    Apter Power supplies factory-original GE VersaMax processors, ensuring robust and high-speed distributed controller performance.

IC200CPUE05-JP

/ 4.9
1001 reviews | Need a Specific Revision?
The General Electric IC200CPUE05-JP is a central processing unit featuring an embedded Ethernet interface, designed as part of the VersaMax programmable logic controller series.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IC200CPUE05-JP
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC200CPUE05-JP

  • Manufacturer:
    General Electric
  • Part Number:
    IC200CPUE05-JP
  • Product Family:
    GE VersaMax
  • Product Type:
    Central Processing Unit
  • Stock:
    1
  • Operating Temperature Range:
    0°C to +60°C
  • Storage Temperature Range:
    -40°C to +85°C
  • Humidity Range:
    5% to 95% (non-condensing)
  • Protection Rating:
    IP20
  • Processor:
    32-bit RISC processor
  • Clock Speed:
    90 MHz
  • Memory:
    64 KB Configurable User Memory
  • Communication Interfaces:
    RS-232, RS-485, Ethernet
  • Weight:
    0.28 kg
  • Estimated shipping dimensions:
    12.6x13x7cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Operating Environment Monitoring & Control

Features:

  • Central Processing Hub for VersaMax Modular I/O Architectures
  • Embeds Ethernet alongside RS-232 and RS-485 Communication Ports
  • Accommodates Ladder Diagram and Instruction List Programming Methods
The IC200CPUE05-JP functions as the central processing unit in a VersaMax rack, providing intelligent control and embedded Ethernet connectivity to all modules within the system. The IC200CPUE05-JP incorporates non-volatile flash memory for program storage, representing a significant improvement in data retention and system reliability over previous CPU designs.

The IC200CPUE05-JP provides essential control functions common to the entire rack, and is a critical component of the control path, directly affecting the proper, normal operation of the overall automation system. One IC200CPUE05-JP CPU module is required per rack.

For memory protection and data retention applications, the IC200CPUE05-JP employs a hierarchical backup architecture. A super capacitor provides power to memory for 1 hour immediately following power loss. Beyond 1 hour, the backup battery protects memory contents for up to 6 months, ensuring sustained data preservation during extended power interruptions.

The IC200CPUE05-JP General Electric CPU with Embedded Ethernet Interface may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IC200CPUE05-JP CPU with Embedded Ethernet Interface Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
General Electric IC200CPUE05-JP CPU with Embedded Ethernet Interface Specs

General

  • Manufacturer General Electric
  • Model IC200CPUE05-JP
  • Condition New Original ready stock
  • Product Family IC200CPUE05,IC200BEM00,IC200CHS022
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Factory Automation: Packaging lines, assembly systems, and material conveyors.
  • Water Treatment: Pumping stations, flow monitoring, and chemical dosing.
  • Building Automation: HVAC control, lighting systems, and facility management.
  • OEM Machinery: Dedicated local control for complex standalone machines.
  • Mounting: Standard 35mm DIN rail or direct panel mounting.
  • Temperature: Standard operational range from 0°C to 60°C.
  • Humidity: Up to 95% non-condensing relative humidity levels.
  • Protection: Requires tool-accessible enclosures for hazardous industrial areas.
  • Memory Backup: Internal supercapacitor provides 1 hour of power.
  • Battery Backup: Removable battery retains data up to 6 months.
  • I/O Capacity: Controls 64 modules and 2,048 I/O points.
  • Built-In Ports: One RJ-45 Ethernet, one RS-232, one RS-485.
  • Ethernet Protocols: Supports SRTP Server and Ethernet Global Data.
  • Status LEDs: Visual indicators for Power, OK, Run, and Fault.
  • Port Indicators: Dedicated LED lights for Ethernet data traffic link.
  • Hardware Switches: Physical Run/Stop toggle and Ethernet Restart push button.
  • Programming: Configured via Ladder Diagram using PAC Machine Edition.
Description
The IC200CPUE05-JP is a General Electric CPU module with an embedded Ethernet interface, designed for the VersaMax PLC series. This compact and versatile controller is engineered to handle medium-scale automation tasks efficiently, providing a robust platform for process control, machine automation, and distributed I/O management. The IC200CPUE05-JP addresses the challenge of integrating multiple communication protocols and managing extensive I/O configurations within a single, space-saving unit, eliminating the need for separate communication modules and simplifying system architecture.

