    Apter Power supports IS210DSVOH1A quotations, product manuals, and Mark VI servo-path matching.

IS210DSVOH1A

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IS210DSVOH1A is a compact Mark VI simplex servo terminal board that connects valve-control outputs, LVDT feedback, and active pulse-rate signals to a VSVO processor.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IS210DSVOH1A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS210DSVOH1A

  • Manufacturer:
    General Electric
  • Part Number:
    IS210DSVOH1A
  • Product Family:
    GE Mark VI Gas Turbine Control
  • Product Type:
    Compact Simplex Servo Terminal Board
  • Stock:
    1
  • Servo Outputs:
    2 bidirectional channels
  • LVDT Inputs:
    6 position-feedback circuits
  • Pulse Inputs:
    2 active pulse-rate channels
  • Processor Interface:
    VSVO
  • Processor Cable:
    One 37-pin cable
  • Field Terminals:
    36-position Euroblock
  • Field Wiring:
    #18 AWG shielded twisted pair
  • LVDT Excitation:
    3.2 kHz, 7.00 Vrms nominal
  • Mounting:
    DIN rail, vertical stacking supported
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Servo Path LVDT Feedback Pulse Inputs Wiring Setup

Features:

  • Two simplex servo-current output channels connect through one compact terminal assembly.
  • Six LVDT feedback circuits share the VSVO cable with the servo-control paths.
  • Two active pulse-rate inputs support flow-related signal acquisition.
IS210DSVOH1A concentrates actuator drive, position feedback, and pulse-rate termination on a DIN-rail board for a simplex Mark VI signal path.

The fixed Euroblock keeps the field conductors on the terminal assembly while the 37-pin connector transfers conditioned signals to the VSVO processor.

Current-selection jumpers and electronic identification separate coil matching from controller recognition and diagnostic reporting.

Apter Power may supply and support the General Electric IS210DSVOH1A Compact Simplex Servo Terminal Board for installed Mark VI systems.
General Electric IS210DSVOH1A Compact Simplex Servo Terminal Board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Servo Path

  • Channels: Two bidirectional servo-current outputs.
  • Coil Range: Jumper selection covers the supported servo-current and coil-resistance combinations.
  • External Trip: The compact assembly includes the external trip connection used by the servo path.
  • Processor Link: One 37-pin cable carries the servo signals to VSVO.

LVDT Feedback

  • Sensor Count: Six LVDT feedback circuits are terminated.
  • Excitation: The excitation source operates at 3.2 kHz and 7.00 Vrms nominal.
  • Signal Return: Position feedback returns through the VSVO interface cable.
  • Monitoring: Excitation and feedback values participate in the board diagnostics.

Pulse Inputs

  • Input Count: Two active pulse-rate channels are provided.
  • Signal Source: The channels accept externally powered active probes.
  • Processing: Pulse signals are transferred to the VSVO processor.
  • Use: The two channels form the compact flow-measurement input path.

Wiring Setup

  • Terminal Block: A fixed 36-position Euroblock lands field conductors.
  • Cable Type: #18 AWG shielded twisted pair is used for field wiring.
  • Grounding: SCOM is available at screws 31 through 36.
  • Mounting: The board slides into a DIN-rail holder and can be stacked vertically.
Description
General Electric IS210DSVOH1A is a compact simplex servo terminal board for the Mark VI turbine-control platform. It provides the field termination between a VSVO processor and two servo channels, six LVDT position-feedback circuits, and two active pulse-rate inputs.

A 37-pin cable carries the processor-side signals for IS210DSVOH1A, while a permanently mounted 36-position Euroblock accepts the field wiring. Six SCOM screws give the board short ground-return points, and the field conductors are arranged for #18 AWG shielded twisted-pair cable.

Within IS210DSVOH1A, the servo paths deliver bidirectional coil current while the LVDT circuits provide 3.2 kHz excitation and receive the corresponding position feedback. The two pulse-rate channels accept active probe signals used by the VSVO signal-processing path.

Servo-coil jumpers on IS210DSVOH1A select the required current and resistance range. Board identification, servo-current checks, and LVDT excitation and feedback monitoring allow the VSVO controller to distinguish configuration and signal-path faults.
Alternative Names
IS210-DSVO-H1A IS210 DSVO H1A IS 210 DSVO H1A GE IS210DSVOH1A General Electric IS210DSVOH1A GE Energy IS210DSVOH1A Mark VI IS210DSVOH1A Servo Terminal Board IS21ODSVOH1A
Technical notes
General Electric IS210DSVOH1A provides two servo outputs, six LVDT feedback inputs, and two active pulse-rate inputs through a simplex VSVO connection.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How is General Electric IS210DSVOH1A linked to the servo processor?
A single 37-pin cable connects General Electric IS210DSVOH1A to the VSVO processor, carrying both control and feedback paths for the compact simplex assembly.
What field wiring should be landed on General Electric IS210DSVOH1A?
General Electric IS210DSVOH1A is arranged for #18 AWG shielded twisted-pair wiring on its fixed 36-position Euroblock, with terminals 31 through 36 used for SCOM.
Which position sensors can General Electric IS210DSVOH1A terminate?
Six LVDT position-feedback circuits terminate on General Electric IS210DSVOH1A and receive their excitation through the servo I/O path.
Why are servo-coil jumpers fitted on General Electric IS210DSVOH1A?
The jumpers let General Electric IS210DSVOH1A match the configured servo current to the connected coil resistance instead of using one fixed drive range.
Can two active pulse probes connect through General Electric IS210DSVOH1A?
Yes. General Electric IS210DSVOH1A provides two active pulse-rate inputs that pass their signals to the VSVO processor.
What can trigger a board-identification fault for General Electric IS210DSVOH1A?
A mismatch between the expected terminal-board type and the identification returned through the processor cable can make the VSVO report General Electric IS210DSVOH1A as incompatible.
