    Apter Power can provide IC695NIU001 pricing, quotation assistance, and access to the applicable official General Electric technical documentation.

IC695NIU001

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IC695NIU001 is a PACSystems RX3i Ethernet Network Interface Unit Plus for remote RX3i and Series 90-30 I/O over Ethernet Global Data.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for IC695NIU001
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC695NIU001

  • Manufacturer:
    General Electric
  • Part Number:
    IC695NIU001
  • Product Family:
    GE PACSystems RX3i
  • Product Type:
    PACSystems RX3i Ethernet Network Interface Unit Plus
  • Stock:
    1
  • Function:
    Ethernet Network Interface Unit Plus
  • Data Exchange:
    Ethernet Global Data
  • Local Logic:
    20 KB; all supported languages except C
  • User Flash:
    10 MB
  • Real-Time Clock:
    Battery backed
  • Serial Ports:
    One RS-232 and one RS-485
  • Ethernet Interface:
    Uses backplane IC695ETM001 module
  • TCP/IP Services:
    SRTP
  • Maximum Inputs:
    1300 bytes per ENIU exchange
  • Maximum Outputs:
    1300 bytes per controller set
  • Redundancy:
    Supports redundant controllers
  • Programming Software:
    PAC Machine Edition Logic Developer 5.51 or later
  • Backplane Power:
    520 mA at 3.3 VDC; 950 mA at 5 VDC for Plus version
  • Tariff Code:
    8537101190
  • Country of origin:
    United States
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals EGD Exchange Station Hardware Local Services Troubleshooting

Features:

  • Operates remote RX3i and compatible Series 90-30 I/O through EGD.
  • Includes 20 KB local logic and 10 MB user-data flash on the Plus platform.
  • Supports redundant controllers, SRTP services, serial ports, and station diagnostics.
Automatic EGD exchanges separate remote-I/O transfer from the central controller scan while returning station health information for application monitoring.

Local logic can handle selected tasks at the I/O station, but C programming is excluded from the supported language set.

Up to 1300 bytes of inputs and 1300 bytes of outputs are supported in its supported exchange arrangement.

General Electric IC695NIU001 PACSystems RX3i Ethernet Network Interface Unit Plus is available for Apter Power quotation and official-documentation support.
General Electric IC695NIU001 PACSystems RX3i Ethernet Network Interface Unit Plus Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

IC695NIU001 Automatic I/O Exchange

  • Output path: A controller-produced EGD exchange sends outputs to the station.
  • Input path: A second exchange returns inputs and NIU status.
  • Payload: Each direction supports the supported 1300-byte arrangement.
  • Timing: Update performance depends on network traffic and controller scan time.

IC695NIU001 Remote-I/O Station

  • Backplane: Use an RX3i Universal Backplane.
  • Power: Install an appropriate IC695 power supply.
  • Ethernet: Add one or more IC695ETM001 modules.
  • I/O mix: Supported RX3i and Series 90-30 modules can populate the station.

IC695NIU001 Local Processing

  • Logic space: The Plus version provides 20 KB of optional logic.
  • Language limit: Supported languages exclude C programming.
  • Flash: Ten megabytes retain local user data.
  • Clock: A battery-backed real-time clock supports station timekeeping.

IC695NIU001 Service Checks

  • Exchange status: Monitor returned status words in controller logic.
  • Flash mismatch: Clear flash before an older PME version downloads.
  • Serial access: RS-232 and RS-485 ports support local service connections.
  • Firmware: Use only a release matched to the complete hardware revision.
Description
IC695NIU001 turns an RX3i Universal Backplane into a remotely controlled Ethernet I/O station using automatic Ethernet Global Data exchange.

After configuration, IC695NIU001 exchanges inputs and outputs automatically with a capable EGD master and returns station status in the same cyclic data path.

The Plus platform adds 20 KB of optional local logic, 10 MB flash storage, a battery-backed real-time clock, two serial ports, SRTP services, diagnostics, and redundant-controller support.