The IC200CPUE05-JP supports up to 64 modules with up to 2048 I/O points, making it suitable for applications requiring substantial input and output capacity. It can be either autoconfigured or configured from a programmer using configuration software, offering flexibility for both rapid deployment and detailed customization. The IC200CPUE05-JP provides 64KB of configurable memory for the application program, hardware configuration, registers (%R), analog inputs (%AI), and analog outputs (%AQ), ensuring sufficient space for complex control logic and data handling. Programming is supported in Ladder Diagram and Instruction List, accommodating engineers with different programming preferences and legacy system requirements.

Communication capabilities of the IC200CPUE05-JP include embedded RS-232, RS-485, and Ethernet interfaces, facilitating seamless integration with HMIs, SCADA systems, and other networked devices. The IC200CPUE05-JP supports the EZ Program Store device, simplifying program backup and transfer procedures. With a height of 70mm when mounted on a DIN rail with a power supply (sold separately), the IC200CPUE05-JP maintains a compact footprint suitable for space-constrained control panels.
Revisions

Revision Part #

Also known as

IC200CPUE05A
IC200CPUE05-A, Series A, Rev A
IC200CPUE05AA
IC200CPUE05-AA, Series AA, Rev AA
IC200CPUE05AB
IC200CPUE05-AB, Series AB, Rev AB
IC200CPUE05AD
IC200CPUE05-AD, Series AD, Rev AD
IC200CPUE05B
IC200CPUE05-B, Series B, Rev B
IC200CPUE05BE
IC200CPUE05-BE, Series BE, Rev BE
IC200CPUE05CF
IC200CPUE05-CF, Series CF, Rev CF
IC200CPUE05CG
IC200CPUE05-CG, Series CG, Rev CG
IC200CPUE05EG
IC200CPUE05-EG, Series EG, Rev EG
IC200CPUE05EH
IC200CPUE05-EH, Series EH, Rev EH
IC200CPUE05FH
IC200CPUE05-FH, Series FH, Rev FH
IC200CPUE05GJ
IC200CPUE05-GJ, Series GJ, Rev GJ
IC200CPUE05GK
IC200CPUE05-GK, Series GK, Rev GK
IC200CPUE05HK
IC200CPUE05-HK, Series HK, Rev HK
IC200CPUE05LT
IC200CPUE05-LT, Series LT, Rev LT
IC200CPUE05MV
IC200CPUE05-MV, Series MV, Rev MV
IC200CPUE05MX
IC200CPUE05/X, Series X, Rev X
Alternative Names
IC2OOCPUEO5-JP IC200CPUE05 JP IC200CPU005 IC200ALG322 IC200MDL740 IC200PWR102 IC200MDL241 IC200ALG240
Technical notes
To ensure superior reliability and data retention, the IC200CPUE05-JP utilizes non-volatile flash memory alongside a battery backup that protects program data and the real-time clock for up to 6 months. Additionally, an onboard super capacitor provides immediate power to the memory for 1 hour during sudden outages, while the backup battery features a shelf life of 5 years when not in use.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the IC200CPUE05-JP module used for in automation systems?
The GE IC200CPUE05-JP CPU Module is a central processing unit used in industrial automation systems. It functions as the control “brain,” managing logic execution, data processing, and communication between connected I/O modules.
How large a system can the IC200CPUE05-JP support?
It can support up to 64 expansion modules and handle up to 2048 I/O points. This makes it suitable for medium to large-scale distributed control applications requiring extensive field device connectivity.
Does the IC200CPUE05-JP support easy maintenance or program updates?
Yes. It includes a physical Run/Stop switch for operational control and supports the EZ Program Store device, allowing programs to be transferred, copied, or updated without a computer.
How flexible is system configuration with this IC200CPUE05-JP CPU?
The system can be automatically configured or manually set using programming software, allowing engineers to adapt it to different automation requirements.
How does this IC200CPUE05-JP support system upgrades or modernization?
It can be integrated with Ethernet-based HMI panels and expanded I/O modules, making it suitable for upgrading older systems into more connected, IoT-ready industrial environments.
