HE693RTD600T

/ 4.9
1001 reviews | Need a Specific Revision?
HORNER HE693RTD600T is a six-channel RTD input module with 16-bit conversion and Revision T identification for installed Series 90-30 or supported RX3i systems.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for HE693RTD600T
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for HE693RTD600T

  • Manufacturer:
    HORNER
  • Part Number:
    HE693RTD600T
  • Product Family:
    HORNER
  • Product Type:
    6-Channel RTD Input Module
  • Stock:
    1
  • Input channels:
    6 RTD inputs
  • Resolution:
    0.5 °C or 0.5 °F
  • Conversion:
    16-bit integrating A/D
  • Conversion rate:
    50 channels/s
  • Power draw:
    75 mA typical at 5 VDC
  • Operating temperature:
    0 to 60 °C
  • Tariff Code:
    8537101190
  • Country of origin:
    United States
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals RTD Inputs Revision Fit Channel Checks Applications

Features:

  • Six RTD channels: consolidates temperature inputs in one module.
  • 16-bit conversion: uses an integrating A/D path for resistance-temperature acquisition.
  • Revision identity: the T suffix supports platform and hardware matching.
The complete revision marking distinguishes the required hardware from earlier HE693RTD600 versions.

Sensor type, terminal wiring and accepted scaling define whether the installed channel configuration can be retained.

The documented conversion path supports multi-point temperature acquisition where consistent RTD interpretation matters.

For HORNER HE693RTD600T 6-Channel RTD Input Module requirements, Apter Power provides technical-document review, quotations and procurement support.
HORNER HE693RTD600T 6-Channel RTD Input Module Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Channel count: six RTD inputs share the module.
  • Sensor selection: the configured RTD type must match the connected element.
  • Resolution: RTD600 scaling is documented at 0.5 °C or 0.5 °F.
  • Update rate: conversion is specified at 50 channels per second.
  • Exact suffix: the supplied unit is marked Revision T.
  • Platform check: compare Series 90-30 or RX3i support with the installed rack.
  • Terminal match: retain the accepted field-wire and return arrangement.
  • Configuration record: keep scaling and alarm limits with the replacement file.
  • Open sensor: inspect the RTD loop before attributing a fault to the module.
  • Reading bias: compare lead arrangement and configured RTD type.
  • Shared symptoms: multiple affected channels can indicate power or rack issues.
  • Acceptance: verify stable ambient and simulated-temperature readings before release.
  • Process temperature: acquires RTD measurements for PLC logic.
  • Machine thermal monitoring: supervises bearings, enclosures or process surfaces.
  • Legacy rack maintenance: supports exact-revision replacement in installed systems.
  • Migration preparation: preserves channel and scaling records for platform review.
Description
Six resistance-temperature channels give HE693RTD600T a consolidated 16-bit acquisition path, helping engineers bring multiple RTD signals into one Horner PLC slot.

Revision T on HE693RTD600T is part of the hardware identity because Horner distinguishes earlier Series 90-30-only revisions from later Series 90-30 and RX3i support.

For replacement planning, HE693RTD600T should be checked against the installed PLC platform, RTD type, terminal wiring and accepted scaling; Apter Power can assist with documentation and exact-revision sourcing.
Alternative Names
HE693RTD600T HE693RTD600-T HE693 RTD600T HE693 RTD 600 T Horner HE693RTD600T HE693RTD600 Rev T HE693RTD600 Revision T
Technical notes
Revision T is part of the hardware identity. Confirm the rack family and RTD wiring before transferring channel scaling or alarm limits from an earlier HE693RTD600 revision.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can HE693RTD600T consolidate six RTD loops in one PLC slot?
Yes. Six RTD inputs bring six temperature points into one slot, reducing rack space for a multi-sensor installation.
Can HE693RTD600T support a temperature process that needs updates within one second?
Yes for many monitoring duties. Its 50-channel-per-second conversion rate should be compared with the fastest alarm or control response required by the process.
Is HE693RTD600T suitable when operators need half-degree temperature resolution?
Yes. Its 0.5 °C or 0.5 °F resolution supports half-degree display increments when the PLC and HMI use the same units and scaling.
Is HE693RTD600T suitable for a cabinet that may exceed 60 °C?
Its operating range ends at 60 °C, so a hotter enclosure needs cooling or a different installation before the module is selected.
Can a PLC rack with only 60 mA of spare 5 V capacity accept HE693RTD600T?
Additional capacity is needed because the module typically draws 75 mA at 5 VDC. Include that demand in the complete rack power budget.
Which RTD sensor families can be configured with HE693RTD600T?
The module supports Pt-100 variants, Pt-1000, Cu-10/50/53/100, Ni-120, Pt-90, TD5R and linear-resistance inputs; select the matching channel type for each sensor.
