Features:
- IS400ERSEG1A identifies the ERSE converter-interface position within an EX2100e regulator.
- Its control path supports pulse-width-modulated regulation of the static converter.
- The EX2100e architecture assigns one converter to simplex systems and two to dual regulators.
IS400ERSEG1A belongs to the regulator-side electronics that coordinate the static-converter path.
Board matching for IS400ERSEG1A depends on the ERSE designation and the installed simplex or dual arrangement.
Power-source selection remains an EX2100e system decision rather than a setting on IS400ERSEG1A.
The General Electric IS400ERSEG1A EX2100e Static Converter Interface Board may be available for purchase and technical support from Apter Power.
General Electric IS400ERSEG1A EX2100e Static Converter Interface Board Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Converter Interface Functions
- Control position: Transfers regulator commands into the converter-control path.
- Regulation method: Supports the pulse-width-modulated converter path used to control excitation current.
- Functional identity: ERSE distinguishes the static-converter interface function within the regulator hardware.
- System boundary: Requires the processor and power-conversion hardware of the EX2100e regulator assembly.
Regulator Power-Path Context
- Control power: The exciter installation determines the available ac, PMG, or dc control-power arrangement.
- Conversion stage: The regulator converter translates control commands into current for the amplifier path.
- Board scope: The interface board does not independently select the plant-level power source.
- Matching point: Power-source and converter configuration must agree with the installed EX2100e arrangement.
Simplex and Dual Regulator Structure
- Simplex layout: A simplex EX2100e regulator uses one converter module.
- Dual layout: A dual arrangement uses two converter modules for the regulator structure.
- Configuration check: Identify the installed redundancy layout before selecting converter hardware.
- Identification: Use the complete IS400ERSEG1A designation when verifying the ERSE position.
Installation Matching Boundaries
- Platform: The board is associated with the EX2100e excitation control system.
- Part-number scope: The IS400ERSEG1A identifier specifies the ERSE group and hardware revision.
- Hardware match: Match the ERSE function and full part number before installation.
- System settings: Regulator redundancy and source selection remain system-level configuration decisions.