An operating station combines the NIU, a Universal Backplane, an RX3i power supply, one or more IC695ETM001 Ethernet modules, application software, and the required I/O modules.
Revisions

Revision Part #

Also known as

IC695NIU001AHAD
IC695NIU001-AHAD, Series AHAD, Rev AHAD
IC695NIU001AGAD
IC695NIU001-AGAD, Series AGAD, Rev AGAD
IC695NIU001AEAD
IC695NIU001-AEAD, Series AEAD, Rev AEAD
IC695NIU001ADAD
IC695NIU001-ADAD, Series ADAD, Rev ADAD
IC695NIU001ACAD
IC695NIU001-ACAD, Series ACAD, Rev ACAD
IC695NIU001ACAC
IC695NIU001-ACAC, Series ACAC, Rev ACAC
IC695NIU001ACAB
IC695NIU001-ACAB, Series ACAB, Rev ACAB
IC695NIU001ABAA
IC695NIU001-ABAA, Series ABAA, Rev ABAA
IC695NIU001AAAA
IC695NIU001-AAAA, Series AAAA, Rev AAAA
IC695NIU001DP
IC695NIU001-DP, Series DP, Rev DP
IC695NIU001DN
IC695NIU001-DN, Series DN, Rev DN
IC695NIU001DM
IC695NIU001-DM, Series DM, Rev DM
IC695NIU001CL
IC695NIU001-CL, Series CL, Rev CL
IC695NIU001CK
IC695NIU001-CK, Series CK, Rev CK
IC695NIU001CJ
IC695NIU001-CJ, Series CJ, Rev CJ
IC695NIU001BH
IC695NIU001-BH, Series BH, Rev BH
IC695NIU001BG
IC695NIU001-BG, Series BG, Rev BG
IC695NIU001BF
IC695NIU001-BF, Series BF, Rev BF
IC695NIU001BE
IC695NIU001-BE, Series BE, Rev BE
IC695NIU001BD
IC695NIU001-BD, Series BD, Rev BD
IC695NIU001AC
IC695NIU001-AC, Series AC, Rev AC
IC695NIU001AB
IC695NIU001-AB, Series AB, Rev AB
IC695NIU001AA
IC695NIU001-AA, Series AA, Rev AA
Alternative Names
IC695 NIU001 IC695-NIU001 IC695NIU-001 GE IC695NIU001 GE Fanuc IC695NIU001 General Electric IC695NIU001 PACSystems RX3i IC695NIU001 Ethernet NIU Plus IC695NIU001
Technical notes
IC695NIU001 Error 8552 after an older programming-tool download requires clearing flash through Flash/EEPROM; clearing only controller RAM does not remove the conflict.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why does IC695NIU001 report Error 8552 when downloading an older project?
Clear the IC695NIU001 flash memory through the Flash/EEPROM command, not only RAM, before downloading with an older PAC Machine Edition version.
What should be checked when IC695NIU001 stops exchanging remote I/O?
For IC695NIU001, verify both EGD exchanges, the ETM001 path, producer and consumer IDs, network addressing, exchange status words, and controller logic monitoring.
Can IC695NIU001 execute logic locally if the controller link is interrupted?
IC695NIU001 provides 20 KB of optional local logic, but the intended behavior and output handling must be explicitly designed and tested.
Why is an Ethernet module required with IC695NIU001?
IC695NIU001 performs the NIU control function, while backplane IC695ETM001 modules provide the physical Ethernet interface used for EGD and SRTP.
How are redundant controllers connected to IC695NIU001?
Configure the IC695NIU001 input exchange to a group address so both controllers receive it, and configure output handling for the redundant architecture.
What limits the size of an IC695NIU001 EGD transfer?
IC695NIU001 supports up to 1300 bytes of inputs and 1300 bytes of outputs for the controller set.
Which serial services remain available on IC695NIU001?
IC695NIU001 includes one RS-232 and one RS-485 port for supported serial communication and service functions.
