of the protection path, directly affecting the proper, normal operation of the overall monitor system. One 3500/42M 176449-02 monitor module is required per monitoring application depending on the desired channel configuration. The 3500/42M 176449-02 occupies only a single full-height slot in the rack and can be located in any available monitor slot position.

For Multi-Function Monitoring applications, the 3500/42M 176449-02 supports paired channel programming installed within the module. In addition to standard single function operation, the paired configuration also performs automatic signal processing. The 3500/42M 176449-02 dual channel pairing executes monitoring using the internal circuitry specified in the configuration options. Using this method, the monitoring system continually processes the health of all inputs. If the system detects that any monitored parameter exceeds configured alert or danger setpoints, it will automatically drive alarms and place an event in the System Event List.

The 3500/42M 176449-02 Bently Nevada Proximitor Seismic Monitor may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 3500/42M 176449-02 Proximitor Seismic Monitor Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 3500/42M 176449-02 Proximitor Seismic Monitor Specs

General

  • Manufacturer Bently Nevada
  • Model 3500/42M 176449-02
  • Condition New Original ready stock
  • Product Family 128229-01,128240-01,135489-01
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Vibration Monitoring: Measures radial vibration, acceleration, and velocity.
  • Positioning: Tracks thrust position, differential expansion, and eccentricity.
  • Specialized Analysis: Supports REBAM (Rolling Element Bearing Activity Monitor), shaft absolute monitoring, and circular acceptance region tracking.
  • Alarming: Automatically triggers alerts or machine trips when vibration levels exceed user-defined setpoints.
  • Field Upgradable: Firmware is typically updated via the 3500 Rack Configuration Software.
  • Legacy Support: While the manufacturer may have moved newer versions to "End-of-Life" (EOL), support and spare modules are often available through third-party specialized industrial suppliers like Artisan Technology Group.
  • Status Indicators: The module features front-panel LEDs (OK, TX/RX, and Bypass) to confirm operational health and communication status during or after updates.
  • Channel Pairs: Channels are programmed in pairs (e.g., Channels 1 & 2 can perform one function, while 3 & 4 perform another).
  • Sensor Compatibility: Accepts inputs from 1 to 4 proximity, velocity, or acceleration transducers.
  • I/O Setup: Requires selection between Internal or External Termination I/O modules (e.g., part number 140471-01 for internal terminations).
  • Full-Scale Range: Adjustable from 0 to 100% of the transducer's capacity.
  • Alarm Setpoints: Configurable Alert and Danger thresholds for each measured value.
  • Filters: Supports user-programmable frequency response filters (e.g., 4 Hz to 4000 Hz) to isolate specific machine speeds or frequencies.
Description
The 3500/42M 176449-02 Proximitor Seismic Monitor is a four-channel monitoring module designed to accept inputs from both proximity and seismic transducers. It conditions these incoming signals to deliver precise vibration and position measurements, while also comparing the conditioned outputs to user-programmable alarm thresholds for reliable machine protection.

Using the 3500 Rack Configuration Software, each channel of the 3500/42M 176449-02 can be configured to monitor and report a variety of parameters. These include radial vibration, acceleration, eccentricity, REBAM, differential expansion, circular acceptance region, thrust position, shaft absolute, and velocity. The flexibility of these options allows users to tailor the monitor’s functionality to specific machine conditions and operational requirements.
Alternative Names
35OO/42M 176449-O2 3500/42M I76449-02 3500-42M 17644902 3500/42M 128229-01 3500/42M 128240-01 3500/42M 126632-01 3500/42M 143489-01
Technical notes
The Bently Nevada 3500/42M 176449-02 is a 4-channel proximitor seismic monitor that continuously protects machinery by accepting inputs from both proximity and acceleration transducers.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the storage temperature range of the 3500/42M 176449-02?
The storage temperature range is -40°C to +85°C (-40°F to +185°F).
What monitoring functions are supported by Bently Nevada 3500/42M 176449-02?
Bently Nevada 3500/42M 176449-02 monitors machinery vibration and position conditions using proximity, velocity, or acceleration transducer input signals.
How are alarm setpoints configured for the 3500/42M 176449-02?
Alarm setpoints are configured using the Rack Configuration Software. Users can set alert levels for each measured value and danger setpoints for any two of the measured values.
