          Request IC694MDL660 quotations, English technical information, and RX3i input-system matching from Apter Power.

        IC694MDL660

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        General Electric IC694MDL660 is a PACSystems RX3i 32-point 24 VDC positive/negative-logic input module for receiving discrete field signals.
        In Stock
        Ships by Tuesday, September 29
        Fast Shipping Available
        Get a quick price for IC694MDL660
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IC694MDL660

        • Manufacturer:
          General Electric
        • Part Number:
          IC694MDL660
        • Product Family:
          GE PACSystems RX3i
        • Product Type:
          PACSystems RX3i 32-Point 24 VDC Input Module
        • Stock:
          1
        • Input Points:
          32
        • Logic:
          Positive / negative
        • Input Groups:
          4 groups of 8
        • Input Voltage Range:
          0–30 VDC
        • Nominal Input Current:
          7 mA per point
        • Filter Times:
          0.5, 1, 2, 5, 10, 50, 100 ms
        • Backplane Current:
          300 mA
        • Rated Voltage:
          24 VDC
        • Weight:
          0.485 lbs (0.22 kg)
        • Estimated shipping dimensions:
          3.5 × 13.3 × 13.6 cm
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Input Wiring Signal Filtering Module Status Installation

        Features:

        • Accepts thirty-two discrete 24 VDC field inputs through one RX3i rack position.
        • Supports positive- or negative-logic wiring for compatible sensing devices.
        • Organizes the inputs into four groups of eight with separate group commons.
        IC694MDL660 gives an RX3i controller a dense connection point for switches, sensors, and dry-contact interfaces.

        Selectable input filtering lets IC694MDL660 reject bounce or electrical noise without forcing every installation to use the same response time.

        When IC694MDL660 is replaced, the existing group commons, polarity, terminal assignments, and filter settings should remain aligned with the controller configuration.

        The General Electric IC694MDL660 PACSystems RX3i 32-Point 24 VDC Input Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        General Electric IC694MDL660 PACSystems RX3i Input Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Field Signal Arrangement

        • Group Commons: Four eight-point groups let field returns be organized separately across the module.
        • Logic Polarity: Positive- or negative-logic devices require the matching common and signal direction.
        • Voltage Window: Field inputs operate from 0 to 30 VDC around a nominal 24 VDC system.
        • Terminal Transfer: Record each point and common before moving the removable wiring assembly to a replacement.

        Response Tuning

        • Filter Choices: Configurable intervals range from 0.5 ms to 100 ms for the thirty-two input points.
        • Contact Bounce: A longer interval can prevent a mechanical contact from appearing as several rapid transitions.
        • Noise Rejection: Filtering can suppress short disturbances that do not represent a valid field-state change.
        • Timing Check: The chosen interval must still allow the controller to recognize events within the required machine response.

        Input and Hardware Feedback

        • Point Indication: Front LEDs provide a direct view of the commanded state received at each input.
        • Controller Data: The RX3i reads the thirty-two point states through the module backplane interface.
        • Terminal Check: Module status information can identify whether the removable terminal assembly is present.
        • Revision Meaning: Status-bit interpretation differs between revision A and later IC694MDL660 hardware.

        Rack and Replacement Planning

        • Rack Position: The module installs in a compatible PACSystems RX3i universal backplane slot.
        • Field Isolation: Keep each group common associated with its original eight input circuits.
        • Configuration Match: Logic polarity and filter values in the controller project must agree with the connected devices.
        • Revision Review: Confirm the complete catalog suffix and terminal-block compatibility before exchanging hardware.
        Description
        General Electric IC694MDL660 is a PACSystems RX3i discrete input module that brings thirty-two 24 VDC field signals into one universal backplane slot. Four groups of eight points organize the input bank around separate commons.

        Positive- or negative-logic devices can connect to IC694MDL660 when signal polarity and the group common follow the selected wiring arrangement. Each active input draws approximately 7 mA at the nominal 24 VDC level.

        Selectable filtering in IC694MDL660 offers intervals from 0.5 ms to 100 ms, allowing the controller to reject contact bounce or short electrical disturbances while preserving the response required by the machine sequence.

        Front indicators on IC694MDL660 show active input points, and the removable terminal assembly keeps the four field groups organized. The module draws 300 mA from the 5 VDC backplane supply.
        Revisions

        Revision Part #

        Also known as

        IC694MDL660BC
        IC694MDL660-BC, Series BC, Rev BC
        Get Parts Quote
        IC694MDL660CC
        IC694MDL660-CC, Series CC, Rev CC
        Get Parts Quote
        IC694MDL660EC
        IC694MDL660-EC, Series EC, Rev EC
        Get Parts Quote
        Alternative Names
        IC694 MDL660 IC694-MDL660 IC694MDL 660 GE IC694MDL660 GE Fanuc IC694MDL660 General Electric IC694MDL660 RX3i IC694MDL660 IC694MDL66O
        Technical notes
        General Electric IC694MDL660 accepts 32 discrete 24 VDC inputs in four groups and supports both positive- and negative-logic wiring.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        How are the IC694MDL660 input points arranged for field wiring?
        General Electric IC694MDL660 divides its 32 inputs into four groups of eight, so each group common and field polarity must be preserved during wiring.
        Can IC694MDL660 receive both sourcing and sinking field signals?
        IC694MDL660 supports positive- and negative-logic arrangements when the connected device polarity and group common are wired consistently.
        Which IC694MDL660 setting helps stabilize a noisy input?
        Selectable IC694MDL660 input filters from 0.5 ms through 100 ms can suppress bounce or noise; choose the interval that still meets the required response time.
        What should be recorded before replacing IC694MDL660?
        Save the IC694MDL660 rack slot, terminal assignment, group commons, polarity, filter settings, and hardware revision before disconnecting field wiring.
        Why can an IC694MDL660 point remain off when 24 VDC is present?
        For IC694MDL660, check the correct group common, device polarity, terminal contact, field return, filter setting, and controller configuration before replacing the module.
        How should an IC694MDL660 replacement be matched?
        Match the complete IC694MDL660 catalog number, revision, terminal block, RX3i rack compatibility, and the existing four-group wiring plan.
