DS200SLCCG4A

/ 4.9
1001 reviews | Need a Specific Revision?
As a Group 4 LAN Communications Card, General Electric DS200SLCCG4A provides LCP-to-SDCC data exchange while omitting DLAN and ARCNET hardware.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for DS200SLCCG4A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DS200SLCCG4A

  • Manufacturer:
    General Electric
  • Part Number:
    DS200SLCCG4A
  • Product Family:
    GE Mark V/VI Driver Board
  • Product Type:
    LAN Communications Card
  • Stock:
    1
  • Hardware Group:
    SLCC Group 4
  • Network Scope:
    No DLAN or ARCNET circuits
  • Primary Processor:
    LAN Control Processor, U1
  • Program Devices:
    EPROM U6 and U7
  • Local RAM:
    U8 and U9
  • Processor Exchange:
    Dual-ported RAM U5
  • SDCC Interface:
    3PL
  • DCFB or SDCI Interface:
    2PL
  • Group 4 Grounding:
    WJ2-WJ5 provisions
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Network Scope Data Exchange Grounding Map Local Access

Features:

  • Implements Group 4 local communication without DLAN or ARCNET hardware.
  • Transfers selected processor data through the SDCC exchange buffer.
  • Uses group-specific grounding provisions at designated signal points.
Group identity is essential for DS200SLCCG4A because its communication scope differs from network-equipped SLCC versions. The absence of DLAN and ARCNET hardware is part of the board definition, not a missing option.

Controller information on DS200SLCCG4A passes through the shared buffer and the 3PL inter-card route. Local computation remains on the LCP side until data are presented to the SDCC.

Ground references on DS200SLCCG4A follow the G4 assignment for WJ2-WJ5. Keeping those provisions with the correct group prevents an unused network point from being interpreted as an active channel.

The General Electric DS200SLCCG4A Group 4 LAN Communications Card may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric DS200SLCCG4A LAN Communications Card Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Group 4 Boundary

  • DLAN: Group 4 does not implement the DLAN circuitry.
  • ARCNET: No ARCNET module is assigned to this hardware group.
  • Local Processing: The LCP and its memory devices remain active.
  • Interpretation: Absent network response is expected for interfaces not fitted.

Controller Handoff

  • U5 Buffer: Dual-ported memory separates LCP and DCP access.
  • 3PL Route: Controller-bound traffic leaves through the SDCC connection.
  • 2PL Route: The DCFB or SDCI side supplies its distinct power-and-data path.
  • Isolation: A fault can be localized to one connector boundary.

Group-Specific References

  • WJ2-WJ5: These provisions assign designated communication points to ground.
  • Group Match: The pattern belongs to the G4 board arrangement.
  • Unused Paths: Grounding distinguishes inactive network points from signal inputs.
  • Wiring Rule: Host connections must follow the G4 cabinet documentation.

On-board Interaction

  • Operator Port: Local programming and status use the dedicated service connection.
  • Status Path: Display functions are controlled by the LCP side.
  • Program Devices: U6 and U7 establish the operating-code context.
  • Check Order: Local access can be tested before the SDCC exchange route.
Description
DS200SLCCG4A is the Group 4 member of the SLCC hardware family for GE drive and exciter controls. This version concentrates on local communication processing and SDCC exchange because DLAN and ARCNET circuitry are not implemented.

Communication logic for DS200SLCCG4A runs on U1. Its memory map separates program code in U6/U7, working data in U8/U9, and the SDCC-accessible exchange buffer in dual-ported device U5.

DS200SLCCG4A reaches the SDCC through 3PL, receives the DCFB or SDCI route at 2PL, and serves the keypad/programmer at KPPL. These paths allow local status and setup access independently of the network circuits omitted from Group 4.

Group-specific grounding provisions distinguish DS200SLCCG4A from other SLCC cards. WJ2 through WJ5 assign designated communication points to ground, so the G4 jumper and connector pattern must be kept with its intended host arrangement.
Revisions

Revision Part #

Also known as

DS200SLCCG4AF
DS200SLCCG4A-F, Series F, Rev F
Alternative Names
GE DS200SLCCG4A DS200-SLCC-G4A DS 200 SLCC G4A General Electric G4 LAN card GE Group 4 communication board SLCC G4 drive interface card DS200 SLCC G4 A DS2OOSLCCG4A
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why does DS200SLCCG4A provide no DLAN or ARCNET response?
DS200SLCCG4A is the Group 4 version and does not include those network circuits. Diagnose its local processor, SDCC exchange, and wired interfaces instead of expecting DLAN or ARCNET operation.
DS200SLCCG4A appears active locally, but the SDCC sees no new data; which boundary matters?
Data leave DS200SLCCG4A through the Group 4 inter-card route at 3PL. At the processor boundary, U5 is the shared buffer; test the cable path and buffer access as separate fault domains.
DS200SLCCG4A is energized, so why is its upstream interface still silent?
On DS200SLCCG4A, upstream traffic enters from the DCFB or SDCI side through 2PL. Inspect that cable and its power/data continuity before examining the SDCC connection.
What is the practical effect of WJ2 through WJ5 on DS200SLCCG4A?
On DS200SLCCG4A, WJ2-WJ5 provide Group 4 grounding assignments for designated communication points. Their state must remain consistent with the G4 host wiring.
Where is local operator communication handled on DS200SLCCG4A?
DS200SLCCG4A uses KPPL for the keypad/programmer path. A missing local response should be traced through KPPL and the LCP memory chain, not through absent network circuits.
