          Apter Power provides IS220PPRFH1B quotations, product manuals, and Mark VIe PROFIBUS matching support.

        IS220PPRFH1B

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        General Electric IS220PPRFH1B is a Mark VIe PROFIBUS master gateway that exchanges cyclic and acyclic data between IONet control and PROFIBUS DP devices.
        In Stock
        Ships by Tuesday, September 29
        Fast Shipping Available
        Get a quick price for IS220PPRFH1B
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IS220PPRFH1B

        • Manufacturer:
          General Electric
        • Part Number:
          IS220PPRFH1B
        • Product Family:
          GE Mark VIe Distributed I/O
        • Product Type:
          PROFIBUS Master Gateway Module
        • Stock:
          1
        • Protocol Role:
          PROFIBUS DP-V0/DP-V1 Class 1 master
        • Network Interface:
          RS-485 through DE-9 connector
        • Transmission Rate:
          9.6 Kbps to 12 Mbps
        • Maximum Slaves:
          124
        • Data per Slave:
          Up to 244 input bytes and 244 output bytes
        • H1B Frame Rates:
          10, 20, or 40 ms
        • Process Data Limit:
          3584 input / 3584 output / 7168 combined bytes
        • Accessory Board:
          IS200SPIDG1A
        • Power Supply:
          27.4–28.6 V dc, 0.18 A maximum
        • Operating Temperature:
          -20 to +55 °C
        • Tariff Code:
          8517623990
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Gateway Services Network Capacity HotBackup Logic Physical Interface

        Features:

        • IS220PPRFH1B operates as a PROFIBUS DP Class 1 master in Mark VIe and Mark VIeS control.
        • The gateway carries both cyclic process exchange and supported acyclic access.
        • Optional Boolean event logging records configured events with 10 ms resolution.
        IS220PPRFH1B places PROFIBUS device communication behind the controller's IONet interface.

        Its H1B configuration supports defined control-frame choices for different network loads.

        The accessory-board arrangement keeps field-bus termination separate from the controller-side gateway electronics.

        The General Electric IS220PPRFH1B PROFIBUS Master Gateway Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        General Electric IS220PPRFH1B PROFIBUS Master Gateway Module Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        PROFIBUS Master Functions

        • DP-V0 exchange: Cyclic process input and output data are transferred between the controller and slaves.
        • DP-V1 access: Acyclic Class 1 services support diagnostics and online parameterization.
        • Slave setup: The gateway applies the configured device and network parameters.
        • Alarm handling: DP-V1 alarm information is returned through the gateway interface.

        Configuration Boundaries

        • Addressed devices: One master can supervise as many as 124 PROFIBUS slaves.
        • Slave payload: Each device can use up to 244 input bytes and 244 output bytes.
        • Input total: Configured input process data must not exceed 3584 bytes.
        • Combined total: Input and output data together are limited to 7168 bytes.

        Active and Standby Pair

        • Normal state: One module owns the PROFIBUS master role while the partner remains synchronized.
        • Failure trigger: Communication loss or loss of module power can initiate takeover.
        • Transfer time: The standby unit becomes active in less than 200 ms.
        • Shared network: Both modules are wired to the same PROFIBUS segment in the approved pair arrangement.

        Connection and Operating Limits

        • Bus connector: PROFIBUS uses the RS-485 DE-9 interface.
        • Termination: Resistors are enabled only at the two physical ends of the segment.
        • Power input: The gateway draws no more than 0.18 A from a 27.4–28.6 V dc supply.
        • Ambient range: Rated operation extends from -20 to +55 °C.
        Description
        Serving the PROFIBUS side of a Mark VIe or Mark VIeS control architecture, General Electric IS220PPRFH1B is a PPRF Class 1 master gateway. Its position is between the IONet controller domain and a PROFIBUS DP segment.

        Controller configuration and output commands enter IS220PPRFH1B from IONet, are applied to the configured slave network, and return as process inputs, alarms, and diagnostic information. This two-way path includes cyclic exchange as well as supported acyclic parameter access.

        The H1B hardware defines the timing and data-capacity boundary for IS220PPRFH1B; the chosen frame rate must be evaluated together with the slave count and mapped input/output bytes. This prevents a fast update selection from being considered separately from the actual network load.

        For the physical installation, IS220PPRFH1B works with the IS200SPIDG1A accessory board and an RS-485 PROFIBUS connection. A second matching gateway can form the documented active/standby arrangement when HotBackup operation is required.
        Alternative Names
        GE IS220PPRFH1B General Electric IS220PPRFH1B IS220-PPRF-H1B IS220 PPRF H1B PPRF H1B PROFIBUS Gateway GE PPRF H1B Module Mark VIe PPRF Gateway IS220PPRF H1B
        Technical notes
        IS220PPRFH1B is the DP-V1-capable H1B gateway; its network design is constrained by both slave count and aggregate input/output byte limits.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        A slave is online but its process values do not update through IS220PPRFH1B. What should be checked first?
        Check the configured input and output byte mapping for that slave and confirm that the total network allocation remains inside the IS220PPRFH1B process-data limits.
        Why can cyclic I/O continue while a DP-V1 parameter request through IS220PPRFH1B fails?
        Cyclic DP-V0 exchange and DP-V1 acyclic access use different services; verify that the slave supports the requested Class 1 service and that IS220PPRFH1B has the correct device configuration.
        The PROFIBUS segment connected to IS220PPRFH1B is intermittent near one end. Where should termination be enabled?
        Enable termination only at IS220PPRFH1B when it is one physical end of the segment and at the device at the opposite end; intermediate nodes must not be treated as end terminators.
        An IS220PPRFH1B network is close to its capacity limit. Which figures must be evaluated together?
        Review the slave count, the bytes assigned to each slave, and the combined input/output total for IS220PPRFH1B rather than checking only one of those values.
        What should be verified if the standby IS220PPRFH1B does not take over after the active gateway loses power?
        Confirm that both IS220PPRFH1B units are configured as the approved HotBackup pair, share the intended PROFIBUS segment, and retain healthy partner communication before the failure.
        Why would an IS220PPRFH1B fail to start even though its network configuration is valid?
        Verify the IS200SPIDG1A companion hardware and the 27.4–28.6 V dc supply to IS220PPRFH1B; a valid slave map does not replace the required accessory and power conditions.
