DS200SLCCG2A

/ 4.9
1001 reviews | Need a Specific Revision?
DS200SLCCG2A is General Electric's Group 2 LAN Communications Card for DLAN, SDCC processor exchange, and optional local terminal connections.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for DS200SLCCG2A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DS200SLCCG2A

  • Manufacturer:
    General Electric
  • Part Number:
    DS200SLCCG2A
  • Product Family:
    GE Mark V/VI Driver Board
  • Product Type:
    LAN Communications Card
  • Stock:
    1
  • Communication Group:
    Group 2 SLCC
  • Control System:
    GE drive and exciter controls
  • Main Processor:
    LAN Control Processor, U1
  • Program Memory:
    EPROM U6 and U7
  • Working Memory:
    RAM U8 and U9
  • Interprocessor Memory:
    Dual-ported RAM U5
  • SDCC Connection:
    3PL
  • DCFB or SDCI Path:
    2PL
  • Local Interface:
    KPPL keypad/programmer connection
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals DLAN Setup Memory Map Board Links Local Access

Features:

  • Runs LAN protocol tasks separately from drive-regulation processing.
  • Bridges DLAN and local-terminal traffic into the SDCC data interface.
  • Supports isolated or RS-422 branches with position-based termination.
Network placement gives DS200SLCCG2A a defined boundary between field communication and the drive processor. The card interprets LAN traffic before presenting organized data to the controller.

Shared-memory access on DS200SLCCG2A lets the LCP and DCP exchange information without combining their program spaces. This division preserves independent communication and regulation workloads.

Optional local hardware reaches DS200SLCCG2A through dedicated connectors rather than the DLAN pair. The keypad and LAN Terminal Board therefore remain identifiable as separate service paths.

The General Electric DS200SLCCG2A LAN Communications Card may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric DS200SLCCG2A LAN Communications Card Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

 Network Positioning

  • Driver Mode: Jumpers select isolated DLAN or RS-422 operation.
  • Termination: The physical end of a network segment requires the assigned termination.
  • Group Scope: Group 2 includes DLAN configuration provisions.
  • Separation: Network choices do not replace the independent keypad connection.

 Processor Storage

  • Program Pair: U6 and U7 contain the LCP operating program.
  • Working RAM: U8 and U9 hold active processor data.
  • Shared Buffer: U5 is dual-ported for LCP-to-DCP exchange.
  • Processor: U1 executes the LAN communication workload.

Connector Roles

  • 2PL: Carries power and data on the DCFB or SDCI side.
  • 3PL: Provides the direct inter-card route to the SDCC.
  • IOPL: Connects the optional LAN Terminal Board when fitted.
  • Path Check: Each cable has a distinct role and destination.

Operator Interface

  • KPPL: Links the keypad or programmer to the communication card.
  • Display: Alphanumeric status supports local operating checks.
  • Independence: Local access is separate from DLAN termination.
  • Software Context: Displayed states reflect the installed LCP program set.
Description
GE assigns DS200SLCCG2A to the Group 2 communication hardware for drive and exciter controllers. External network channels reach the SDCC through this card, with isolation choices selected by its DLAN configuration.

DS200SLCCG2A uses the LAN Control Processor at U1 with program storage in EPROM devices U6 and U7 and working memory in U8 and U9. Dual-ported RAM U5 exchanges data with the Drive Control Processor on the SDCC, separating LAN processing from drive-control execution.

For DS200SLCCG2A, 2PL carries power and data between the communication board and the DCFB or SDCI path, while 3PL connects to the SDCC. KPPL supports the keypad/programmer interface and IOPL is used when the optional LAN Terminal Board is present.

DS200SLCCG2A includes Group 2 DLAN provisions for driver selection, signal termination, and isolated or RS-422 operation. Jumper settings must therefore agree with the network position and interface type used by the host system.
Revisions

Revision Part #

Also known as

DS200SLCCG2ACC
DS200SLCCG2A-CC, Series CC, Rev CC
Alternative Names
GE DS200SLCCG2A DS200-SLCC-G2A DS 200 SLCC G2A General Electric G2 LAN card GE Mark V SLCC G2A DLAN communications board G2A DS200 SLCC G2 A DS2OOSLCCG2A
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why can DS200SLCCG2A communicate locally but fail at the end of a DLAN segment?
DS200SLCCG2A uses selectable DLAN termination. Confirm that termination is enabled only at the physical endpoint and that the selected driver matches the isolated or RS-422 network path.
What should be checked when DS200SLCCG2A powers up but exchanges no data with the SDCC?
Trace the DS200SLCCG2A link through 3PL and verify the U5 dual-ported RAM interface between the LAN Control Processor and the SDCC Drive Control Processor.
Which memory devices matter when DS200SLCCG2A starts with an unexpected program identity?
DS200SLCCG2A stores its operating program in EPROM devices U6 and U7. Confirm that both devices form the intended software pair for the host drive or exciter.
Why might the keypad or programmer remain inactive on DS200SLCCG2A?
Check the DS200SLCCG2A KPPL connection and the local interface path. A powered card can still lose operator access when this dedicated connection is open or misaligned.
How should the optional LAN Terminal Board be connected to DS200SLCCG2A?
When the option is present, DS200SLCCG2A uses IOPL for the LAN Terminal Board. Verify that this path is distinct from 2PL power/data and the 3PL SDCC connection.
